DOC No. 47232
1 -
TROUBLESHOOTING ASSISTANCE PROGRAMME
T1
T2
T3
1.1. - Important instructions
Connect (where possible) an ammeter to the oven's power supply.
Run the troubleshooting assistance programme in full.
Note any anomalies observed during the troubleshooting assistance programme.
Then check and replace where necessary the component(s) implicated.
Check the correct operation of the appliance by running the troubleshooting assistance
programme again.
1.2. - Starting situation
•
Connect the appliance.
•
When switching on the appliance for the first time, the screen displays the language
•
Otherwise, set the time to 12:00
•
Press K1
•
Press the keys of the display T1, T2, one after the other and press and hold T3.
1.3. -
Troubleshooting assistance programme procedure
Step
The TAP starts with the display in test
D1
mode.
Press once on the "K1"
2
key
DATE: 02/10/2017
Actions and display
TROUBLESHOOTING ASSISTANCE
PROGRAMME
•
•
PRODUCT:
LX MULTI PYRO DX2
STEAMER 30% OVEN
Result
Displays the different possible
modes.
Select the relevant mode.
Backlight test (black screen).
The tray comes out
automatically
Continue the TAP
K1
Advertisement
Related Manuals for Brandt LX MULTI PYRO DX2
Summary of Contents for Brandt LX MULTI PYRO DX2
- Page 1 TROUBLESHOOTING ASSISTANCE PROGRAMME PRODUCT: DOC No. 47232 DATE: 02/10/2017 LX MULTI PYRO DX2 STEAMER 30% OVEN TROUBLESHOOTING ASSISTANCE PROGRAMME 1.1. - Important instructions Connect (where possible) an ammeter to the oven's power supply. Run the troubleshooting assistance programme in full.
- Page 2 TROUBLESHOOTING ASSISTANCE PROGRAMME PRODUCT: DOC No. 47232 DATE: 02/10/2017 LX MULTI PYRO DX2 STEAMER 30% OVEN Step Actions and display Result • Backlight test (alignment + colour) Press once on the “T1” Continue the TAP • Test the K1 knob...
- Page 3 TROUBLESHOOTING ASSISTANCE PROGRAMME PRODUCT: DOC No. 47163 DATE: 02/10/2017 C45 MULTI PYRO DX2 STEAMER OVEN Step Actions and display Result • Operation of the ventilated element ° Press once on the “T1” generator 3300W Continue the TAP • Operation of motor-driven fan and lamp Press once on the “T1”...
- Page 4 TROUBLESHOOTING ASSISTANCE PROGRAMME PRODUCT: DOC No. 47163 DATE: 02/10/2017 C45 MULTI PYRO DX2 STEAMER OVEN Select CLEAN then DRAIN Select "speed" = 20s drainage or "auto" = 3'19'' drainage max. 1.6. - Steam cooking and water consumption: The oven is horizontal The oven is at room temperature Put 1 litre of water in the tank (maximum capacity) -->...
