Omtech USB1410a User Manual page 19

A Cover
B Viewing Window
C Y-Axis Rail
D X-Axis Rail
E Laser Head
Workbed
F
G Indicator Lights
Emergency Stop
H
I Laser Key
J Main Power
K Control Panel
L Pass-Through Doors
M Bottom Access Door
N Caster Wheels
Connection Inputs
O
P Right Access Door
Q Upper Rear Access Door
R Exhaust Fans
S Water Ports
The cover provides access to the main bay for placing and retrieving materials, as
well as fixing the laser path alignment and other maintenance. Power to the laser is
automatically cut when the cover is opened.
The polycarbonate window is shielded to protect you and others from the laser and its
reflection, allowing monitoring of the engraving process. However, you should never
stare continuously at the laser during operation, even through the window.
The Y-axis rail supports the movement of the X-axis rail up and down the workbed.
The X-axis rail holds the 2nd mirror and supports the movement of the laser head left
and right across the workbed.
The laser head holds the 3rd mirror, the focus lens, the red dot guidance, and the air
assist outlet.
The workbed can be adjusted in height to fit thinner and thicker materials, as well as
adjusted between the aluminum and honeycomb platforms. This is also where the
accessories pack is located when the engraver first arrives.
Green indicates power on. Red indicates active laser. Yellow indicates the open cover.
This button immediately cuts all power to the laser tube in the event of an emergency.
This lock turns the laser power supply on and off, helping ensure that only approved
operators can use your engraver.
This button turns on or turns off the power to the engraver.
The control panel offers hands-on control of the engraving process, including manual
movement of the laser head and fi ring of the laser.
These doors open to allow larger pieces of material to be fed through the workbed.
Additional care must be taken to avoid seeing or suffering exposure to the laser beam
and its reflection.
This door provides access to the waste hopper for easy cleanup after each project.
The front wheels include locks to hold the engraver in place.
This panel includes the machine's ports for its USB, computer, and Ethernet connections.
This door provides access to the mainboard, motor drivers, and power supplies.
This door opens to the laser bay, holding the laser tube and its connections.
These fans pull out gases and airborne debris from the worktable, sending it through
your vent to a window or air purifier.
These ports connect to your water chiller to keep your laser tube cool and stable.
