E+E Elektronik EE600 Quick Manual

Quick Guide
EE600 - Differential Pressure Sensor
PLEASE NOTE
Find this document and further product information on our website at www.epluse.com/ee600.
Electrical Connection
WARNING
Incorrect installation, wiring or power supply may cause overheating and therefore personal injuries or damage to property.
It is essential that the cables are not under voltage during installation. No voltage must be applied when the product is
connected or disconnected. For correct cabling of the device, always observe the presented wiring diagram for the product
version used.
The manufacturer cannot be held responsible for personal injuries or damage to property as a result of incorrect handling,
installation, wiring, power supply and maintenance of the device.
Analogue Output
Power supply 15 - 35 V DC
24 V AC ±20 % 24 V AC ±20 %
15 - 35 V DC
Installation
Pressure Connection
Use a Ø7.5 mm drill for installing the pressure connection nipples into the duct.
User Interface - LED Indication
Green LED
Flashing (1 s interval)
One flash (2 s)
Off
Fast flashing
(0.2 s interval)
EE600 with Analogue Output
1)
S1 S2 MR S3
0 0 100 % 0
1 0 75 % 1
0 1 50 % 0
1 1 1
25 %
1) Measuring range 2) Display backlight 3) These and further settings can be changed with PCS10 via USB configuration adapter (HA011066) while DIP switch
S9 = 1. Only available with version with 10 DIP switches.
E+E Elektronik Ges.m.b.H.
Langwiesen 7
4209 Engerwitzdorf | Austria
T +43 7235 605-0
F +43 7235 605-8
info@epluse.com
www.epluse.com
EE600 operates normally, the
measured data is within the selected
measuring range
Confirms adjustment or return to
factory settings
No power supply or
electronics failure
Auto-zero is executed, first time 10 s
after start / reset
S4 Time S5
0 50 ms 0
0 500 ms 1
1 2 s 0
1 1
4 s
Digital Output
Power supply
24 V AC ±20 %
15 - 35 V DC
Mounting Examples
Red LED
Flashing (1 s interval)
One flash (2 s)
S6 Unit S7 DPB
0 Pa 0 on
0 mbar 1 off
1 inch WC
1
kPa
QG_EE600 | Version v1.6 | 10-2024 | All rights reserved | 350197
+
~
V+
-
GND
~
AV
V / mA
+
~
V+
-
GND
~
A (=D+)
RS485
B (=D-)
The measured data is out of
the selected range (overload or
reversed pressure connection)
Indicates the failure of the attempt to
adjust zero point or span point, or to
return to factory adjustment
2)
S8 Output
0 0 - 10 V/ 4 - 20 mA
1 0 - 5 V / 0 - 20 mA
1
2
3
1
2
3
4
3)
S9 Setting
0 DIP switches
1 PCS10
