R410A TECHNICAL MANUAL Split Systems Air Conditioner Ducted Blower H Series FDN/FGN-H Series — Cooling Only [50Hz] — TM-5SBH-MSS-STA3 Supersede : TM-5SBH-MSS-STA2...
Omitted: Original Version Market “Blank”: Global Standard 4: Indonesia Power Supply V1: 220-240V/1Ph/50Hz Y1: 380-415V/3Ph/50Hz Product Series H: H series Capacity* 80: 80,000 Btu/hr 100: 100,000 Btu/hr 125: 125,000 Btu/hr 150: 150,000 Btu/hr 200: 200,000 Btu/hr 250: 250,000 Btu/hr 300: 300,000 Btu/hr...
Market “Blank”: Global Standard 4: Indonesia Power Supply Y1: 380-415V/3Ph/50Hz Specification Omitted: Microchannel E: E-coating Microchannel Product Series H: H series Capacity* 80: 80,000 Btu/hr 100: 100,000 Btu/hr 125: 125,000 Btu/hr 150: 150,000 Btu/hr Refrigerant N: R410A Model R: Modular Condensing Unit (Horizontal Discharge)
Application Information Application Information Operating Range Ensure the operating temperature is in allowance range. Cooling Outdoor DB (°C) The use of your air conditioner outside the range of working temperature and humidity can result in serious failure. Indoor WB (°C) Cooling Operation Range DB: Dry Bulb WB: Wet Bulb...
Application Information Installation Guideline INDOOR PRELIMINARY SITE SURVEY a) Electrical supply and installation is to conform to local authority’s (e.g. National Electricity Board) codes and regulations. b) Voltage supply fluctuation must not exceed +/- 10% of rated voltage. Electricity supply line must be independent of welding transformers which can cause supply fluctuation. c) Ensure that the location is convenient for wiring and piping. MOUNTING a) For ceiling mounted models, locate a position where piping and ducting work can be kept to a minimum.
Page 12
Application Information INDOOR CLEARANCE Mounting Ensure that the overhead supports are strong enough to hold the unit’s weight. Position hanger rods and check for alignment with the unit. Check that hangers are secure and that the base of fan-coil unit is level in the two horizontal directions, taking into account the gradient recommended for drainage flow as shown.
Page 13
Application Information OUTDOOR LOCATION FOR INSTALLATION OF THE CONDENSING UNITS As condensing temperature rises, evaporating temperature rises and cooling capacity drops. In order to achieve maximum cooling capacity, the location selected should fulfill the following requirements:- a) Install the condensing (outdoor) unit in a way such that hot air distributed by the outdoor condensing unit cannot be drawn in again (as in the case of short circuit of hot discharge air). Allow sufficient space for maintenance around the unit.
Page 14
Application Information OUTDOOR CLEARANCE SINGLE UNIT PATTERN 1 PATTERN 2 1200 TOP VIEW TOP VIEW RN80HY1 SERVICE PANEL PATTERN 1 PATTERN 2 PATTERN 1 PATTERN 2 1500 AIR DISCHARGE DIRECTION TOP VIEW TOP VIEW TOP VIEW TOP VIEW WALL / CEILING PATTERN 3 <1500 AIR DISCHARGE GRILL...
Page 15
Application Information Cable Size Cooling only FDN80HV1 FDN100HV1 Model Unit RN80HY1 RCN100HY1 Indoor 220 - 240V / 1Ph / 50Hz + Voltage range** Outdoor 380 - 415V / 3Ph / 50Hz + N + Power supply cable size* a) Indoor Unit b) Outdoor Unit c) Total Number of conductors a) Indoor Unit b) Outdoor Unit Interconnection cable size* Number of conductors Recommended fuse/ circuit breaker rating*...
Page 16
Application Information 2FGN250HY1 2FGN300HY1 3FGN300HY1 Model Unit RCN125HY1 x 2 RCN150HY1 x 2 RCN100HY1 x 3 Indoor 380 - 415V / 3Ph / 50Hz + N + Voltage range** Outdoor 380 - 415V / 3Ph / 50Hz + N + Power supply cable size* a) Indoor Unit b) Outdoor Unit 10.0 c) Total Number of conductors a) Indoor Unit b) Outdoor Unit Interconnection cable size* Number of conductors...
Page 17
Application Information 3FGN450HY1 4FGN500HY1 4FGN600HY1 Model Unit RCN150HY1 x 3 RCN125HY1 x 4 RCN150HY1 x 4 Indoor 380 - 415V / 3Ph / 50Hz + N + Voltage range** Outdoor 380 - 415V / 3Ph / 50Hz + N + Power supply cable size* a) Indoor Unit b) Outdoor Unit 10.0 10.0 c) Total Number of conductors a) Indoor Unit b) Outdoor Unit Interconnection cable size* Number of conductors...
Page 18
Application Information REFRIGERANT PIPING Maximum Piping Length and Maximum Number of Bends When the pipe length becomes too long, both the capacity and reliability will drop and as the number of bends increases, system piping resistance to the refrigerant flow increases, thus lowering the cooling capacity. As a result the compressor may become defective. Always choose the shortest path and follow the recommendation as tabulated below: Cooling Only Model Outdoor...
Sound Data Sound Data Sound Pressure Level Indoor 1/1 Octave Sound Pressure (dB, ref 20μPa) Overall Noise Model Speed (dBA) Criteria 125Hz 250Hz 500Hz 1kHz 2kHz 4kHz 8kHz High FDN80HV1 High FDN100HV1 FDN125HY1 High FDN150HY1 High 2FDN200HY1 High 2FGN250HY1 High 2FGN300HY1/ High 3FGN300HY1...
Sound Data Indoor Model Measuring Location 2FGN250HY1 2FGN300HY1 3FGN300HY1 3FGN350HY1 UNIT 4FGN400HY1 3FGN450HY1 4FGN500HY1 4FGN600HY1 2m discharge duct length Free return duct Microphone position: 1m away from every side panel of the unit and 1m above the floor level. (Tested with 2m length duct at the air discharge outlet only) Standard: JIS B 8615 Sound Power Level 1/1 Octave Sound Power Level (dB) ref 1pW Overall...
Selection Process Selection Process Drive Package The following are the design requirements for 2FGN250HY1 unit: Model: 2FGN250HY1 Supply Air Quantity 9000 External Static Pressure Step 1: From the fan curve (at 9000 CFM), Standard operating system; Internal Static Pressure Step 2: Therefore at 9000 CFM and 350 Pa external static pressure, Total Static Pressure 250 + 350 Step 3:...
Page 29
Selection Process The following table summarizes the pulley data, motor size used for the FDN/FGN-H series, as manufactured: Pulley Centre Distance, C Model Motor (kW) Motor RPM Horizontal (mm) Vertical (mm) FDN125HY1 1500 FDN150HY1 1500 2FDN200HY1 1420 2FGN250HY1 1440 2FGN300HY1/...
Page 30
Selection Process Example 1: 2FGN250HY1 2FGN250HY1 Blower Curve 5.5 kW 4.0 kW Selected Point 3.0 kW Standard Point Internal Static Pressure with filter Internal Static Pressure w/o filter 6000 6500 7000 7500 8000 8500 9000 9000 4250 2830 3300 3100 3700 4100 Air Flow...
Page 31
Selection Process FAN PERFORMANCE CURVE FDN80HV1 FDN80HV1 MEDIUM HIGH 1000 1200 1400 1600 1800 2000 2200 2400 2600 2800 1040 1180 1320 Air Flow...
Page 32
Selection Process FDN100HV1 FDN100HV1 MEDIUM HIGH 2000 2200 2400 2600 2800 3000 3200 3400 3600 1570 1320 1450 1080 1210 1700 Air Flow...
Engineering & Physical Data Engineering & Physical Data Engineering Data – R410A COOLING MODEL INDOOR UNIT FDN80HV1 FDN100HV1 FDN125HY1 FDN150HY1 MODEL OUTDOOR UNIT RN80HY1 RCN100HY1 RCN125HY1 RCN150HY1 Btu/h 80000 100000 125000 150000 NOMINAL COOLING CAPACITY 23400 29300 36600 44000 NOMINAL TOTAL INPUT POWER (COOLING) 7100 10000 11350...
Page 44
Engineering & Physical Data Engineering Data – R410A COOLING MODEL INDOOR UNIT 2FDN200HY1 2FGN250HY1 2FGN300HY1 3FGN300HY1 MODEL OUTDOOR UNIT RCN100HY1 x 2 RCN125HY1 x 2 RCN150HY1 x 2 RCN100HY1 x 3 Btu/h 200000 250000 300000 300000 NOMINAL COOLING CAPACITY 58600 73200 88000 88000...
Page 45
Engineering & Physical Data Engineering Data – R410A COOLING MODEL INDOOR UNIT 3FGN350HY1 4FGN400HY1 MODEL OUTDOOR UNIT RCN100HY1 RCN125HY1 x 2 RCN100HY1 x 4 Btu/h 350000 400000 NOMINAL COOLING CAPACITY 102500 117200 NOMINAL TOTAL INPUT POWER (COOLING) 34550 39330 NOMINAL RUNNING CURRENT (COOLING) 60.40 70.20 2.97...
Page 46
Engineering & Physical Data Engineering Data – R410A COOLING MODEL INDOOR UNIT 3FGN450HY1 4FGN500HY1 4FGN600HY1 MODEL OUTDOOR UNIT RCN150HY1 x 3 RCN125HY1 x 4 RCN150HY1 x 4 Btu/h 450000 500000 600000 NOMINAL COOLING CAPACITY 131900 146500 175850 NOMINAL TOTAL INPUT POWER (COOLING) 45930 49990 61620...
Performance Data Performance Data Calculation Steps Interpolation method can be used to get the total Solution: cooling capacity, TC and sensible cooling capacity, Based on the Performance Table, SC and power input, PI at those temperatures which 1. Refer to the Indoor DB column, are not stated out in the table.
Page 48
Performance Data (b) Indoor Condition: 25°C DB, 16°C WB By Interpolation Method Outdoor Condition: 35°C DB 25°C – 24°C – 29.18kW ⇒ Outdoor temperature 27°C – 24°C 29.30kW – 29.18kW 35°C ⇒ x = 29.22kW Similarly, = 19.11kW 29.18 18.11 9.99 = 9.99kW 29.30...
Outlines & Dimensions Outlines & Dimensions Indoor Unit Model: FDN80/100HV1 FOR ILLUSTRATIVE PURPOSES ONLY FRONT RIGHT Note: Dimension in mm Model / Dimension 80 / 100 1502 1402 1462 Model / Dimension 80 / 100 1242 Model / Dimension 80 / 100 Model / Dimension 80 / 100...
Page 63
Outlines & Dimensions Model: FDN125/150HY1 FOR ILLUSTRATIVE PURPOSES ONLY FRONT RIGHT Note: Dimension in mm Model / Dimension 125 / 150 1640 1040 1540 1600 Model / Dimension 125 / 150 1377 Model / Dimension 125 / 150 Model / Dimension 125 / 150...
Page 64
Outlines & Dimensions Model: 2FDN200HY1 FOR ILLUSTRATIVE PURPOSES ONLY FRONT RIGHT Note: Dimension in mm Model / Dimension 1794 1624 1854 1894 Model / Dimension Model / Dimension 1040 Model / Dimension...
Page 65
Outlines & Dimensions Model: 2FGN250/300HY1 FOR ILLUSTRATIVE PURPOSES ONLY FRONT RIGHT Note: Dimension in mm Model / Dimension 1766 1636 1826 1866 1766 1636 1826 1866 Model / Dimension 1291 1291 Model / Dimension 1199 1069 1196 1073 1199 1069 1196 1073 Model / Dimension...
Page 66
Outlines & Dimensions Model: 3FGN300HY1 FOR ILLUSTRATIVE PURPOSES ONLY FRONT RIGHT Note: Dimension in mm Model / Dimension 1766 1636 1826 1866 Model / Dimension 1291 Model / Dimension 1199 1069 1196 1073 Model / Dimension...
Page 67
Outlines & Dimensions Model: 3FGN350/450HY1 FOR ILLUSTRATIVE PURPOSES ONLY FRONT RIGHT Note: Dimension in mm Model / Dimension 2022 1852 2082 2122 2174 2004 2234 2274 1240 Model / Dimension 1546 1546 Model / Dimension 1199 1069 1451 1326 1466 1336 1451 1326...
Page 68
Outlines & Dimensions Model: 4FGN400/500HY1 FOR ILLUSTRATIVE PURPOSES ONLY FRONT RIGHT Note: Dimension in mm Model / Dimension 2022 1852 2082 2122 1199 1069 2174 2004 2234 2274 1466 1336 Model / Dimension 1240 1546 1240 1546 Model / Dimension 1451 1326 1451...
Page 69
Outlines & Dimensions Model: 4FGN600HY1 FOR ILLUSTRATIVE PURPOSES ONLY FRONT RIGHT Note: Dimension in mm Model / Dimension 1883 1978 1758 2234 2004 1680 Model / Dimension 2174 1905 1775 Model / Dimension Model / Dimension...
Page 70
Outlines & Dimensions Outdoor Unit Model: RN80HY1 FOR ILLUSTRATIVE PURPOSES ONLY LEFT FRONT Note: Dimension in mm Model / Dimension 1235 929...
Page 71
Outlines & Dimensions Model: RCN100/125/150HY1 FOR ILLUSTRATIVE PURPOSES ONLY LEFT FRONT Note: Dimension in mm Model / Dimension 1067 1006 1030 1067 1002 1006 1030 1166 1002 1096...
Service & Maintenance Service & Maintenance The design concept of the Condensing Unit is such that all servicing can be done from the front and side of the unit. Upon removal of front and side panel, all the electrical “terminal box”, fan and motor assembly and compressor are easily accessible.
Page 76
Service & Maintenance MAINTENANCE For superb performance and lasting durability, please do not forget to conduct proper and regular maintenance. Cleaning The Outdoor Unit Heat Exchanger If you use your air conditioner for prolonged period of time, the outdoor unit heat exchanger will become dirty impairing its function and reducing the performance of the air conditioned.
Troubleshooting Troubleshooting When a malfunction of the air conditioner unit is detected, immediately switch off the main power supply before proceeding with the following troubleshooting procedures. The following are common fault conditions and simple troubleshooting tips. If any other fault conditions which are not listed occur, contact your nearest local dealer.
Page 78
Troubleshooting Error Code Wired Handset : BRC51A62/64 When the system is on and an error occurs, the seven segments LED will blink an error code. Each error code blinking represents different message as below: Error Seven Segments Room Sensor missing / Short E1 blinking Indoor coil sensor missing / Short E2 blinking...
Page 79
Troubleshooting Phase Sequencer The unit with Scroll Compressor can only rotate in one direction. For this reason, a protective device (phase protector) is fitted to prevent incorrect wiring of the electrical phases. When the three phases are not connected correctly, the phase protector operates, and the unit will not start. This device is located in the control box of the outdoor unit. The following table shows the LED indicator light for phase protector under normal operation and fault conditions.
