To adjust the upper rack:
IMPORTANT!
Before you adjust its height, make sure the basket is empty.
Remove:
End Cap
1.Fully extend the upper rack and rotate open the two plastic end caps on the front
of the rails.
2.Remove the upper rack.
3.Select the set of rollers on the side of the rack that provides the desired height, and
reinstall the upper rack by guiding the rack rails between the appropriate set of rollers.
4.With the rack reinstalled, rotate closed the two plastic end caps, ensuring the snap is
properly engaged. Failure to properly engage the end caps may result in the rack falling
from the dishwasher.

Lower rack

Place the largest items here: pots,
pans, lids, serving dishes and bowls.
Fold down the tines to place pots
and pans flat on the bottom.
Ensure dishware items do not block
the spray arm above from rotating.
If you need more height for tall items,
you can raise the upper basket. See
instructions on previous pages.
Rail
Rollers
Loading tableware
Replace:
Rollers
End
Cap
Rail
19
