VeriFone X990 Pro User Manual

Thank you very much for choosing VERIFONE products, please read this manual before deployment so that you could know
the performance better. Please keep this manual for your reference.
Our company will try best to adopt new technologies, new components, new software to improve products. The features,
functions and operations described in this document may be different from the performance of the selling products, in some
cases, the images are prototype. Please inquiry the company or agent for appropriate update.
The device should be installed by after sale service personnel. Our company shall not be liable for any consequences arising
from unauthorized changes to the equipment, replacement of the connected equipment and cables which are not specified.
The User Manual applies to X990 Pro, X990 Pro DW, X990 Pro CT, X990 Pro INCT, X990 Pro DWCT.
Verifone Systems (China) Inc, reserves the right to change product technical specification without prior notice.
1. Overview
Front camera (optional)
Charging LED
/('
Touch screen
VFUHHQ
2. User instruction
2.1 ON/OFF
POWER ON:
Connect the terminal with the dedicated 9V power supply in the box, press "
Power OFF:
press " " ON/OFF button for 3 seconds and then click "Power Off ". on the screen
2.2 Magstripe
Put the magnetic card into the magnetic card slot to read it, with magnetic side towards the printer. Keep the card smooth,
steady when swiping the card.
2.3 Smart card
Insert smart card into the smart card slot, with the metal pads of the smart card facing up, please refer to card identification.
2.4 Contactless
Tab the contactless card near the contactless landing zone on the device, to make contactless transaction.
Put one contactless card one time to avoid confliction.
User Manual
CLTS/NFC
Landing zone
Magstripe
ON/OFF
Smart card
USB-C ON/OFF
ON/OFF
DC-9V
USB-A
POS Terminal User Manual
Paper cabin
Product Label
Speaker
SIM Card cover
Ethernet
RS232
PINPAD
" ON/OFF button for 3 seconds.
