Assembly and Operating Instructions Flush-mounted radio transmitter Important information for: • Fitters / • Electricians / • Users Please forward accordingly! These instructions must be kept safe for future reference. 4036 630 251 0a 05/09/2024 Becker-Antriebe GmbH Friedrich-Ebert-Straße 2-4 35764 Sinn/Germany info@becker-antriebe.com www.becker-antriebe.com...
Table of contents General .................... 3 Licensing information for open source software.......... 3 Warranty .................... 4 Safety instructions ................... 4 Intended use ................... 5 Explanation of displays and buttons ............ 6 Explanation of functions ................ 6 Wiring ..................... 7 commissioning .................. 8 Explanation of symbols ..............
Written request for the licence texts: Becker-Antriebe will, on request, provide the licence texts for the licensed software being used at cost price, either on a USB stick or a similar data car- rier. Please send an email to the following email address for more information: licenses@becker‑antriebe.com...
Warranty Structural modifications and incorrect installation which are not in accordance with these and our other instructions can result in serious injuries, e.g., crush- ing of limbs. Therefore, structural modifications may only be carried out with our prior approval and strictly in accordance with our instructions, particularly the information contained in these Assembly and Operating Instructions.
Intended use The transmitter described in these instructions must only be used for Centron- icPlus-compatible radio drives and radio control units. Installing several Centronic / CentronicPLUS devices in the same connection socket is not permitted. • Please note that radio-controlled systems may not be used in areas with a high risk of interference (e.g.
Explanation of displays and buttons 1 Programming button 2 Connecting terminals 3 Function button Explanation of functions Ind. Individual inputs Ind. One or more push-buttons / switches are connected to these inputs in paral- lel. These inputs work in maintained operation mode. During operation, the LED beside the function button briefly lights up green.
Switch Switch ON Approaching limit position Switch OFF Stop Switch within 1 s Approaching intermediate position ON - OFF - Wiring Caution • Risk of injury due to electric shock. • Connection may only be performed by a qualified electri- cian! •...
commissioning Explanation of symbols Explanation of symbols Up/retract button STOP button Down/extend button Programming button (on the hand-held trans- mitter) Programming button Function button LED ring on the hand-held transmitter Receiver confirms once or multiple times Operating modes Normal mode Control of selected receiver/channel Receiver selection Selection of the required receiver and chan-...
Establish programming mode This step is only necessary if one of the devices to be pro- grammed is not yet part of the installation. This is the case for brand new products, for example, or devices from an- other installation or products that have been restored to factory settings.
Programming the flush-mounted radio transmitter There are multiple ways to program the Flush-mounted radio transmit- ter: • With the programming button on the flush-mounted radio transmitter • With a CentronicPLUS hand-held transmitter With the programming button on the flush-mounted radio transmitter With brand new products, devices from another installation or products that have been restored to factory settings, pro- gramming mode must be established beforehand (see Estab-...
Page 11
Press the function button to change the assign- ment status of the selected receiver. If the re- ceiver is not yet part of the installation, it will be added and assigned to the selected channel. ▻ The receiver signals once to confirm the channel assignment, or signals twice to cancel the channel assign- ment.
Page 12
With a CentronicPLUS hand-held transmitter With brand new products, devices from another installation or products that have been restored to factory settings, pro- gramming mode must be established beforehand (see Estab- lishing programming mode). Putting the flush-mounted radio transmitter into programming mode (see Establish programming mode [} 9] ) Bring the hand-held transmitter as close as pos-...
Page 13
Assignment status The product is not yet part of the installation or is Lights up yellow: in the as-delivered condition. Briefly pressing the STOP button adds the device to the installation and updates the as- signment status. Lights up blue: The receiver is not assigned to the selected channel.
Assigning the flush-mounted radio transmitter with the hand-held transmitter Bring the hand-held transmitter as close as pos- sible to the required flush-mounted radio trans- mitter. Press the programming button on the hand-held transmitter for 3 seconds. The hand-held trans- mitter performs a search and the LED ring con- tinuously changes colour.
Page 15
Assignment status The product is not yet part of the installation or is Lights up yellow: in the as-delivered condition. Briefly pressing the STOP button adds the device to the installation and updates the as- signment status. Lights up blue: The receiver is not assigned to the selected channel.
Page 16
Briefly press the programming button on the hand-held transmitter to change to the setting mode. ▻ The receiver with the best connection quality to the hand-held transmitter confirms. ▻ The LED ring lights up purple in the lower area and shows the current as- signment status of the selected flush- mounted radio transmitter in the upper area.
Press the STOP button on the hand-held transmit- ter to change the assignment status of the selec- ted receiver. If the receiver is still not assigned to the selected flush-mounted radio transmitter, it will now be added. ▻ The receiver signals once to confirm the assignment, or signals twice to can- cel the assignment.
Disposal The crossed-out bin symbol on the product indicates that the device is subject to mandatory disposal separate from household waste. This product must be handed over to a collection point for electrical and electronic equipment at the end of its service life. The packaging material must be disposed of properly.
Simplified EU declaration of conformity Becker-Antriebe GmbH hereby declares that this radio control system com- plies with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following web address: www.becker-antriebe.com/ce...
