Summary of Contents for Zhiyun CINEPEER CX100
- Page 1 The following features are available in this PDF document. Quick Keyword Search Enter the keyword in the search box and hit the search button Quick Jump between Chapters Click the title of a specific chapter on the Contents to jump to it *Reading software such as Adobe Reader is needed to support the functions above.
- Page 2 CINEPEER CX100 COB Light User Guide...
-
Page 3: Table Of Contents
Contents Brief■Introduction ■ Brief■Introduction■ ··················· 1 Product■List ■ Product■List■ ······················ 3 Get■to■Know■CINEPEER■CX100 ■ Get■to■Know■CINEPEER■CX100■ ·············· 4 Charging ■ Charging■ ······················· 5 Installing■Modifiers ■ Installing■and■Removing■the■Reflector■··········· 6 Installing■and■Removing■the■Diffusion■Dome■ ········ 7 Installing■Tripod ■ Installing■Light■Stand ■ How■to■Use■CINEPEER■CX100 ■ Buttons■and■Dials■ ··················· 10 Indicator■Lights■Instruction■ ··············· 11 Operation■Instruction■··················... - Page 4 Warranty■Card ■ Contents Warranty■Period■ ···················· 18 Warranty■Exclusions■ ·················· 18 Warranty■Claim■Procedure■················ 18 Contact■Card ■...
-
Page 5: Brief Introduction
WARNING This product is not waterproof. Prevent contact with any kind of liquid with the CINEPEER CX100 COB Light. Never use the product in the rain or a humid environment. If water accidentally enters the device when using, please stop using it... - Page 6 Brief■Introduction Battery safety precautions: ① It is strictly prohibited to use batteries that are not provided by ZHIYUN. If you need to replace the battery, please contact ZHIYUN or designated agents. ZHIYUN will not be responsible for any battery accidents or equipment malfunctions caused by using batteries that are not officially provided by ZHIYUN.
-
Page 7: Product List
Product List Before using this product, please check carefully that all the following items are included in the product package. In case that any item is found missing, please contact ZHIYUN or your local selling agent. Fill Light x1 Reflector x1... -
Page 8: Get To Know Cinepeer Cx100
Get■to■Know■CINEPEER■CX100 Get to Know CINEPEER CX100 Battery Level/ Charging Indicator Lights Cooling Vent Lanyard Hole Color Temperature Built-in Battery Adjustment Dial Brightness Adjustment Dial Power Button Fan Shade Accessory Mount COB Chip Lanyard Hole DC Charging USB-C Port 1/4''Screw Hole... -
Page 9: Charging
USB Type-C Cable （100-240V） ① It is recommended to charge CINEPEER CX100 when the light is turned off. ② When using while charging, it is recommended to use a USB adapter and USB cable that support the PD fast charging protocol and have a power greater than 100W. -
Page 10: Installing■Modifiers
Installing Align the reflector mount with the accessory mount of the CINEPEER CX100, then mount the reflector onto the CINEPEER CX100 and rotate it in the direction shown until you hear a "click". The reflector buckle will automatically lock, indicating that the installation is complete. -
Page 11: Installing And Removing The Diffusion Dome
Installing■Modifiers Installing and Removing the Diffusion Dome Installing Install the reflector to the diffusion dome, unfold the diffusion dome to the state shown in the figure, align the opening of the diffusion dome with the reflector, then fit the ring-shaped groove of the diffusion dome onto the end of the reflector to complete the installation. -
Page 12: Installing■Tripod
Installing■Tripod Align the 1/4-inch screw at the top of the tripod with the 1/4-inch screw hole at the bottom of the CINEPEER CX100. Then, mount the CINEPEER CX100 onto the tripod. Tripod is not provided. -
Page 13: Installing■Light■Stand
Installing■Light■Stand Align the 1/4-inch screw hole at the bottom of the CINEPEER CX100 with the 1/4- inch screw at the top of the light stand. Then, attach the CINEPEER CX100 to the light stand. ② ① Light stand is not provided. -
Page 14: How■To■Use■Cinepeer■Cx100
How■to■Use■CINEPEER■CX100 DO NOT stare at the LED chips when the device is operating. The IP rating of the outer case is IP20. Buttons and Dials Power Button: Single press+long press: Power on Long press: Power off Color Temperature Adjustment Dial: Turn: Adjust color temperature Brightness Adjustment Dial: Turn: Adjust brightness... -
Page 15: Indicator Lights Instruction
How■to■Use■CINEPEER■CX100 Indicator Lights Instruction Indicator Lights Status Solution Two lights flash quickly at Recommended■to■ Hardware malfunction the same time contact■after-sales Three lights flash quickly Recommended to Hardware malfunction at the same time contact after-sales Recommended■to■use■ Four lights flash quickly at at■a■normal■temperature■... -
Page 16: Operation Instruction
Operation Instruction 1. Single press the power button, then press and hold the power button to turn on the CINEPEER CX100. At this time, the battery level/charging indicator lights show the remaining battery level. 2. Turn the brightness adjustment dial to adjust the brightness value of the light. -
Page 17: Firmware■Upgrade
Tools and the firmware and download. 2. Unzip the firmware for the files with the ".ptz" file extension. 3. Connect the USB-C port of CINEPEER CX100 to the USB port of the computer with the USB Type-C cable. 4. Open "Zhiyun Led Tools", click "Open", and click "Firmware Upgrade". Click "Browse"... - Page 18 Firmware■Upgrade...
-
Page 19: Product■Specifications
Product■Specifications Product Model： PLX107 Battery Capacity 4500mAh Max Output Power 100W Brightness Adjustment 0-100% Range Color Temperature 2700K-6500K Range CRI ≥ 96 CRI/TLCI TLCI ≥ 97 Illuminance (maximum power, 3840(lux) Lab Data 1 without reflector) Illuminance (maximum 21100(lux) Lab Data 2 power, with reflector) Continuous Runtime 30min... - Page 20 The above data is gathered from internal experiments of ZHIYUN laboratories. Under different scenarios, data is different to some extent. Please refer to the...
-
Page 21: Disclaimer■And■Warnings
Guilin Zhishen Information Technology Co., Ltd (hereinafter referred to as "ZHIYUN") reserves all rights for final explanation of this instruction and other documents related to this product. The information is subject to update without notice. - Page 22 1. Customers are entitled to replacement or free repair service in case of quality deficits found in the product within 15 days upon receipt of the product. 2. Customers are entitled to free repair service from ZHIYUN for any product proven defective in material or workmanship that results in product failure during normal consumer usage and conditions within the valid warranty period, which is 12 months counting from the date of selling.
- Page 23 Warranty■Card Customer Information Customer Name: Phone Number: Address: Sales Information Sales date: Product Serial Number: Distributor Name: Distributor’ s Contact Number: First Maintenance Record Service Date: Repairman Signature: Cause of Problem: Service Result: □ Solved □ Unsolved □ Refunded/Replaced...
- Page 24 Contact Card Website Weibo Vimeo Google+ Facebook Facebook (Zhiyun Support) (Zhiyun Tech) Youku Youtube Wechat Instagram...
- Page 25 E-mail: info@zhiyun-tech.com Address: 09 Huangtong Road, Tieshan Industrial Zone, Qixing District, Guilin, 541004, Guangxi, China For full product information, please visit ZHIYUN's official website: Content on www.zhiyun-tech.com is subject to update without notice. ZHIYUN ™ is a trademark of ZHISHEN All product names or brands referred to hereunder may be trademarks or registered trademarks of their respective holders.
