a Programming the intermediate position (IP)
Set the blind to its UP limit before programming in order to always have the same adjustment.
1 2
UP
after
3 seconds
• Press the ▼ and ■ button simultaneously
• Move the blind at its UP limit with
the ▲ button and immediately press
until the blind begins to move DOWN.
the ■ button briefly.
b Programming the automatic slat tilting
1 2
after
3 seconds
• Press simultaneously on the ▲
• Move the blind downward to get
and ■ button until the blind begins
the slats closed.
to move briefly UP.
c Operating
If IP only has been programmed If tilting only has been programmed
UP limit
IP
• Press briefly the ■ button while the • Press briefly the ■ button while the blind
blind is at its UP limit. is closed (after a DOWN movement).
➜ The blind will move and stop at the ➜ The blind will tilt at the pre-set angle.
intermediate position. Note : after an UP movement the blind
does not tilt.
d Delete the intermediate position/automatic tilting
If you record a new IP or a new tilting function, this will automatically erase the previous one.
If you want to erase without recording a new one, Press briefly on the ■ button to reach the IP or to get the tilting (or both), then:
To erase the intermediate position, press the ▼ and ■ buttons simultaneously for more than 5 seconds.
To erase the tilting, press the ■ and ▲ buttons simultaneously for more than 5 seconds.
To erase both, just press the ■ button for more than 5 seconds.
➜ The blind jogs briefly (UP/DOWN) indicating that CENTRALIS uno RTS VB has deleted the intermediate position and/or the tilting.
5
Complete reset
To completely reset the CENTRALIS uno RTS VB, press its PROG button for more than 7 seconds.
This will erase all of the programmed controls, the intermediate position and the automatic tilting.
➜ The blind jogs twice (UP/DOWN), the memory of the CENTRALIS uno RTS VB is cleared.
➜ Tilting mode : back to US mode.
7 sec.
6
Trouble shooting guide
Nothing works:
Phantom intermediate position/slat tilting:
Check the wiring.
The programmed IP can only be reached from the UP limit. not when
Check the battery of the transmitter. the blind is in another position.
Check that the transmitter has been properly Be sure to adjust the slat tilting after a down movement when the
recorded. blind is approximately 3/4 down of the window.
Check for any other possible source of radio
interferences.
4
CENTRALIS uno RTS VB
3/10/06 10:38 Page 1
3 4
5 sec.
STOP
• Press the ■ button more than 5 sec.
• Stop the blind at the intermediate
➜ The blind jogs briefly (UP/DOWN),
position you wish.
If necessary, adjust this position
the intermediate position is recorded.
with the ▲ or ▼ buttons.
4
3
5 sec.
adjust
or the angle
• Press the ■ button more than 5 sec.
• Adjust the tilt angle with the
▲ or ▼ buttons. ➜ The blind jogs briefly (UP/DOWN),
the tilt angle is recorded.
If both IP and tilting have been programmed
UP limit
tilting IP
• Press briefly the ■ button while the blind is at its UP limit.
➜ The blind will move, stop at the intermediate position and tilt at
the pre-set angle.
Note : after a DOWN movement the blind only tilts.
Lost in your programming mode:
Just make a complete reset and start again
(refer to section 5).
We reserve the right to make changes due to technical improvements.
SOMFY SAS, capital 20.000.000 Euros, RCS Bonneville 303.970.230
INSTALLATION
IP
inteo
CENTRALIS UNO RTS VB is an individual control system for AC motor dedicated to external and interior
venetian blind applications.
• CENTRALIS UNO RTS VB has an integrated radio receiver compatible with the RT and RTS
• The commands coming from the radio controls can be disabled thanks to the 0/auto switch.
• An automatic intermediate position and a slat tilting operation can be programmed.
• CENTRALIS UNO RTS VB is compatible with the EOLIS, SOLIRIS and SUNIS sensors RTS. Up to three
1
Characteristics
tilting
80 mm
2
Installation
This device must be installed and programmed by qualified installers for whom this instruction is inten-
ded. Before connecting the unit, read the instructions carefully.
Assembly
2.1
FRONT PLATE
FRAME
CONTROL UNIT
We reserve the right to make changes due to technical improvements.
CENTRALIS UNO RTS VB
transmitters allowing individual, group and master commands. Up to twelve controls can be recorded
in the CENTRALIS UNO RTS VB.
RTS sensors can be memorized in one receiver and one RTS sensor can be memorized in several receivers.
• Main supply : 220-240V 50Hz.
• Class II product
• Protection index IP40.
80 mm • Output : 250V~ 3A
• Output temporisation : activ for 180s.
• Environmental conditions for use :
- temperature 0°C to +40°C (no condensation allowed).
- pollution degree typical for usual living space.
33 mm 17 mm
Hereby, SOMFY, declares that this equipment
is in compliance with the essential require-
ments and other relevant provisions of
Directive 1999/5/EC.
A Declaration of Conformity is available at the
web address www.somfy.com Heading CE
Usable in EU,
The range of radio control is limited by laws regulating
radio devices and by building design.
BRACKET
When planning, please ensure that there is adequate radio
reception.
In order not to affect quality of reception, a minimum
distance of 30 cm between a CENTRALIS uno RTS VB
and a radio transmitter should be maintained.
CENTRALIS uno RTS VB should not be installed in the
WALL
immediate vicinity of metal surfaces. Powerful local trans-
mitter equipment (e.g. cordless headphones) with a trans-
mission frequency identical to the CENTRALIS uno RTS
VB can affect its function.
