Measurement techniques Setup for most tests Constant Voltage (CV) verification CV load and line regulation Constant Current (CC) verification Test Record Forms Test record form - Keysight EDU36311A Calibration Adjustment Procedures Closed–case electronic calibration Calibration interval Calibration adjustment process Calibration security...
Page 3
Save the calibration data Keysight EDU36311A Service Guide...
No part of this manual may be reproduced in any form or by any means (including electronic storage and retrieval or translation into a foreign language) without prior agreement and written consent from Keysight Technologies as governed by United States and international copyright laws.
Declarations of Conformity Declarations of Conformity for this product and for other Keysight products may be downloaded from the Web. Go to https://regulations.about.keysight.com/DoC/default.htm. You can then search by product number to find the latest Declaration of Conformity.
A WARNING notice denotes a hazard. It calls attention to an operating procedure, practice, or the like that, if not correctly per- formed or adhered to, could result in personal injury or death. Do not proceed beyond a WARNING notice until the indicated con- ditions are fully understood and met. Keysight EDU36311A Service Guide...
To Replace the Power-Line Fuse User Replaceable Parts Battery Replacement Disassembly This chapter provides the specifications and service information on cleaning, troubleshooting, repair, and replaceable parts of the EDU36311A. This chapter also explains how to assemble and disassemble the EDU36311A. Keysight EDU36311A Service Guide...
Types of service available If your instrument fails during the warranty period, Keysight Technologies will repair or replace it under the terms of your warranty. After your warranty expires, Keysight offers repair services at competitive prices. You also have the option to purchase a service contract that extends the coverage after the standard warranty expires.
If required, contact a Keysight Technologies Sales and Service office to arrange for proper cleaning to ensure that safety features and performance are maintained. Electrostatic Discharge (ESD) precautions Almost all electrical components can be damaged by electrostatic discharge (ESD) during handling. Component damage can occur at electrostatic discharge voltages as low as 50 V.
Replacing the Power-Line Fuse Refer to EDU36311A User's Guide for details. User Replaceable Parts You can find the instrument support part list at Keysight's Test & Measurement Parts Catalog http://www.keysight.com/find/parts. Battery Replacement SHOCK HAZARD Only qualified, service-trained personnel who are aware of the hazards involved should remove instrument cov- ers.
Page 11
(see red circle below) and push down on the opposite end of the battery (see red arrow below) to seat the bat- tery. 5. Reassemble the front panel when finished. 6. Reset the date and time. Properly dispose of the old battery in accordance with local laws and regulations. Keysight EDU36311A Service Guide...
Then, remove the rubber foot from the instrument. Remove two screws (M3x6) with T10 Torx driver that holds the front panel and the chassis cover. On the rear panel, remove three screws (M3x6) with T10 Torx driver. Pull out the chassis cover. Keysight EDU36311A Service Guide...
Page 13
Remove six screws (M3x6) from the metal handle support. Remove three screws (M3x6) from the rear panel board. Lift up the metal handle support. Open the clip and remove the rear panel board from the metal handle support. Keysight EDU36311A Service Guide...
Page 14
See image (B). Pull out the front panel. Disconnect all the cables from the main board. The front panel is removed. To install back the front panel, perform the above steps in reverse order. Keysight EDU36311A Service Guide...
Insert the stainless steel belt into the PVC strap. Insert the stainless steel gaskets to both side of the stainless steel belt. Cover both side with the plastic cap. Secure both side of the strap handle with two screws (M5x10) using T25 Torx driver. Keysight EDU36311A Service Guide...
Test Record Forms Calibration Adjustment Procedures This chapter contains the performance verification procedures which verify that the EDU36311A is operating within its published specifications. This chapter also provides information on adjustments performed after a performance verification fails. Keysight EDU36311A Service Guide...
150 V, 5 A minimum, with transient capability and a slew rate of Keysight N3300A mainframe, with 833 kA/s or better. N330xA modules LAN / USB controller PC with Keysight Connection Expert loaded Oscilloscope Sensitivity: 1 mV; Bandwidth Limit: 20 MHz Probe: 1:1 with RF Keysight DSOX1202A oscilloscope or...
This setup is used for most tests and it requires the DMM, electronic load, and power supply being verified. Some wire is also required for connection between instruments. A LAN or USB cable is needed for readback data. The Keysight EDU36311A Service Guide...
SCPI MEAS:VOLT? (@<channel>) This is an example for 6 V, 5 A output. 10. Record the voltage returned by the SCPI command query via Keysight Connection Expert, and verify whether it is within the limits calculated. Keysight EDU36311A Service Guide...
8. Take the difference between the DMM readings in steps 6 and 7 that is the CV load regulation (V load – V noload ). The difference of the readings during the immediate change should be within the specification limits. Keysight EDU36311A Service Guide...
Page 21
10. Take the difference between the DMM readings in steps 8 and 9 that is the CV line regulation (V lowline – V high- line ). The difference of the readings during the immediate change should be within the limit calculated from the specification. Keysight EDU36311A Service Guide...
Page 22
7. Adjust the oscilloscope to display transients as shown below. Note that the pulse width (t2-t1) of the transient at the voltage settling band, for example 15 mV for Output 1 from the base line is no more than 50 µs. Keysight EDU36311A Service Guide...
Page 23
The oscilloscope cursors AX and BX represent t1 and t2. The oscilloscope green trace and yellow trace represent output current and output voltage trace. 8. Transient response specification is met when the voltage recovers within 50 μs. Keysight EDU36311A Service Guide...
SCPI MEAS:CURR? (@<channel>) This is an example for 6 V, 5 A output. 11. Record the current returned by the SCPI command query via Keysight Connection Expert, and verify whether it is within the limits calculated. Keysight EDU36311A Service Guide...
Page 25
8. Take the difference between the current readings in steps 6 and 7 is the load regulation current (I load – I short ). The difference of the readings during the immediate change should be within the specification limits. Keysight EDU36311A Service Guide...
Page 26
9. Take the difference between the DMM readings in steps 7 and 8 is the CC line regulation (I lowline – I highline ). The difference of the readings during the immediate change should be within the specification limits. Keysight EDU36311A Service Guide...
Test Record Forms Test record form - Keysight EDU36311A Test record form - Keysight EDU36311A EDU36311A Report Number ____________ Date ______________ Description Outputs Lower limit Result Upper limit Constant Voltage Tests Voltage Programming Zero Voltage Output (V 0 ) Output 1 -0.005 V...
Page 28
Current Programming & Readback, Maximum Current (I max ) 5 A, 6 V 1 A, 30 V 1 A, 30 V CC Load Regulation and Line Regulation 5 A, 6 V 1 A, 30 V 1 A, 30 V Keysight EDU36311A Service Guide...
Calibration Adjustment Procedures This chapter includes calibration adjustment procedures for Keysight EDU36311A power supply. Instructions are applicable for performing the procedures from either the front panel or a controller over the LAN or USB. Perform the verification tests before calibrating your instrument. If the instrument passes the verification tests, the unit is operating within its calibration limits and does not need to be re-calibrated.
You can use the CALibration:STRing command to store a message of up to 40 characters in calibration memory. For example, you could store the last calibration date, the calibration due date, or contact information for the person Keysight EDU36311A Service Guide...
To change a forgotten passcode to a new passcode, you can turn on the instrument CAL:SEC:CODE <code> after shorting CAL SECURE jumper J1 on the front panel board and send scpi com- mand to change the passcode. Keysight EDU36311A Service Guide...
After completing the Voltage and Current calibrations, save the calibration data before exiting the calibration state, or simply exit the calibration state if Auto Save is on. To save the CAL data: CAL:SAVE To enable the CAL Auto Save: CAL:ASAVE ON To exit CAL State: CAL:SEC:STAT 1, <code> Keysight EDU36311A Service Guide...
