Pressure Systems with
Installation and Operating
NOTE: Prior to installation remove the inlet and outlet
pipe transport plugs & associated seals from the
suction and/or discharge ports.
WARNING : The Torrium2 controller, pump and associated pipework operate
under pressure. Under no circumstances should the Torrium2 controller,
pump or associated pipework be disassembled unless the internal pressure
of the unit has been relieved. Failure to observe this warning will expose
persons to the possibility of personal injury and may also result in damage
to the pump, pipework or other property.
WARNING: Failure to follow these instructions and comply with all applicable
codes may cause serious bodily injury and/or property damage.
Please pass these instructions on to the operator of this equipment.
Davey BIT Series
Instructions

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BIT Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Davey BIT Series

  • Page 1 Davey BIT Series Pressure Systems with Installation and Operating Instructions NOTE: Prior to installation remove the inlet and outlet pipe transport plugs & associated seals from the suction and/or discharge ports. WARNING : The Torrium2 controller, pump and associated pipework operate under pressure.
  • Page 2 Davey pressure system is designed to handle clean water. The system should not be used for any other purpose without specific referral to Davey. The use of the system to pump flammable, corrosive and other materials of a hazardous nature is specifically excluded.
  • Page 3 Priming Cap which covers the 1” Male Vertical Outlet and access to the internal check valve. Horizontal Outlet 1” Male Status Indicator Lights Prime Button Rotary Coupling Inlet 1” Male Fitting the Torrium2 directly to the Pump The Torrium2 is fitted with a rotary coupling. This coupling allows the pump controller to be fitted simply and easily to the pump discharge.
  • Page 4: Choosing A Site

    If you use the vertical outlet instead or as well, you need to consider access to the inbuilt check valve in the Torrium. Davey suggest you use the enclosed flexible connection to allow for ease of access to the check valve.
  • Page 5 All wiring must conform to National (NEC), CSA, state, provincial, and local codes. Power supply voltage, phase and controls must match motor. The Davey Torrium2 fitted to this pump has status indicator light mounted on its front panel. These lights will only work when unit is connected to an electrical supply.
  • Page 6: Pipe Connections

    NOTE: For protection, the Davey pump motors are fitted with an automatic reset thermal overload, constant tripping of this overload indicates a problem e.g. low voltage at pump, excessive temperature (above 115°F) in pump enclosure. Pipe Connections For best performance use P.V.C. or polythene pipes at least the same diameter as the pump’s inlet and delivery...
  • Page 7 Evaporative coolers, RO filters and extra draw-off capacity Where a Torrium2 equipped pump is required to supply water to an evaporative cooler, reverse osmosis (R.O.) filter or similar low flow device, the Torrium2 will detect the limited demand. This will result in the Torrium2 adapting to the slow demand. The pump start pressure will be allowed to drop to a lower cut in pressure each time low flows are detected.
  • Page 8 BOOSTING MUNICIPAL WATER SUPPLY OR WELL PUMP APPLICATIONS We recommend the Davey BT Series or changing the Torrium2 from model TT45 to TT70. Abrasive Materials The pumping of abrasive materials will cause damage to the pressure system which will then not be covered by the guarantee.
  • Page 9 Priming and Operation The Torrium2 module fitted to your BIT Series Pressure Pump is provided with a push button “Prime” button. This button is used during initial priming of the pump and also acts as a reset button if the Torrium2 switches out in pump protection mode.
  • Page 10: Maintenance

    MOTOR STOPS - YELLOW STATUS INDICATOR LIGHT IS ILLUMINATED. 1. Motor ”over temperature” cut-out tripped. Consult Davey dealer. 2. Motor not free to turn - e.g. a jammed impeller. Consult Davey dealer. 3. Prime button has been held in for too long. Release prime button and switch off power for 1 minute to allow unit to reset.
  • Page 11 During servicing, use only approved, non-petrochemical based oring and gasket lubrication. If unsure, consult your Davey Dealer for advice. WARNING: Do not use hydrocarbon based or hydrocarbon propelled sprays around the electrical components of this pump.
  • Page 12 The product must only be connected to the voltage shown on the nameplate. 4. Davey shall not be liable for any loss of profits or any consequential, indirect or special loss, damage or injury of any kind whatsoever arising directly or indirectly from the product or any defect, and the purchaser shall indemnify Davey against any claim by any other person whatsoever in respect of any such loss, damage or injury.
