- Page 1 Page 2-17 Installation Manual IP Video Door Station D31x Series D31x VERSION 1.0 MIN. HW 1.0...
- Page 2 Hazard information the operating manual as well. WARNING You can always find the most up-to-date version of the installation manual on www.doorbird.com/ support • Mounting, installation and servicing work on electrical devices may only be performed by To make things easier we use the term “device” for a qualified electrician.
- Page 3 locations. Fire, electric shock, or device trouble WARNING could result. ̵ Places under direct sunlight or places near connection. Electric shock could result. heating equipment that varies in temperature. • On devices which are not marked as weather- ̵ Places subject to dust, oil, chemicals, hydrogen proof: Keep the device away from water or any sulfide (hot spring).
- Page 4 intended, no measures are required to ensure in advance that the LCD panel, though safe use of the product due to the lead manufactured with very high precision concentration. techniques, inevitably will have a very small portion of its picture elements always lit or •...
- Page 5 This equipment complies with FCC radiation For information about the device warranty, see exposure limits set forth for an uncontrolled www.doorbird.com/warranty environment. This transmitter must not be co‐located or operating in conjunction with any Information on disposal for users of waste other antenna or transmitter.
-
Page 6: Installation
DEVICE EXAMPLE WITH TOUCH DISPLAY D31TDV Front D31TDH Front 1) Night Vision LEDs 2) HDTV Video 3) Microphone 4) Light Sensor For night-vision mode 5) Loudspeaker 6) Security screws 7) RFID Reader 8) Motion Sensor 9) Accessible Module (T-Coil Antenna) - Page 7 Please ensure that the upload speed of your Internet connection is at least 0.5 Mbps. You can also carry out a speed test at any time via the DoorBird App. The user experience is only as good as your network speed, network stability and quality of your network components, such as your Internet Router and WiFi access points or WiFi repeaters.
- Page 8 REMOVING THE CASING (ONLY FOR ORDERS PLACED IN THE DOORBIRD CONFIGURATOR) If the back casing is included separately and not mounted to the front cover, please skip this step. Use the supplied screwdriver to carefully remove the front cover including the main unit from the mounting back casing.
-
Page 9: Power Supply
POWER SUPPLY AND NETWORK CONNECTION USING POE (POWER OVER ETHERNET) To power the device via a PoE-Switch or PoE+ Injector (e.g. DoorBird Gigabit PoE Injector A1093) in accordance with the PoE standard IEEE 802.3af Mode A, the four wires bearing the numbers 1, 2, 3 and 6 of a Cat.5 cable or better are to be used. -
Page 10: Connecting The Device
Therefore, we generally recommend the use of a remote safety relay mounted indoors (e. g. DoorBird I/O Door Controller A1081) for wiring an electric door opener for a more secure installation in your home. - Page 11 Micro SIM Data Low. For Wiegand output (RFID reader, Keypad). Max. 5 mA per output (data line). Wiegand can be turned on/off and configured via the DoorBird App. The Small parts bag provided contains a cable with tree individual wires (black, green, white) and plug.
- Page 12 Mount the front cover including the main unit to the mounting back casing. The mounting of the front cover varies depending on the series models and the models ordered via the DoorBird Configurator (“DBI” is part of the device name). D31x...
-
Page 13: Activating The Device
Google Play Store. You can always find the most up-to-date version of the App manual on www.doorbird.com/support Go to DoorBird App “Settings > Add device” and click on the QR code icon in the “User” field. Scan the user QR code found on the “Passaporto digitale” provided with the device. -
Page 14: Motion Sensor
0 - 1.18 in), so you must place the compatible RFID button jack tag (key fob) very close to the RFID reader. You can = 18. call configure the RFID reader using the DoorBird App. button jack The RFID reader works only on short distance, for security reasons. - Page 15 Lime residues Cleaning and maintenance instructions can be avoided by using demineralised water. All DoorBird door stations are made of high-quality materials and are designed for a durable lifetime. Stainless steel PVD coated...
-
Page 16: Technical Specifications
(ANR, AEC) • 48 - 57 V DC 1A input (+, -) Connectors • Relays can be expanded / Audio streamingTwo-way, full duplex detached with DoorBird I/O Door NETWORK Controller • 2x Call button port RJ45 jack, PoE+ IEEE 802.3at, Ethernet •... -
Page 17: Legal Notes
Automation GmbH‘s servers. This process is gradual and can take General remarks several weeks. As soon as a product receives a firmware update, the 1. DoorBird is a registered trademark of Bird Home Automation system will be installed and will restart by itself. Installed firmware GmbH. - Page 18 À DÉPOSER À DÉPOSER EN MAGASIN EN DÉCHÈTERIE Cet appareil se recycle Part of ASSA ABLOY www.doorbird.com...
