SITUO 1 io
SITUO 5 io
Télécommandes 1 canal - 5 canaux io
FR
Manuel d'installation et d'utilisation
1-channel – 5-channel io remote controls
EN
Installation and operating guide
Programmierbarer Funksender mit 1 – 5 Kanälen io
DE
Montage- und Gebrauchsanweisung
1-kanaal - 5-kanalen io-afstandsbedieningen
NL
Installatie- en gebruikshandleiding
Piloty zdalnego sterowania 1-kanałowe - 5-kanałowe io
PL
Instrukcja montażu i obsługi
Mandos a distancia de 1 canal - 5 canales io
ES
Manual de instalación y de uso
Telecomandi a 1 - 5 canali io
IT
Manuale di installazione e d'uso
Comandos à distância 1 canal - 5 canais io
PT
Guia de instalação e de utilização
Τηλεχειριστήρια 1 καναλιού - 5 καναλιών io
EL
Εγχειρίδιο εγκατάστασης και χρήσης
II
II
5153434A
Advertisement
Table of Contents
Related Manuals for SOMFY SITUO 1 io II
Summary of Contents for SOMFY SITUO 1 io II
- Page 1 SITUO 1 io SITUO 5 io Télécommandes 1 canal - 5 canaux io Manuel d’installation et d’utilisation 1-channel – 5-channel io remote controls Installation and operating guide Programmierbarer Funksender mit 1 – 5 Kanälen io Montage- und Gebrauchsanweisung 1-kanaal - 5-kanalen io-afstandsbedieningen Installatie- en gebruikshandleiding Piloty zdalnego sterowania 1-kanałowe - 5-kanałowe io...
-
Page 2: Table Of Contents
5 Installing the remote control wall mounting 6 Tips and recommendations 6.1 Specific case of an io partner solar motor (example Velux®) 7 Replacing the battery 8 Technical data EN - Installation and operating guide SOMFY io 1-channel – 5-channel remote controls... -
Page 3: Welcome
Motorisations for gates, garage doors and roller shutters, alarm systems, lighting controls, heating thermostats and all Somfy products are designed to meet your expectations in terms of safety, comfort and energy efficiency. At Somfy, the pursuit of quality is a continuous process of improvement. Somfy's reputation has been built upon the reliability of its products, and the Somfy brand is synonymous with innovation and technological expertise worldwide. -
Page 4: Product Description
Channel 2: The channel selection button is used to navigate between channels. Channel 3: The indicator lights indicate the selected channel (see illustration opposite). Channel 4: Channel 5: EN - Installation and operating guide SOMFY io 1-channel – 5-channel remote controls... -
Page 5: Use
Short press On Open • Stop if the shutter is moving Short press – • Favourite position saved if the shutter is open or closed Short press Off Close EN - Installation and operating guide SOMFY io 1-channel – 5-channel remote controls... -
Page 6: Programming Your Remote Control
Use a fine-tipped object to make a short press on the PROG button on the back of the remote control. The indicator light on the remote-controlled socket will come on permanently, then go off. Example with Somfy io remote-controlled socket EN - Installation and operating guide SOMFY io 1-channel – 5-channel remote controls... - Page 7 We therefore advise you to add your products little by little with an individual control to avoid any deprogramming error. EN - Installation and operating guide SOMFY io 1-channel – 5-channel remote controls...
-
Page 8: Programming On A Somfy Io Roller Shutter Or Hinged Shutter Motorisation
▶ Programming a remote control Identify the original shutter control, i.e. the remote control or control point which only controls this shutter. - If the original control is lost or broken and it is the only one that controls the shutter, contact Somfy assistance. -
Page 9: Deleting Your Remote Control
Use a fine-tipped object to make a short press on the PROG button on the back of the remote control. The indicator light on the remote-controlled socket goes off. Example with Somfy io remote-controlled socket EN - Installation and operating guide SOMFY io 1-channel – 5-channel remote controls... - Page 10 The shutter moves up and down (or emits 2 audible signals). Original control Back of control point Back of remote control Remote control to be deleted EN - Installation and operating guide SOMFY io 1-channel – 5-channel remote controls...
-
Page 11: Installing The Remote Control Wall Mounting
Remove the protective film from the adhesive on the back of the wall mounting. Fasten the wall mounting to a flat, clean and dry surface and press to ensure optimum bonding. Place the Situo io remote control on its holder. EN - Installation and operating guide SOMFY io 1-channel – 5-channel remote controls... -
Page 12: Tips And Recommendations
6.1 Specific case of an io partner solar motor (example Velux®) Only perform this procedure to control a solar shutter motor from a partner brand other than Somfy. This procedure must be performed for each channel of the Situo 5 io remote control to be paired with an io partner solar motor. -
Page 13: Replacing The Battery
Replace the cover. Screw the rear cover back into place. Please separate batteries from other types of waste and recycle them via the local collection system. CR2032 EN - Installation and operating guide SOMFY io 1-channel – 5-channel remote controls... -
Page 14: Technical Data
Radio range 150 m in free field. Use guaranteed on most floors according to the environment (point-to-point access). Operating temperature 0°C to + 48°C Power supply 1 x 3 V CR2032 battery EN - Installation and operating guide SOMFY io 1-channel – 5-channel remote controls... - Page 15 Somfy Belux NV. Somfy Italia SRL 02 712 07 70 800827151 www.somfy.be www.somfy.it Somfy Ltd. (+44) 0113 391 3030 www.somfy.co.uk Somfy Sp. z o.o 810377199 www.somfy.pl SOMFY ACTIVITES SA 50 avenue du Nouveau Monde 74300 CLUSES FRANCE www.somfy.com...
