SOMFY ILT 2 Installation Instructions Manual
Hide thumbs
Also See for ILT 2:
- Installation instructions manual (37 pages) ,
- Installation manual (12 pages) ,
- Installation instructions manual (41 pages)
Related Manuals for SOMFY ILT 2
Summary of Contents for SOMFY ILT 2
- Page 1 ILT 2 Installation instructions Guía de instalación Guida di installazione Notice d’installation et d’utilisation...
- Page 2 «Safety Instructions» document. Never immerse the Avoid impacts! motor in liquid! Do not drop it! Never drill holes in the motor! Copyright © 2009 Somfy SAS. All rights reserved - V0 - 12/2009...
- Page 3 Do not dispose of your scrapped appliances, nor your used batteries with household waste. You are liable to dispose of all your electronic or electrical equipment waste by relocating over to a dedicated collection point for recycling. Copyright © 2009 Somfy SAS. All rights reserved - V0 - 12/2009...
-
Page 4: Installation
4 mm Motor preparation the motor. Motor/tube assembly Slide the motor into the tube. For smooth tubes, position the notch on the crown. 15 mm 5 mm 20 mm Copyright © 2009 Somfy SAS. All rights reserved - V0 - 12/2009... - Page 5 Mount the motorized tube on the motor Wiring Motor Wiring: 230V/50Hz 3 x 1,5 mm White 3 x 0.75 mm Phase Green Yellow/ Green Phone connector wiring: Dry Contact DOWN IR Contact DATA Copyright © 2009 Somfy SAS. All rights reserved - V0 - 12/2009...
- Page 6 The LED lights on. Put the selector upward. Press the UP or DOWN push button of If the direction is wrong, press the STOP button more than 2 seconds. Copyright © 2009 Somfy SAS. All rights reserved - V0 - 12/2009...
- Page 7 Put the selector on its central position, the DOWN end limit is recorded. Check the setting that the motor stops at the UP and DOWN limits just set. Copyright © 2009 Somfy SAS. All rights reserved - V0 - 12/2009...
- Page 8 Put the selector on its central position to set the intermediate position. Move the screen to the required position, with the UP or DOWN button. Press the StOP button more than Copyright © 2009 Somfy SAS. All rights reserved - V0 - 12/2009...
