PACIFIC RANGE HOOD
OPERATING INSTRUCTION
Model Number:
PHBX5670
Read all instructions before operating the range hood.
331-01-000498(1)

Advertisement

Chapters

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PRO PHBX5670 and is the answer not in the manual?

Questions and answers

Summary of Contents for Pacific PRO PHBX5670

  • Page 1 PACIFIC RANGE HOOD OPERATING INSTRUCTION Model Number: PHBX5670 Read all instructions before operating the range hood. 331-01-000498(1)
  • Page 2: Table Of Contents

    Table of Content Safety Information P1-P3 Product Functions / Performance Specification Chart Part Supplied Circuit Diagram Installation Specifications List of Materials Installation Guidelines Installation Procedures – Under Cabinet P10-P11 Installation Procedures – Wall Mount P12-P13 Installation Instructions – Optional Duct Cover P14-P15 Operating Instructions P16-P17...
  • Page 3: Safety Information

    Safety Information READ AND SAVE THESE INSTRUCTIONS Your safety and the safety of others are very important. WARNING We have provided many important safety messages in this manual for your appliance. Always read and obey all safety messages. WARNING - TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS, OBSERVE THE FOLLOWING: a) Use this unit only in the manner intended by the manufacturer.
  • Page 4 Safety Information READ AND SAVE THESE INSTRUCTIONS WARNING WARNING WARNING - TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, WARNING - TO REDUCE THE RISK OF INJURY TO PERSONS OR INJURY TO PERSONS, OBSERVE THE FOLLOWING: IN THE EVENT OF A RANGE TOP GREASE FIRE, OBSERVE THE FOLLOWING a : a) Installation work and electrical wiring must be done by qualified person(s) in accordance with all applicable codes and...
  • Page 5 Safety Information READ AND SAVE THESE INSTRUCTIONS Operation Always leave safety grilles and fil ters in place. Without these components, operating blowers could catch onto hair, fingers and loose clothing. The manufacturer declines all responsibility in the event of failure to observe the instructions given here for installation, maintenance and suitable use of the product.
  • Page 6: Product Functions / Performance Specification Chart P4

    Product Functions 1. Memory function to remember the last used fan and light settings 2. 3-min and 5-min automatic delay off 3. Built-in timer 4. Built-in clock Performance Specification Chart Model PHBX5670 Weights (kg) NW 18 / GW 25 Color Black Glass + Stainless Steel Dimension (mm) (D x H x W) 480 x 315 x 693...
  • Page 7: Part Supplied P5

    Parts Supplied (2) 6” Collar (1) Mounting Bracket (1) Hood Body (1) Blower Housing (1) Bottom Panel (1) Glass Touch Control (1) Oil Tray (1) LED Strip...
  • Page 8: Circuit Diagram

    Circuit Diagram...
  • Page 9: Installation Specifications

    Installation Specifications Dimensional Drawing 58.6 Side Front Back Mounting Template Cabinet Wall...
  • Page 10: List Of Materials

    List of Materials Part Supplied STANDARD CONFGURATION HARDWARE PACKET CONTENT 5x24x1T Washer Hood 3/16x3” Flat Head Screw 6 inch Collar #6x 1-1/2" Wood Screw M4x8 Round Head Screw Round Rubber Oil Tray 太 平 洋 油 煙 機 排油煙機使用說明書 Duct Cover; Upper User Manual 型號: PHBX5670...
  • Page 11: Installation Guidelines

    Installation Guidelines 1.Location • Air turbulence from window/door may reduce the effectiveness of hood. Suggest to close windowdoor before using hood .(FIG. 1) 2.Mounting Height and Position (FIG.1) • The installation height is measured vertically from center of hood to the top of the cook top. •...
  • Page 12: Installation Procedures - Under Cabinet

    Installation Procedures Under Cabinet – 1. Take out the appliance from the box and check 4. Place the template at the desired location on the List of Material . the wall, and drill the holes as indicated on the template, remove the template after all holes were drilled.
  • Page 13 Installation Procedures Under Cabinet – 7. Place the "Cabinet" template facing down and 12. Use (6)M4x8 round head screws to screws the stick it on the bottom of the upper cabinet, drill collar on the top of hood. holes according to the template, take down the template after all holes were drilled.
  • Page 14: Installation Procedures - Wall Mount

    Installation Procedures Wall Mount – 1. Take out the appliance from the box and check 4. Place the template at the desired location on the wall, the List of Material . and drill the holes as indicated on the template, remove the template after all holes were drilled.
  • Page 15 Installation Procedures Wall Mount – 7. Use two holes located at the upper backside to 11. Use (6)M4x8 round head screws to screws the hang the appliance on the installation bracket. collar on the top of hood. 8. Secure the support brackets with (2) M4x8 round head screws above the appliance.
  • Page 16: Installation Instructions - Optional Duct Cover

    Installation Instructions – Optional Duct Cover P1C-0068 Duct cover Optional Duct Cover 560-1070mm Model #: P1C-0068 Note: P1C-0068 is not supplied in the package, To order it, please call 23936060. 1. Center and attach duct cover bracket to wall below ceiling or soffit using (2)#6x 1-1/2" wood screws.
  • Page 17 Installation Instructions – Optional Duct Cover 2. Attach the (2) bottom brackets to the top of hood by securing the (6) M4x8 black screws for each side. 3. Remove the protective film from the duct cover surface. 4. Extend inner (top) duct cover upwards and secure to duct cover bracket using (2) M4x8 round head screws.
  • Page 18: Operating Instructions

    Operating Instructions Show the Speeds & Timer Hour Minute PROXIMITY SENSOR When approaching the hood while it is powered off, the clock will illuminate. If neither the fan nor lights are turned on within 60 seconds, the clock will turn off. The icons will not disappear until the fan and lights are turned off.
  • Page 19 Operating Instructions Show the Speeds & Timer Hour Minute Timer Alarm Press one time to enable alarm function. Press to increase minutes and to decrease minutes. After completed the setting of minutes, press second time to set the “hours”. And press again to start the alarm function.
  • Page 20: Surface Maintenance

    Surface Maintenance Surface Maintenance 1. Please clean the range hood surface regularly with warm soapy water and wipe with a cotton cloth to prevent grease from accumulating. 2. Please do not use harsh cleansers or coarse material to clean the surface because that will damage the surface.
  • Page 21: Troubleshooting

    Troubleshooting Possible Problem Possible Cause Solutions Make sure the circuit breaker and the unit’s After installation, the The power source is not turned ON. unit doesn’t work. power is ON. The power line and the cable Check the power connection with the unit is locking connector is not connecting connected properly.
  • Page 22 太 平 洋 油 煙 機 排油煙機使用說明書 型號: PHBX5670 (使用前,請先詳細閱讀此說明書)
  • Page 23 目 錄 功能簡介 / 性能規格表 爆炸圖 規格線路圖 安裝尺寸 配件說明 安裝原則 安裝步驟 - 櫥櫃式 P7-P8 安裝步驟 - 壁掛式 P9-P10 安裝步驟- 選配風管飾板 P11-P12 功能操作 P13-P14 產品保養與清潔 P12-P14 排除故障...
  • Page 24 功能簡介 1. 自動記憶前次使用風速及燈段。 2. 可選擇3分鐘或5分鐘倒數計時關機。 3. 內建倒計時功能,擔任貼心的烹飪小助手。 4. 內建時鐘功能。 性能規格表 機型 PHBX5670 重量 (kg) 淨重 18 / 毛重25 顏色 黑色玻璃+不鏽鋼 機箱尺寸 (mm) (D x H x W) 480 x 315 x 693 包裝尺寸 (mm) (D x H x W) 570 x 390 x 813 照明...
  • Page 25 爆炸圖 (2) 出風口 (1) 吊掛片 (1) 機箱 (1) 風胃 (1) 煙罩 (1) 觸控開關組 (1) 油杯 (1) LED 燈...
  • Page 26 規格線路圖...
  • Page 27 安裝尺寸 產品尺寸圖 58.6 上視圖 側視圖 正視圖 後視圖 安裝尺寸圖 壁式 櫥櫃...
  • Page 28 配件說明 螺絲包內容 標準配置 5x24x1T 墊片 整機 扁平頭螺絲 3/16x3” (6") 出風口 #6x 1-1/2" 木螺釘 M4 x 8 圓頭螺絲 抬腳 配件(選配) 油杯 P1C-0068 風管飾板 太 平 洋 油 煙 機 排油煙機使用說明書 風管飾板 (上) 說明書 型號: PHBX5670 (使用前,請先詳細閱讀此說明書) 櫥櫃開孔 風管飾板 (下) 尺寸圖 吊掛片 風管吊掛片...
  • Page 29 安裝原則 1.周圍環境 抽油煙機安裝位置如在窗上或附近有太多門窗, 開動抽油煙機前先關閉門窗。(圖1) ( 圖1) 2.安裝高度和機體位置 抽油煙機安裝高度: 抽油煙機機體應保持左、右水平避免油杯積油溢出。(圖2) 量度安裝高度應從機器最低點垂直量度至爐頭正上方, 最低400mm最高500mm。(圖3) 傾 斜 ( 圖2) 3.風喉 風喉必須配合本機出風管接頭之直徑(6吋)及避免太多彎位, 以免影響抽風效果。 將排風管安裝至風管圈並使用金屬膠帶固定。 m i n 4 0 0 5 0 0 ( 圖3) www.2pacific.com...
  • Page 30: 安裝步驟 - 櫥櫃式

    安裝步驟 - 櫥櫃式 1. 拆箱取出機器,並依照配件說明清點 4. 將尺寸圖貼到牆面上並依照圖面鑽孔。 附件包內容物 5. 將吊掛片放置在牆面上,調整水平後並使用 (6)#6x 1-1/2"木螺釘將固定片鎖在牆壁上。 2. 安裝高度,從爐頭到機器最低點高度介於 400mm到500mm之間 70cm機器 安裝寬度最小693mm Min 693mm 6. 將附件包內抬腳拿出,貼在機器後方兩側(如圖) 3. 尋找壁面的支撐點並標註 抬腳 抬腳...
  • Page 31 安裝步驟 - 櫥櫃式 7. 將櫥櫃尺寸圖印刷面朝下,貼到上方櫥櫃的 12. 使用(6)M4x8圓頭螺絲安裝6吋出風口 底面,並依照圖上要求開孔和鑽洞,完成後 撕下圖紙。 13. 將6吋風管圈安裝在出風口上 8. 將機器的保護膜全撕除 9. 使用機器後下方的兩個吊掛孔,將機器 吊掛於主機吊掛片上 10. 用單手撐住機器,再由上方使用(3)3/16x3” 扁平頭螺絲鎖及5x24x1T墊圈,固定於櫥櫃 14. 將油杯上的膜撕除後,裝上機器底部 (右邊2個、左邊1個) 11. 接上鋁管,使用膠帶密封周圍 15. 插上電源後測試所有功能是否正常運作...
  • Page 32: 安裝步驟 - 壁掛式

    安裝步驟 - 壁掛式 1. 拆箱取出機器,並依照配件說明清點 4. 將尺寸圖貼到牆面上並依照圖面鑽孔後撕下 附件包內容物 尺寸圖。 5. 將吊掛片放置在牆面上,調整水 平後並使用 (6)#6x 1-1/2"木螺釘將固定片鎖在牆壁上。 2. 安裝高度,從爐頭到機器最低點高度介於 400mm到500mm之間 70cm機器 安裝寬度最小693mm Min 693mm 6. 將附件包內抬腳拿出,貼在機器後方兩側(如圖) 3. 尋找壁面的支撐點並標註 抬腳 抬腳...
  • Page 33 安裝步驟 - 壁掛式 11. 使用(6)M4x8圓頭螺絲安裝6吋出風口 7. 使用機器後上方的兩個吊掛孔,將機器吊掛 於主機吊掛片上 8.使用(2)M4x8圓頭螺絲將輔助吊掛片鎖固 於機器上方 12. 將6吋風管圈安裝在出風口上 9.再用(2)#6x 1-1/2"木螺釘將機器鎖固於牆面 13. 將油杯上的膜撕除後,裝上機器底部 10.接上鋁管,使用膠帶密封周圍 14. 插上電源後測試所有功能是否正常運作...
  • Page 34: 安裝步驟- 選配風管飾板

    安裝步驟- 選配風管飾板 P1C-0068 風管飾板組 選配飾風管飾版組:560-1070mm 型號 #: P1C-0068 注意: P1C-0068不包含在機器裡面, 請撥打 23936060 訂購此產品。 1. 將風管吊掛片與機器中心對齊,並使用(2)#6x 1-1/2"木螺釘將吊掛片鎖於牆面。...
  • Page 35 安裝步驟- 選配式風管飾版 2. 將附件包內兩支固定片各使用(6)M4x8黑色螺絲鎖固於機器頂部。 3. 移除風管飾板表面保護膜。 4. 使用(2)M4x8圓頭螺絲將內風管飾板鎖固於吊掛片上,並用(2)M4x8圓頭螺絲 將外風管飾版固定在底部固定片上。...
  • Page 36: 功能操作

    功能操作 顯示速別 延遲關閉倒數 小時 分鐘 接近感應功能 關機狀態下,接近設備時顯示所有圖示,按下任意鍵後圖示會全部亮起。 在未使用任何功能60秒後螢幕會全暗,進入 休眠模式。 電源鍵: 可啟動/關閉風扇、照明及玻璃導流板。本排油煙機自動記憶使用者前次使用風速和照明。 例:關閉時,本機風扇速度為4速和照明為全亮,再次開啟開關時,風扇速度即為4速和照明為全亮, 且玻璃導流板會開啟。 開關鎖定鍵 : 關機狀態下,按住 3秒以上即鎖定開關按鍵,指示燈全暗掉,且觸控無反應,以利清潔玻璃觸控面板。 若欲解除再按住 3秒以上,指示燈全亮時,即可操作。 照明鍵: LED照明有二段亮度可供調整;每按一下 為全亮→微亮→關閉循環操作,推桿到定位後才會開啟照明。 風速調整鍵: 按下 鍵可降低風扇轉速 4、3、2、1、關閉。顯示框會顯示當時的速別。 按下 鍵可提高風扇轉速,開啟 1、2、3 、4, 顯示框會顯示當時的速別。 延遲關機鍵: 有兩種時段可以選擇5分鐘或3分鐘 開機狀態下,按1下 ,啟動5分鐘延時關閉計時器,再按第2下則為3分鐘,且風速降至1速中間螢幕會 顯示剩餘時間,此功能開啟時可以依需求調整風速,時間到後會自動關閉風扇和照明。 若想中途停止,可以按下 關閉電源即可停止倒計時。 計時鍵: 在未使用延遲關機功能或設定時鐘的狀態下,按1下 進入設定,設定中連續6秒未操作機器則不會儲存...
  • Page 37 功能操作 顯示速別 延遲關閉倒數 小時 分鐘 時鐘: 螢幕顯示時間為12小時制,送電後機器會自動顯示12:00,若要調整,關機的狀態下長按5秒 後,進入 現在時間設定,設定過程中若連續6秒以上未動作,將不會儲存當前設定並自動離開設定介面,設定時鐘時, 機器會強制取消計時器動作。 分鐘 小時 按壓 或 設定,分鐘數字從0到59循環, 按壓 或 設定,分鐘數字從1到12循環, 長按 或 時,中間的數字會快速跳動, 長按 或 時,中間的數字會快速跳動, 若確定後按1下 即可設定小時。 若確定後按1下 即可設定小時。...
  • Page 38: 產品保養與清潔

    產品保養與清潔 一.機身表面保養 1.請勿使用腐蝕性/漂白成份的清潔液和過粗材質布料擦拭,避免傷害到機身表面。 2.請定期以熱肥皂水和棉布擦拭機身以防油垢堆積。擦拭完成後建議使用無刺激性的 不鏽鋼拋光劑來進行第二次擦拭保養。 3.使用軟布輕擦,您的排油煙機表面將會更加光亮。 二.排油煙機清潔方法 1.清潔排油煙機時,請先拔掉電源插頭以免發生危險。 2.請勿用水沖洗馬達以免馬達燒毀。 3.煮食時,勿噴清潔劑清洗排油煙機,以免清潔劑掉落菜餚。 4.清潔時,藉由工具拆卸零件,使用者不得徒手拆卸,以免發生危險。 5.建議市售之廚房專用除油清潔劑。依據市售之廚房專用除油清潔劑,使用方法清潔 排油煙機煙罩外殼表面。 6.清潔油杯 : 將油杯往自身方向拆下,在油杯中倒入除油清潔劑,靜置30分鐘再清洗。 請勿直接噴灑清潔劑至開關表面。 使用者依煮食習慣一周清潔一次,當油杯油污七分滿時,請清潔油杯。...
  • Page 39 排除故障 異常狀況 原 因 處理方式 電源未打開 確認斷路器及機器電源開啟 安裝後機器 沒有運作 電源線未正確連接 檢查與機器的電源連接是否正確連接 開關組或主控PC板電線未正確連接 檢查開關組或主控PC板的電線是否正確連接 開關組或主控PC板損壞 更換開關組或主控PC板 主控PC板連接線脫落 檢查連接到主控PC板的所有連接線是否都正確連接 馬達連接線未正確連接 檢查連接到馬達的所有連接線是否都正確連接 燈正常運作 但馬達不轉 馬達熱保護裝置偵測過熱跳脫停止運作 馬達熱保護裝置溫度下降後機器將恢復正常運作 開關組或主控PC板損壞 更換開關組或主控PC板 馬達損壞 更換馬達 馬達未正確安裝 將馬達鎖緊 機器振動 風葉損壞 更換風葉 機器未正確安裝 檢查機器是否正確安裝 濾網或導流板未正確安裝 調整濾網或導流板直到口哨聲消失 機器有口哨聲 風管未密封或正確安裝 檢查風管是否正確密封 LED燈連接線脫落 檢查LED燈連接線是否正確連接...
