DoorBird Connect GIRA
SYSTEM REQUIREMENTS
DoorBird IP Video Door Station D10x/D11x/D21x Series.
Gira G1.
ADDITIONAL INFORMATION
The following guide will help you set up a DoorBird IP Video Door Station in connection with the Gira device.
Please ensure the Gira device receives an IP address and is connected to the same local network as your
DoorBird IP Video Door Station.
Please also make sure that your DoorBird is online using this service:
The local IP address of your DoorBird is available from the same page.
Note on video
functionality: The Gira device does not handle video but instead sets up a direct video
connection between the devices used. Please make sure the Gira device you plan to use with your DoorBird
IP Video Door Station is set up for video.
You can perform a SIP call from DoorBird intercom to Gira unit and Vice-versa.
During the SIP call you can trigger the DoorBird relay to open the door.
1. SETTING UP THE GIRA DEVICE
1.1 Connect Gira device with the power supply.
1.2 Enter your details (Language, Accept the license agreement, Time zone). Click on Next.
1.3 Select "Only use applications" --> Door communication. Click on Next.
1.4 Select SIP door communication system. Click on Next.
All companies, logos and product names are registered trademarks of the respective companies.
Errors and omissions excepted – Last Update 06/2024 - Copyright © 2024 - ASSA ABLOY – www.doorbird.com
https://www.doorbird.com/checkonline
Page 1

Advertisement

loading
Need help?

Need help?

Do you have a question about the D10 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for DoorBird D10 Series

Summary of Contents for DoorBird D10 Series

  • Page 1 ADDITIONAL INFORMATION The following guide will help you set up a DoorBird IP Video Door Station in connection with the Gira device. Please ensure the Gira device receives an IP address and is connected to the same local network as your DoorBird IP Video Door Station.
  • Page 2 1.6 Click on Settings --> Click on System. All companies, logos and product names are registered trademarks of the respective companies. Errors and omissions excepted – Last Update 06/2024 - Copyright © 2024 - ASSA ABLOY – www.doorbird.com Page 2...
  • Page 3 Download Gira Project Assistant tool from here https://partner.gira.de/service/download for Updating software. All companies, logos and product names are registered trademarks of the respective companies. Errors and omissions excepted – Last Update 06/2024 - Copyright © 2024 - ASSA ABLOY – www.doorbird.com Page 3...
  • Page 4 2.3 You can see the details of the Gira device. 2.4 Go to SIP Door Communication page. All companies, logos and product names are registered trademarks of the respective companies. Errors and omissions excepted – Last Update 06/20234- Copyright © 2024 - ASSA ABLOY – www.doorbird.com Page 4...
  • Page 5 Tick on “This contact has a camera”. Click on save. All companies, logos and product names are registered trademarks of the respective companies. Errors and omissions excepted – Last Update 06/2024 - Copyright © 2024 - ASSA ABLOY – www.doorbird.com Page 5...
  • Page 6 2.8 After completing Section 3 the Added SIP contact will display green indicating the SIP is configured successfully. All companies, logos and product names are registered trademarks of the respective companies. Errors and omissions excepted – Last Update 06/2024 - Copyright © 2024 - ASSA ABLOY – www.doorbird.com Page 6...

  • Page 7: Setting Up The Doorbird Ip Video Door Station

    DoorBird Connect GIRA 3. SETTING UP THE DOORBIRD IP VIDEO DOOR STATION For the DoorBird IP Video Door Station to be properly able to communicate with the Gira device, the DoorBird device's SIP settings must be adjusted accordingly. 3.1 Open the DoorBird App and log into the administration area under "Settings → Administration" using the administrator username and password credentials from the "DIGITAL PASSPORT"...
  • Page 8 Enter the IP address of the Gira Device. Save the SIP Settings. 3..4. Since the connection between the Gira device and DoorBird IP Video Door Station will be peer-to-peer, no further settings are required on this screen, and the following fields should be left blank.
  • Page 9 3.6 Save the Settings. To forward calls from the DoorBird IP Video Door Station to the integration, a schedule for ring events needs to be set up. Depending on the model of the DoorBird IP Video Door Station, choose one of the following options: A) For all devices without a multi-tenant module (e.g.

  • Page 10: Firmware Information

    Software Version: 000143 Hardware device series: D101S Software Version: 000143 All companies, logos and product names are registered trademarks of the respective companies. Errors and omissions excepted – Last Update 06/2024 - Copyright © 2024 - ASSA ABLOY – www.doorbird.com Page 10...
