Summary of Contents for Zhiyun MOLUS B300
- Page 1 The following features are available in this PDF document. Quick Keyword Search Enter the keyword in the search box and hit the search button Quick Jump between Chapters Click the title of a specific chapter on the Contents to jump to it *Reading software such as Adobe Reader is needed to support the functions above.
- Page 2 ZHIYUN MOLUS B300/B500 COB Light User Guide...
-
Page 3: Table Of Contents
Contents Brief■Introduction ■ Brief■Introduction■ ··················· 1 Product■List ■ Product■List■ ······················ 3 Get■to■Know■ZHIYUN■MOLUS■B300/B500 ■ Get■to■Know■ZHIYUN■MOLUS■B300/B500■·········· 4 Power■Supply ■ Power■Supply■ ····················· 5 Installing■Accessories ■ Installing/Detaching■the■Reflector■ ············ 6 Installing■a■Light■Stand■ ················· 7 Installing/Detaching■the■Umbrella■ ············ 8 How■to■Use■ZHIYUN■MOLUS■B300/B500 ■ Buttons■and■Dials■ ··················· 9 Operation■Instructions■ ················· 10 Power-On■Settings■ ··················· 11 Firmware■Upgrade... - Page 4 Warranty■Card ■ Contents Warranty■Period■ ···················· 18 Warranty■Exclusions■ ·················· 18 Warranty■Claim■Procedure■················ 18 Contact■Card ■...
-
Page 5: Brief Introduction
WARNING This product is not waterproof. Prevent contact with any kind of liquid with the ZHIYUN MOLUS B300/B500. Never use the product in the rain or a humid environment. If water accidentally enters the device when using, please stop using it... - Page 6 7. Before storing this product, please make sure it is completely cooled and store it in a dry and ventilated place. 8. Do not disassemble this product on your own. In the event of malfunctions, it should be repaired by ZHIYUN or authorized maintenance personnel.
-
Page 7: Product List
Before using this product, please check carefully that all the following items are included in the product package. In case that any item is found missing, please contact ZHIYUN or your local selling agent. ZHIYUN MOLUS B300/B500 COB Light Reflector x1... -
Page 8: Get To Know Zhiyun Molus B300/B500
Get■to■Know■ZHIYUN■MOLUS■B300/B500 Get to Know ZHIYUN MOLUS B300/B500 DIM Dial USB-C Port Accessory Mount Fan Guard COB Chip Cooling Vent Umbrella Hole Umbrella Hole Lock Dial Bracket Bracket Latch Cooling Vent Display Screen CCT Dial Adjusting Handle Fan Guard Fan Guard... -
Page 9: Power Supply
Power Supply This product does not contain batteries. To ensure normal operation, please follow these steps: Use the provided AC power cable to connect the ZHIYUN MOLUS B300/B500 to the AC power outlet to supply power to the B300/B500. A�����V-���V... -
Page 10: Installing■Accessories
Installing■Accessories Installing/Detaching the Reflector ZHIYUN MOLUS B300/B500 is compatible with standard Bowens mount accessories, and in this case, we will use the standard reflector (Bowens mount) as an example for installation. Installing: Align the mount of the standard reflector with the accessory mount of the MOLUS B300/B500, and install the standard reflector onto the light body ①... -
Page 11: Installing A Light Stand
Installing■Accessories Installing a Light Stand Align the end of the bracket with the 1/4 screw at the top of the light stand ① . Then, install the B300/B500 onto the light stand and tighten the bracket latch ② . Loosen the bracket hinge latch ③ and adjust the angle of the light body as you wish ④... -
Page 12: Installing/Detaching The Umbrella
Installing■Accessories Installing/Detaching the Umbrella Insert the handle of the umbrella into the umbrella hole on the bracket, and then tighten the umbrella lock clockwise. To detach the umbrella, rotate the umbrella lock counterclockwise and pull out the handle of the umbrella. Umbrella is not provided in the product package. -
Page 13: How■To■Use■Zhiyun■Molus■B300/B500
The protection level of the MOLUS B300/B500 outer case is IP20. ① During the use of the MOLUS B300/B500， when the temperature rises to a certain degree, the fan will automatically turn on to achieve the purpose of heat dissipation for the light. -
Page 14: Operation Instructions
How■to■Use■ZHIYUN■MOLUS■B300/B500 Operation Instructions 1. CCT Mode Settings In the CCT mode interface, single press/turn the DIM dial to adjust the brightness. Single press/turn the CCT dial to adjust the color temperature. Brightness adjustment range: 0-100% Color temperature adjustment range: 2700K-6500K ����K... -
Page 15: Power-On Settings
“ O” side. When connected to power, you need to put the switch to the “一” side to power on the light. Live mode: Before connecting ZHIYUN MOLUS B300/B500 to the AC power, the power switch is at the “ 一” side. The light will be automatically powered on when... -
Page 16: Firmware■Upgrade
2. Unzip the firmware for the files with the ".ptz" file extension. 3. Connect the USB-C port of ZHIYUN MOLUS B300/B500 to the USB port of the computer with the USB Type-C cable. 4. Open "Zhiyun Led Tools", click "Open", and click "Firmware Upgrade". Click "Browse"... - Page 17 Firmware■Upgrade Method 2: The firmware of the ZHIYUN MOLUS B300/B500 can be upgraded using the "ZY Vega" app. For more detailed instructions, please visit the ZHIYUN official website at www.zhiyun-tech.com and watch the related video tutorials for the ZHIYUN MOLUS B300/B500.
-
Page 18: Product■Specifications
Product■Specifications Product Model： PLB106/PLB108 ZHIYUN MOLUS ZHIYUN MOLUS Product Model Remark B300 COB Light B500 COB Light Power 300W 500W Color Temperature 2700K-6500K Range Brightness 0-100% Adjustment Range CRI ≥ 95 CRI/TLCI TLCI ≥ 97 TM-30 Rf (on average) TM-30 Rg (on average) ≥... - Page 19 5500K with 100% brightness. The illuminance is 63200(lux)/76400(lux). The actual illuminance varies under different conditions. Any data mentioned in this user guide is the result of internal testing at ZHIYUN Lab. Under different objective conditions, there may be varying degrees of error...
-
Page 20: Disclaimer■And■Warnings
Guilin Zhishen Information Technology Co., Ltd (hereinafter referred to as "ZHIYUN") reserves all rights for final explanation of this instruction and other documents related to this product. The information is subject to update without notice. -
Page 21: Safe Operation Instructions
DO NOT use with incompatible components or in any way otherwise as mentioned or instructed in the product documents provided by ZHIYUN. The safety guidelines herein contain instructions for safety, operation and maintenance. - Page 22 1. Customers are entitled to replacement or free repair service in case of quality deficits found in the product within 15 days upon receipt of the product. 2. Customers are entitled to free repair service from ZHIYUN for any product proven defective in material or workmanship that results in product failure during normal consumer usage and conditions within the valid warranty period, which is 12 months counting from the date of selling.
- Page 23 Warranty■Card Customer Information Customer Name: Phone Number: Address: Sales Information Sales date: Product Serial Number: Distributor Name: Distributor’ s Contact Number: First Maintenance Record Service Date: Repairman Signature: Cause of Problem: Service Result: □ Solved □ Unsolved □ Refunded/Replaced...
- Page 24 Contact Card Website Weibo Vimeo Google+ Facebook Facebook (Zhiyun Support) (Zhiyun Tech) Youku Youtube Wechat Instagram...
- Page 25 E-mail: info@zhiyun-tech.com Address: 09 Huangtong Road, Tieshan Industrial Zone, Qixing District, Guilin, 541004, Guangxi, China For full product information, please visit ZHIYUN's official website: Content on www.zhiyun-tech.com is subject to update without notice. ZHIYUN ™ is a trademark of ZHISHEN All product names or brands referred to hereunder may be trademarks or registered trademarks of their respective holders.
