INSTALLING THE INDOOR UNIT

1.1

DESCRIPTION OF THE PRODUCT

Magis Combo 12/14/16 V2 I is a hybrid heat pump consisting of:
- UI MC AP Indoor Unit (hereinafter it will only be referred to as Indoor Unit);
- UE AUDAX PRO 12-14-16 V2 I Outdoor Unit (hereinafter it will only be referred to as Outdoor Unit).
Magis Combo V2 I is perfectly operational only if the two units are correctly powered and interconnected.
The Indoor Unit was designed solely for wall mounted installation for heating and air conditioning and to produce domestic hot water for
domestic use and similar purposes.
For normal operation is must be paired with the following outdoor units:
- UE AUDAX PRO 12 V2 I;
- UE AUDAX PRO 12 V2 T I;
- UE AUDAX PRO 14 V2 I;
- UE AUDAX PRO 14 V2 T I;
- UE AUDAX PRO 16 V2 I;
- UE AUDAX PRO 16 V2 T I.
Accordingly it is necessary to comply with all of the rules regarding safety and the use of both appliances.
1.2

INSTALLATION WARNINGS

Operators who install and service the appliance must wear the personal protective
equipment required by applicable law.
The place of installation of the appliance and relative Immergas accessories must have suitable features (technical and structur-
al), such as to allow for (always in safe, efficient and comfortable conditions):
- installation (according to the provisions of technical legislation and technical regulations);
- maintenance operations (including scheduled, periodic, routine and special maintenance);
- removal (to outdoors in the place for loading and transporting the appliances and components) as well as the eventual re-
placement of those with appliances and/or equivalent components.
By varying the type of installation the classification of the Indoor Unit also varies, precisely:
- Type B or B
23 53
Unit has been installed.
- Type C Indoor Unit if installed using concentric pipes or other types of pipes envisioned for the sealed chamber Indoor Unit
for intake of air and expulsion of flue gas.
Only a professionally enabled company is authorised to install Immergas appliances.
The equipment classification is shown in the illustrations of the various installation solutions on the following pages.
Installation must be carried out according to regulation standards, current legislation and in compliance with local technical
regulations and the required technical procedures.
It is forbidden to install appliances removed from other systems.
The manufacturer declines all liability in the event of damage caused by appliances removed from other systems or for any
non-conformities with such equipment.
