Summary of Contents for Zhiyun CINEPEER C100

Page 1 The following features are available in this PDF document. Quick Keyword Search Enter the keyword in the search box and hit the search button Quick Jump between Chapters Click the title of a specific chapter on the Contents to jump to it *Reading software such as Adobe Reader is needed to support the functions above.
Page 2 ZHIYUN CINEPEER C100 User Guide...
Page 3: Table Of Contents
Contents Brief■Introduction ■ Brief■Introduction■ ··················· 1 Product■List ■ Product■List■ ······················ 3 Get■to■Know■ZHIYUN■CINEPEER■C100 ■ Get■to■Know■ZHIYUN■CINEPEER■C100■ ··········· 5 Charging ■ Charging■ ······················· 6 Installing■Modifiers ■ Installing■and■Removing■the■Barn■Doors■·········· 7 Installing■and■Removing■the■Diffuser■ ··········· 9 Installing■and■Removing■the■Grid■ ············· 10 Installing■and■Removing■the■Light■Clamp■ ········· 11 Installing■and■Removing■the■Stick■Light■Connector■ ····· 12 How■to■Use■ZHIYUN■CINEPEER■C100 ■ Buttons■and■Dials■ ··················· 13 Operation■Instruction■··················...
Page 4 Warranty■Card ■ Contents Warranty■Period■ ···················· 23 Warranty■Exclusions■ ·················· 23 Warranty■Claim■Procedure■················ 23 Contact■Card ■...
Page 5: Brief Introduction
WARNING This product is not waterproof. Prevent contact with any kind of liquid with the ZHIYUN CINEPEER C100. Never use the product in the rain or a humid environment. If water accidentally enters the device when using, please stop using it...
Page 6 Do not expose this product to an environment above 40℃ . Battery safety precautions: ① It is strictly prohibited to use batteries that are not provided by ZHIYUN. If you need to replace the battery, please contact ZHIYUN or designated agents.
Page 7: Product■List
Before using this product, please check carefully that all the following items are included in the product package. In case that any item is found missing, please contact ZHIYUN or your local selling agent. Main Device x1 USB Type C Cable x1...
Page 8 Product■List Stick Light Connector x1** Storage Bag x1 Quick Start Guide x1 Items marked “ *” are only included in ZHIYUN CINEPEER C100 COMBO package. Items marked “**” should be purchased separately.
Page 9: Get To Know Zhiyun Cinepeer C100
Get■to■Know■ZHIYUN■CINEPEER■C100 Get to Know ZHIYUN CINEPEER C100 MODE Button Power Button 1/4 Screw Hole USB-C Port SELECT Dial DC Charging Port ADJUST Dial Display Screen Light Shade Microphone Built-in Battery Cooling Vent Cooling Vent 1/4 Screw Hole...
Page 10: Charging
① Charging with USB adapter: Use a Type-C cable to connect the USB adapter to the Type-C port of the CINEPEER C100 and plug the USB adapter into an AC socket. It is recommended to use a USB adapter that meets the PD fast charging protocol and is higher than 100W in power.
Page 11: Installing■Modifiers
Installing and Removing the Barn Doors Installing: Install the barn doors onto the ZHIYUN CINEPEER C100 as shown in the figure ① , until the end of the barn doors is level with the end of the light body. Press down the two U-shaped clips on the barn doors ②...
Page 12 Installing■Modifiers Removing: Fold the side panels of the barn doors to the position shown in the figure ① . Hold the side panels with both hands, and at the same time, use your thumbs to push the light body from the outside of the U-shaped clip above the barn doors ②...
Page 13: Installing And Removing The Diffuser
Installing■Modifiers Installing and Removing the Diffuser Installing: Install the barn doors to the light and expand the barn doors to both sides to their vertical state ① . Attach the diffuser to the barn doors side panels until the diffuser completely covers the LED chips ② . Push the barn doors outward to put up the diffuser ③...
Page 14: Installing■And■Removing■The■Grid
Installing■Modifiers Installing and Removing the Grids Installing： Install the barn doors to the light and expand the barn doors to both sides to their vertical state ① . Loosen the straps and make sure both sides of the grids are aligned with the barn doors ②...
Page 15: Installing And Removing The Light Clamp
Installing■Modifiers Installing and Removing the Light Clamp Install the light clamp onto the ZHIYUN CINEPEER C100 and tighten it, then install the whole assembly onto the crossbar of the C-stand adapter. When disassembling, remove the light and the light clamp assembly from the crossbar of the C-stand adapter, then remove the light clamp from the light body.
Page 16: Installing And Removing The Stick Light Connector
Installing■Modifiers Installing and Removing the Stick Light Connector Unlock the stick light connector ① and separate it ② . Install the two parts to two stick lights respectively ③ , join two stick lights together with the connector, and the connector will lock automatically ④ . When disassembling, unlock the stick light connector and separate two stick lights, then remove the connector from the stick light.
Page 17: How■To■Use■Zhiyun■Cinepeer■C100
How■to■Use■ZHIYUN■CINEPEER■C100 DO NOT stare at the LED chips when the device is operating. The IP rating of the outer case is IP20. ① During the use of the light, when the temperature rises to a certain degree, the fan will automatically turn on for heat dissipation.
Page 18: Operation Instruction
How■to■Use■ZHIYUN■CINEPEER■C100 Operation Instruction 1. CCT Mode Settings Single press MODE button to switch to CCT mode. Turn the SELECT dial to switch to brightness/color temperature/Green-Magenta options. Single press or turn the ADJUST dial to adjust the chosen value. Brightness adjustment range: 0-100% Color temperature adjustment range:2700K-6500K;...
Page 19: Color Fade
How■to■Use■ZHIYUN■CINEPEER■C100 3. RGB Mode Settings Single press MODE button to switch to RGB mode. Turn the SELECT dial to switch to RGB options. Single press or turn the ADJUST dial to adjust the value. RGB adjustment range: 0-100% Brightness adjustment range: 0-100% ��%...
Page 20 How■to■Use■ZHIYUN■CINEPEER■C100 5. FX Mode Settings Single press MODE button to switch to FX mode. Turn the SELECT dial to switch to FX/brightness/speed/color temperature options. Single press/turn the Adjust dial to adjust the chosen value. Effect Types: SOS, Paparazzi, Candle, Bad Bulb, TV, Lightning, CCT Pulse, CCT...
Page 21 Turn the ADJUST dial to adjust the chosen value and press the ADJUST dial once to confirm. MENU Language: English BT Rst: Version: V�.�� Under the "MENU" option, you can also check the firmware version information for the ZHIYUN CINEPEER C100.
Page 22: Firmware■Upgrade
Firmware■Upgrade You can use “ Zhiyun Led Tools” or “ZY Vega” to perform the ZHIYUN CINEPEER C100 firmware upgrade. Method 1: 1. Visit the official website of ZHIYUN (www.zhiyun-tech.com), go to the ZHIYUN CINEPEER C100 product page, click "Download", find the Zhiyun Led Tools and the firmware and download.
Page 23 Firmware■Upgrade Method 2: The firmware of the ZHIYUN CINEPEER C100 can be upgraded using the "ZY Vega" app. For more detailed instructions, please visit the ZHIYUN official website at www.zhiyun-tech.com and watch the related video tutorials for the ZHIYUN CINEPEER C100.
Page 24: Product■Specifications
Product■Specifications Product Model： PL113 Battery Capacity 6S/4500mAh Max Power 100W Color Temperature 2700K-6500K Range Dimming Range 0-100% RGB Range 0° -360° CRI ≥ 95 CRI/TLCI TLCI ≥ 98 208pcs cool&warm +96pcs LED Chip Illuminance (Max power, without 3870(lux) Lab Data 1 modifier) Charging Time 3H 53min...
Page 25 The above data is gathered from internal experiments of ZHIYUN laboratories. Under different scenarios, data is different to some extent. Please refer to the actual use.
Page 26: Disclaimer■And■Warnings
Guilin Zhishen Information Technology Co., Ltd (hereinafter referred to as "ZHIYUN") reserves all rights for final explanation of this instruction and other documents related to this product. The information is subject to update without notice.
Page 27: Warranty Period
1. Customers are entitled to replacement or free repair service in case of quality deficits found in the product within 15 days upon receipt of the product. 2. Customers are entitled to free repair service from ZHIYUN for any product proven defective in material or workmanship that results in product failure during normal consumer usage and conditions within the valid warranty period, which is 12 months counting from the date of selling.
Page 28 Warranty■Card Customer Information Customer Name: Phone Number: Address: Sales Information Sales date: Product Serial Number: Distributor Name: Distributor’ s Contact Number: First Maintenance Record Service Date: Repairman Signature: Cause of Problem: Service Result: □ Solved □ Unsolved □ Refunded/Replaced...
Page 29 Contact Card Website Weibo Vimeo Google+ Facebook Facebook (Zhiyun Support) (Zhiyun Tech) Youku Youtube Wechat Instagram...
Page 30 E-mail: info@zhiyun-tech.com Address: 09 Huangtong Road, Tieshan Industrial Zone, Qixing District, Guilin, 541004, Guangxi, China For full product information, please visit ZHIYUN's official website: Content on www.zhiyun-tech.com is subject to update without notice. ZHIYUN ™ is a trademark of ZHISHEN All product names or brands referred to hereunder may be trademarks or registered trademarks of their respective holders.
