Summary of Contents for Zhiyun MOLUS G300
- Page 1 The following features are available in this PDF document. Quick Keyword Search Enter the keyword in the search box and hit the search button Quick Jump between Chapters Click the title of a specific chapter on the Contents to jump to it *Reading software such as Adobe Reader is needed to support the functions above.
- Page 2 ZHIYUN MOLUS G300 COB Light User Guide...
-
Page 3: Table Of Contents
Contents Brief■Introduction ■ Brief■Introduction■ ··················· 1 Product■List ■ Product■List■ ······················ 3 Get■to■Know■ZHIYUN■MOLUS■G300 ■ Get■to■Know■ZHIYUN■MOLUS■G300■ ············ 4 Power■Supply ■ Power■Supply■ ····················· 5 Installing■Modifiers ■ Installing/Detaching■the■Reflector■ ············ 6 Installing■a■Light■Stand■ ················· 7 Installing/Detaching■the■Umbrella■ ············ 8 How■to■Use■ZHIYUN■MOLUS■G300 ■ Buttons■and■Dials■ ··················· 9 Operation■Instruction■·················· 10 Power-on■Setting■ · ··················· 12 Firmware■Upgrade... - Page 4 Warranty■Card ■ Contents Warranty■Period■ ···················· 19 Warranty■Exclusions■ ·················· 19 Warranty■Claim■Procedure■················ 19 Contact■Card ■...
-
Page 5: Brief Introduction
WARNING This product is not waterproof. Prevent contact with any kind of liquid with the ZHIYUN MOLUS G300. Never use the product in the rain or a humid environment. If water accidentally enters the device when using, please stop using it... - Page 6 7. Before storing this product, please make sure it is completely cooled and store it in a dry and ventilated place. 8. Do not disassemble this product on your own. In the event of malfunctions, it should be repaired by ZHIYUN or authorized maintenance personnel.
-
Page 7: Product■List
Product List Before using this product, please check carefully that all the following items are included in the product package. In case that any item is found missing, please contact ZHIYUN or your local selling agent. COB Light x1 Controller x1... -
Page 8: Get To Know Zhiyun Molus G300
Get■to■Know■ZHIYUN■MOLUS■G300 Get to Know ZHIYUN MOLUS G300 Bowens Mount Cooling Vent COB Chip Aviation Interface Bracket Hinge Latch Bracket Hinge Light Grip Bowens Mount Lock Switch Fan Guard Cooling Vent Umbrella Hole Umbrella Lock Bracket Latch Aviation Plug USB-C Port... -
Page 9: Power Supply
This product does not contain batteries. To ensure normal operation, please follow these steps: Use the controller cable to connect the controller to the ZHIYUN MOLUS G300, and then use an AC power cable to connect the controller to a power outlet to supply power to the G300. -
Page 10: Installing■Modifiers
Installing: Align the mount of the standard reflector with the mount of the MOLUS G300, and install the standard reflector onto the light body ① . Press the standard reflector slightly into the mount of the light body, and rotate the standard reflector counterclockwise until it is locked in place and cannot be rotated ②... -
Page 11: Installing A Light Stand
Installing■Modifiers Installing a Light Stand Align the end of the bracket with the 1/4 screw at the top of the light stand ① . Then, install the G300 onto the light stand and tighten the bracket latch ② . Loosen the bracket hinge latch ③ and adjust the angle of the light body as you wish ④... -
Page 12: Installing/Detaching The Umbrella
Installing■Modifiers Installing/Detaching the Umbrella Insert the handle of the umbrella into the umbrella hole on the bracket, and then tighten the umbrella lock clockwise. To detach the umbrella, rotate the umbrella lock counterclockwise and pull out the handle of the umbrella. ②... -
Page 13: How■To■Use■Zhiyun■Molus■G300
② During the use of the MOLUS G300, when the temperature rises to a certain degree, the fan will automatically turn on to achieve the purpose of heat dissipation for the light. -
Page 14: Operation Instruction
② In order to provide a better user experience, when the MAX mode is used at temperatures exceeding 30° C, MOLUS G300 will automatically disable the MAX mode and return to the CCT mode once the temperature has risen to a... - Page 15 Turn the DIM dial to adjust the chosen option. Single press the DIM dial to confirm. MENU Language English ： BT Rst： Firmware： V�.�� Under the "MENU" option, you can also check the firmware version information for the ZHIYUN MOLUS G300.
-
Page 16: Power-On Setting
How■to■Use■ZHIYUN■MOLUS■G300 Power-on Setting Normal mode: Before connecting the MOLUS G300 to an AC power source, the power switch should be on the left side. After connecting to power, toggle the power switch to the right side to turn on the light. -
Page 17: Firmware■Upgrade
Firmware■Upgrade You can use “Zhiyun Led Tools” or “ZY Vega” to perform the ZHIYUN MOLUS G300 firmware upgrade. Method 1: 1. Visit the official website of ZHIYUN (www.zhiyun-tech.com), go to the ZHIYUN MOLUS G300 product page, click "Download", find the Zhiyun Led Tools and the firmware and download. - Page 18 Firmware■Upgrade Method 2: The firmware of the ZHIYUN MOLUS G300 can be upgraded using the "ZY Vega" app. For more detailed instructions, please visit the ZHIYUN official website at www.zhiyun-tech.com and watch the related video tutorials for the ZHIYUN MOLUS G300.
-
Page 19: Product■Specifications
Product■Specifications Product Model： PLG105 Max. Input Power 500W Max. Output Power 450W Color Temperature 2700K-6500K Range Brightness Adjustment 0-100% Range CRI ≥ 95 CRI/TLCI TLCI ≥ 97 TM-30 Rf (on average) TM-30 Rg (on average) ≥ 94 AC100~240V/6.5~4A Power Supply Standard 50~60Hz Illuminance (CCT mode, maximum power,... - Page 20 4300K with 100% brightness. The illuminance is 81100lux. The actual illuminance varies under different conditions. Any data mentioned in this user guide is the result of internal testing at ZHIYUN Lab. Under different objective conditions, there may be varying degrees of error...
-
Page 21: Disclaimer■And■Warnings
Guilin Zhishen Information Technology Co., Ltd (hereinafter referred to as "ZHIYUN") reserves all rights for final explanation of this instruction and other documents related to this product. The information is subject to update without notice. -
Page 22: Safe Operation Instructions
DO NOT use with incompatible components or in any way otherwise as mentioned or instructed in the product documents provided by ZHIYUN. The safety guidelines herein contain instructions for safety, operation and maintenance. - Page 23 1. Customers are entitled to replacement or free repair service in case of quality deficits found in the product within 15 days upon receipt of the product. 2. Customers are entitled to free repair service from ZHIYUN for any product proven defective in material or workmanship that results in product failure during normal consumer usage and conditions within the valid warranty period, which is 12 months counting from the date of selling.
- Page 24 Warranty■Card Customer Information Customer Name: Phone Number: Address: Sales Information Sales date: Product Serial Number: Distributor Name: Distributor’ s Contact Number: First Maintenance Record Service Date: Repairman Signature: Cause of Problem: Service Result: □ Solved □ Unsolved □ Refunded/Replaced...
- Page 25 Contact Card Website Weibo Vimeo Google+ Facebook Facebook (Zhiyun Support) (Zhiyun Tech) Youku Youtube Wechat Instagram...
- Page 26 E-mail: info@zhiyun-tech.com Address: 09 Huangtong Road, Tieshan Industrial Zone, Qixing District, Guilin, 541004, Guangxi, China For full product information, please visit ZHIYUN's official website: Content on www.zhiyun-tech.com is subject to update without notice. ZHIYUN ™ is a trademark of ZHISHEN All product names or brands referred to hereunder may be trademarks or registered trademarks of their respective holders.
