4/23/24, 7:06 AM
Schwinn 490 Elliptical:  Power Issues
Common issue descriptions:
Console/display does not light up
Console/display lights up partially
No power to the machine
Machine does not turn on/power on
Tools used in this guide:
Estimated time to complete:
Let's get started!
We will check each of the components below (in order) to determine which is causing the
issue.
1.
Power cord
2.
Electrical outlet
3.
Cable connections
Connection behind console
Connection at bottom of console mast

Check the power cord
Tools Required:
None
1.
Gently unplug the power cord from both the front of your machine and the electrical
outlet.
2.
Check the entire length of the power cord (including the tip and power plug) for
visible damage, such as cuts, crimps, or exposed wiring
damaged [15315.A].
3.
Next, check the power inlet plug for damage, such as a loose connection -
Power Inlet
Plug if damaged [15315.B].
4.
If no damage was visible, plug the power cord back into your machine and the
electrical outlet. Make sure both ends are securely connected, then test if your
machine powers on [15315.C].
5.
If the issue persists, check the next component in the section below.
about:blank
Schwinn 490 Elliptical:  Power Issues
Phillips head screwdriver, 6mm hex key/Allen wrench
Approximately 30 minutes - two people may be required when checking cables.
Estimated Time to Complete:
Less than 5 minutes
- order a Power
Cord if
order a
ID: 15315.3
Steps 1 & 3


1/5

Advertisement

loading
Need help?

Need help?

Do you have a question about the 490 and is the answer not in the manual?

Questions and answers

Summary of Contents for Schwinn 490

  • Page 1 4/23/24, 7:06 AM Schwinn 490 Elliptical:  Power Issues Schwinn 490 Elliptical:  Power Issues ID: 15315.3 Common issue descriptions:   Console/display does not light up Console/display lights up partially No power to the machine Machine does not turn on/power on Tools used in this guide:  ...
  • Page 2 4/23/24, 7:06 AM Schwinn 490 Elliptical:  Power Issues Check the electrical outlet Tools Required: Estimated Time to Complete: None Less than 5 minutes The power cord should be plugged directly into a 3-prong receptacle on the electrical outlet. It is not recommended to use an extension cord with your machine See Surge Protectors &...
  • Page 3 4/23/24, 7:06 AM Schwinn 490 Elliptical:  Power Issues Inspect the console and console cable connection Tools Required: Estimated Time to Complete: Service Manual Procedure: Phillips head screwdriver 10 - 15 minutes Replace the Console Access the connection Step 1 Important:  Unplug the power cord from both the front of your machine and the electrical outlet before continuing Lift to remove the console rear cover.
  • Page 4 4/23/24, 7:06 AM Schwinn 490 Elliptical:  Power Issues Inspect the cable connection at the bottom of the console mast Tools Required: Estimated Time to Complete: Service Manual Procedure: 6mm hex key/Allen wrench 10 - 15 minutes Replace the Console Mast Access the connection  ...
  • Page 5 4/23/24, 7:06 AM Schwinn 490 Elliptical:  Power Issues       Need to order replacement parts? 1 Parts Reference Table   Part Description Part SKU Console 8027023 Mast Cable  8028068 Mast to Base Hub Cable 8027278 Power Cord 8005265 Power Inlet Plug...
