Summary of Contents for Zhiyun CINEPEER CM25
- Page 1 The following features are available in this PDF document. Quick Keyword Search Enter the keyword in the search box and hit the search button Quick Jump between Chapters Click the title of a specific chapter on the Contents to jump to it *Reading software such as Adobe Reader is needed to support the functions above.
- Page 2 CINEPEER CM25 Fill Light User Guide...
-
Page 3: Table Of Contents
Contents Brief■Introduction ■ Brief■Introduction■ ··················· 1 Product■List ■ Product■List■ ······················ 3 Get■to■Know■CINEPEER■CM25 ■ Get■to■Know■CINEPEER■CM25■ ·············· 4 Charging ■ Charging■ ······················· 5 Installing■Modifier ■ Installing■and■Removing■Silicone■Diffuser■ ········· 6 Installing■Tripod ■ Installing■Light■Stand ■ How■to■Use■CINEPEER■CM25 ■ Dials■and■Indicator■Lights■ ················ 9 Indicator■Lights■Instruction■ ··············· 10 Operation■Instruction■·················· 11 Firmware■Upgrade ■... - Page 4 Warranty■Card ■ Contents Warranty■Period■ ···················· 17 Warranty■Exclusions■ ·················· 17 Warranty■Claim■Procedure■················ 17 Contact■Card ■...
-
Page 5: Brief Introduction
WARNING This product is not waterproof. Prevent contact with any kind of liquid with the CINEPEER CM25 Fill Light. Never use the product in the rain or a humid environment. If water accidentally enters the device when using, please stop using it... - Page 6 Brief■Introduction Battery safety precautions: ① It is strictly prohibited to use batteries that are not provided by ZHIYUN. If you need to replace the battery, please contact ZHIYUN or designated agents. ZHIYUN will not be responsible for any battery accidents or equipment malfunctions caused by using batteries that are not officially provided by ZHIYUN.
-
Page 7: Product List
Before using this product, please check carefully that all the following items are included in the product package. In case that any item is found missing, please contact ZHIYUN or your local selling agent. Fill Light x1 Silicone Diffuser x1... -
Page 8: Get To Know Cinepeer Cm25
Get■to■Know■CINEPEER■CM25 Get to Know CINEPEER CM25 Cooling Vent Color Temperature Battery Level/ Charging Indicator Lights (the top light is regarded as the Cooling Vent 4th light and the bottom as 1/4 Screw Hole Brightness the 1st) Cooling Vent USB-C Port... -
Page 9: Charging
15W. USB Charger AC Power USB Type-C Cable （100-240V） ① It is recommended to fully charge CINEPEER CM25 before using it. Low battery might impair the product performance. ② USB charger is not included in the package. -
Page 10: Installing■Modifier
① . Then, slide the other end of the silicone diffuser onto the CINEPEER CM25 to complete the installation ② . To remove, simply take off the silicone diffuser from the CINEPEER CM25. -
Page 11: Installing■Tripod
Installing■Tripod Align the 1/4-inch screw at the top of the tripod with the 1/4-inch screw hole at the bottom of the CINEPEER CM25. Then, mount the CINEPEER CM25 onto the tripod. Tripod is not provided. -
Page 12: Installing■Light■Stand
Installing■Light■Stand Align the 1/4-inch screw hole at the bottom of the CINEPEER CM25 with the 1/4- inch screw at the top of the light stand. Then, attach the CINEPEER CM25 to the light stand. ② ① Light stand is not provided. -
Page 13: How■To■Use■Cinepeer■Cm25
How■to■Use■CINEPEER■CM25 DO NOT stare at the LED chips when the device is operating. The IP rating of the outer case is IP20. Dials and Indicator Lights Brightness/Power Dial: Turn upward: Power on/increase brightness Turn downward: Power off/decrease brightness Color Temperature Adjustment Dial: Turn upward: Increase color temperature value Turn downward: Decrease color temperature value... -
Page 14: Indicator Lights Instruction
How■to■Use■CINEPEER■CM25 Indicator Lights Instruction Indicator Lights Status Solution First indicator light flashes Low battery level Second indicator light Recommended to Hardware malfunction flashes contact after-sales Third indicator light flashes Firmware upgrading Recommended to Fourth indicator light Firmware lost upgrade the firmware flashes again Recommended to use at... -
Page 15: Operation Instruction
How■to■Use■CINEPEER■CM25 Operation Instruction 1. Turn the brightness/power dial upwards. When you hear a "click" sound and the “DIM” points between "OFF" and 0%, the fill light is turned on, and the battery level/charging indicator lights display the remaining power. 2. Continue turning the brightness/power dial to adjust the brightness of the fill light. -
Page 16: Firmware■Upgrade
Zhiyun Gimbal Tools and the firmware and download. 2. Unzip the firmware for the files with the ".ptz" file extension. 3. Connect the USB-C port of CINEPEER CM25 to the USB port of the computer with the USB Type-C cable. - Page 17 Firmware■Upgrade Searching Files Firmware Upgrade Path: Browse File Name: Open Cancel Upgrade Uploading, please wait Cancel...
-
Page 18: Product■Specifications
Product■Specifications Product Model： PLM105 Battery Capacity 2000mAh Max Output Power Color Temperature 2700K-6200K Range Dimming Range 0-100% CRI ≥ 96 CRI/TLCI TLCI ≥ 97 112pcs LED Chip (56pcs warm light +56pcs cool light ) Charging Time 1H 20min Lab Data 1 (PD fast charging) Illuminance 3360(lux) - Page 19 The above data is gathered from internal experiments of ZHIYUN laboratories. Under different scenarios, data is different to some extent. Please refer to the...
-
Page 20: Disclaimer■And■Warnings
Guilin Zhishen Information Technology Co., Ltd (hereinafter referred to as "ZHIYUN") reserves all rights for final explanation of this instruction and other documents related to this product. The information is subject to update without notice. - Page 21 1. Customers are entitled to replacement or free repair service in case of quality deficits found in the product within 15 days upon receipt of the product. 2. Customers are entitled to free repair service from ZHIYUN for any product proven defective in material or workmanship that results in product failure during normal consumer usage and conditions within the valid warranty period, which is 12 months counting from the date of selling.
- Page 22 Warranty■Card Customer Information Customer Name: Phone Number: Address: Sales Information Sales date: Product Serial Number: Distributor Name: Distributor’ s Contact Number: First Maintenance Record Service Date: Repairman Signature: Cause of Problem: Service Result: □ Solved □ Unsolved □ Refunded/Replaced...
- Page 23 Contact Card Website Weibo Vimeo Google+ Facebook Facebook (Zhiyun Support) (Zhiyun Tech) Youku Youtube Wechat Instagram...
- Page 24 E-mail: info@zhiyun-tech.com Address: 09 Huangtong Road, Tieshan Industrial Zone, Qixing District, Guilin, 541004, Guangxi, China For full product information, please visit ZHIYUN's official website: Content on www.zhiyun-tech.com is subject to update without notice. ZHIYUN ™ is a trademark of ZHISHEN All product names or brands referred to hereunder may be trademarks or registered trademarks of their respective holders.
