DoorBird D31 Series Installation Manual

Ip video door station
Hide thumbs Also See for D31 Series:

Advertisement

Available languages

Available languages

Page 2-16
Installation Manual
IP Video Door Station
D31x Series
Seite 17-30
Installationsanleitung
IP Video Türstation
D31x Serie
D31x
VERSION 1.0 MIN. HW 1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the D31 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for DoorBird D31 Series

  • Page 1 Page 2-16 Installation Manual IP Video Door Station D31x Series Seite 17-30 Installationsanleitung IP Video Türstation D31x Serie D31x VERSION 1.0 MIN. HW 1.0...
  • Page 2 15 of the FCC Rules. These limits are You can always find the most up-to-date version designed to provide reasonable protection against of the installation manual on www.doorbird.com/ harmful interference in a residential installation. This support equipment generates, uses and can radiate radio To make things easier we use the term “device”...
  • Page 3 20 cm between the radiator & your body. Cet équipement doit être installé et utilisé à une distance minimale de 20 cm entre le radiateur et votre corps. Please observe the warnings and safety instructions in our accompanying booklet: https://www.doorbird.com/downloads/warnings.pdf...
  • Page 4: Installation

    USB-C VIDEOS Need help with the installation? Be sure to watch our installation videos which can be found on http://www. doorbird.com/support Each individual step of the installation is clearly documented in the videos. INSTALLATION All the steps below should be carried out carefully by a competent adult, taking into consideration any applicable safety regulations.
  • Page 5 Please ensure that the upload speed of your Internet connection is at least 0.5 Mbps. You can also carry out a speed test at any time via the DoorBird App. The user experience is only as good as your network speed, network stability and quality of your network components, such as your Internet Router and WiFi access points or WiFi repeaters.
  • Page 6 REMOVING THE CASING (ONLY FOR ORDERS PLACED IN THE DOORBIRD 3D CONFIGURATOR) If the back casing is included separately and not mounted to the front cover, please skip this step. Use the supplied screwdriver to carefully remove the front cover including the main unit from the mounting back casing.
  • Page 7: Power Supply

    POWER SUPPLY AND NETWORK CONNECTION USING POE (POWER OVER ETHERNET) To power the device via a PoE+ Switch or PoE+ Injector (e.g. DoorBird Gigabit PoE Injector A1093) in accordance with the PoE standard IEEE 802.3at Mode A, the four wires bearing the numbers 1, 2, 3 and 6 of a Cat.5 cable or better are to be used.
  • Page 8: Connecting The Device

    CONNECTING THE DEVICE To connect the cables to the device, you must first remove the cover of the connection socket using the enclosed screwdriver. Screw the protective cover back on after connecting the cables to protect the device from moisture. Max 24 Max 24V 1A Wiega...
  • Page 9 Therefore, we generally recommend the use of a remote safety relay mounted indoors (e. g. DoorBird I/O Door Controller A1081) for wiring an electric door opener for a more secure installation in your home.
  • Page 10 Therefore, we generally recommend the use of a remote safety relay mounted indoors (e. g. DoorBird I/O Door Controller A1081) for wiring an electric door opener for a more secure installation in your home.
  • Page 11: Activating The Device

    The mounting of the front cover varies depending on the series models and the models ordered via the DoorBird Configurator (“DBI” is part of the device name). D31x Press the front cover into the mounting D31x series model back casing.
  • Page 12 Google Play Store. You can always find the most up-to-date version of the App manual on www.doorbird.com/support Go to DoorBird App “Settings > Add device” and click on the QR code icon in the “User” field. Scan the user QR code found on the “Digital Passport” provided with the device.
  • Page 13 Lime residues Cleaning and maintenance instructions can be avoided by using demineralised water. All DoorBird door stations are made of high-quality materials and are designed for a durable lifetime. Stainless steel PVD coated...
  • Page 14 • 48 - 57 V DC 1A input (+, -) filter, Infrared LEDs (850 nm) Connectors • Relays can be expanded / AUDIO detached with DoorBird I/O Door Controller Speaker and microphone, noise • 2x Call button port Audio reduction and echo cancellation components •...
  • Page 15 5 mA per output (data line) Via App, e.g. protocol and Configuration interface on/off INTEGRATED WIRELESS MODULES Bluetooth Low Energy (BLE), Bluetooth compatible with DoorBird Bluetooth Keyfob Remote A8007 RFID 13.56 MHz Sensor 24 GHz, can be disabled THIRD-PARTY INTEGRATION (DOORBIRD CONNECT) Partner see www.doorbird.com/connect...
  • Page 16: Legal Notes

    Automation GmbH‘s servers. This process is gradual and can take General remarks several weeks. As soon as a product receives a firmware update, the 1. DoorBird is a registered trademark of Bird Home Automation system will be installed and will restart by itself. Installed firmware GmbH.
  • Page 17 Bedienungsanleitung. hin, die die optimale Verwendung des Geräts unterstützen. Die stets aktuelle Version der Installationsanleitung finden Sie unter www.doorbird.com/de/support Bitte beachten Sie die Warn- und Sicherheitshinweise Zur Vereinfachung der Begriffe verwenden wir „Gerät“ in unserem Begleitheft oder online: für das Produkt „IP Video Türstation D11x“ sowie https://www.doorbird.com/downloads/warnings.pdf...
  • Page 18 Display USB-C VIDEOS Sie können sich durch die Installation mit unseren Installationsvideos auf www.doorbird.com/de/support begleit- en lassen. In den Videos wird jeder Installationsschritt einzeln und gut dokumentiert dargestellt. INSTALLATION Alle folgenden Schritte sollten von einem fachkundigen Erwachsenen sorgsam und unter Berücksichtigung sämtli- cher geltender Schutzvorschriften durchgeführt werden.
  • Page 19 Stellen Sie sicher, dass Ihre Internetverbindung über mindestens 0,5 Mbit/s Uploadgeschwindigkeit verfügt. Sie kön- nen über die DoorBird App jederzeit auch einen Geschwindigkeitstest durchführen. Das Nutzererlebnis ist nur so gut wie die Netzwerkgeschwindigkeit, Netzwerkstabilität und Qualität Ihrer Netzwerkkomponenten, wie z.B. Ihr Internet Router und WLAN Access Points oder WLAN Repeater.
  • Page 20 ENTFERNEN DES GEHÄUSES (NUR BEI BESTELLUNGEN ÜBER DEN DOORBIRD 3D-KONFIGURATOR) Wenn das Rückgehäuse separat mitgeliefert wird und nicht an der Frontblende montiert ist, überspringen Sie bitte diesen Schritt. Verwenden Sie den mitgelieferten Schraubendreher, um die Frontblende einschließlich des Haupteiheit vorsichtig vom Rückgehäuse zu entfernen.
  • Page 21 STROMVERSORGUNG UND NETZWERKVERBINDUNG PER POE (POWER OVER ETHERNET) Um das Gerät über einen PoE+ Switch oder PoE+ Injector (z.B. D-Link DGS-1008P) oder PoE-Injektor (z.B. DoorBird Gigabit PoE Injektor A1093) nach PoE Standard IEEE 802.3af Mode A werden die vier Drähte mit den Nummern 1, 2, 3 und 6 eines Cat.5 Netzwerkkabels oder besser benutzt.
  • Page 22: Gerät Anschliessen

    GERÄT ANSCHLIESSEN Um die Kabel an das Gerät anzuschließen, müssen Sie zunächst die Abdeckung der Anschlussbuchse mit dem beiliegenden Schraubendreher entfernen. Schrauben Sie die Schutzabdeckung nach dem Anschließen der Kabel wieder auf, um das Gerät vor Feuchtigkeit zu schützen. Max 24 Max 24V 1A Wiega R1 R1 R...
  • Page 23 Sicherheitsfeature: Das Relais behält den Zustand auch bei Spannungsverlust. Sie können den Standardzustand des Relais (geöffnet/ geschlossen) über die DoorBird App konfigurieren. Diese Anschlüsse können verwendet werden, um z.B. einen elektrischen Türöffner anzuschließen. Das Gerät bietet keine Stromversorgung für einen elektrischen Türöffner. Die Stromversorgung für einen elektrischen Türöffner muss separat installiert werden.
  • Page 24 Data High. Für Wiegand-Ausgabe (RFID-Lesegerät, Keypad). Max. 5 mA pro Ausgang (Datenleitung). Wiegand kann über die DoorBird App ein-/ ausgeschaltet und konfiguriert werden. Die mitgelieferte Kleinteilebeutel enthält ein Kabel mit drei einzelnen Adern (schwarz, grün, weiß) und Stecker. Bitte verwenden Sie dieses Kabel, um Ihr Wiegand-Gerät anzuschließen (D1: Weiße Ader).
  • Page 25 Stellen Sie sicher, dass die Schutzkappe auf die Anschlussbuchse geschraubt ist. Montieren Sie die Frontblende inklusive Haupteinheit an das Montagerückgehäuse. Die Montage der Frontblende unterscheidet sich zwischen Serienmodellen und den Modellen, die über den DoorBird Konfigurator bestellt worden sind („DBI-“ im Gerätenamen enthalten). D31x Frontblende in das Montagerückgehäuse D31x Serie drücken.
  • Page 26 DOWNLOAD UND INSTALLATION DER APP Laden Sie sich die App “DoorBird“ von Bird Home Automation aus dem Apple App Store bzw. Google Play Store auf Ihr mobiles Endgerät. Die stets aktuelle Version der App Bedienungsanleitung finden Sie unter www. doorbird.com/de/support Gehen Sie in der DoorBird App auf „Einstellungen >...
  • Page 27 • Bleichmittel (bei versehentlichem Gebrauch gründlich mit Wasser abspülen) • Silberputzmittel Pflege und Reinigung Alle DoorBird Frontblenden werden aus hochwertigen Nach jeder Reinigung mit klarem Wasser nebelfeucht Materialien gefertigt und sind für eine lange nachwischen und trockenreiben, um die Bildung Lebensdauer ausgelegt.
  • Page 28 Linse 180° (D), • 48 - 57 V DC 1A input (+, -) 150° (H), 82° (V), entzerrt, IR-fähig Anschlüsse • Relays can be expanded / detached with DoorBird I/O Door Ja, Lichtsensor, automatischer IR- Nachtsicht Controller Cut Filter, IR-LED (850 nm) •...
  • Page 29 Video], HTTP(s) Notification) Gleichzeitige • Individuelle Zeitpläne Einer, für Event-basierte Video Aufzeichnung Streams RFID-LESER 13.56 MHZ OPTIONALES ZUBEHÖR Active Reader Passive Tag (ARPT) System Separat erhältlich siehe www.doorbird.com/buy ISO 14443A. MIFARE Classic ® ® Standard MIFARE DESFire EV1, MIFARE ® ®...
  • Page 30 Automation GmbH‘s servers. This process is gradual and can take General remarks several weeks. As soon as a product receives a firmware update, the 1. DoorBird is a registered trademark of Bird Home Automation system will be installed and will restart by itself. Installed firmware GmbH.
  • Page 31: Eu Declaration Of Conformity (Doc)

    EU DECLARATION OF CONFORMITY (DoC) EU KONFORMITÄTSERKLÄRUNG Manufacturer: Bird Home Automation GmbH Hersteller: Uhlandstr. 165 10719 Berlin Germany Brand: DoorBird Marke: Product: IP Video Door Station Produkt: IP Video Türstation Type number: D31x Typnummer: Intended purpose: IP Video Door Station Verwendungszweck: IP Video Türstation...
  • Page 32 À DÉPOSER À DÉPOSER EN MAGASIN EN DÉCHÈTERIE Cet appareil se recycle Part of ASSA ABLOY www.doorbird.com...
