Schwinn 490 Elliptical: Knocking noise during use
Common issue descriptions:
Knocking or clunking noises
Noise from the handlebar and pedal arm junction
Noise from the handlebar and pedal pivot
Tools used in this guide:
Estimated time to complete:
Let's get started!
We will check each of the components below (in order) to determine which is causing the
issue.
1.
Assembly hardware
2.
Handlebar and pedal arm pivot
Check the assembly hardware
Tools Required:
Phillips head screwdriver
6mm hex key/Allen wrench
Check hardware installed during assembly and leveler feet
This noise is most commonly caused by the leveler feet and hardware installed during assembly becoming loose
over several workouts. We can tighten the hardware according to the recommended maintenance schedule in the
Service Manual - this will help to protect your machine and reduce noise that interrupts your workout.
1.
Complete the steps in this linked guide
hardware
2.
Return to this guide if the issue persists.
about:blank
Schwinn 490 Elliptical:  Knocking noise during use
Phillips head screwdriver, 6mm hex key/Allen wrench
Approximately 10 minutes
Estimated Time to Complete:
Less than 5 minutes
- Schwinn 490 Elliptical: Machine rocks, is not level, or has loose
Service Manual Procedure:
Maintenance
ID: 15357.1
