MXP7000
QUICK START GUIDE 1
2
3
4
1 Antenna
6
5
2 LTE/Device Status LED
7
3 TETRA Status LED
8
4 Front Camera
17
5 Front Microphone
6 Ambient Light Sensor
19
(ALS)
9 7 Earpiece Speaker
20
8 Touch Screen Display
9 Front Speaker and 21
Microphone
10 Rotary Knob
11
10
11
Emergency Button
13
12
12 Rear Microphone
13 Rear Camera with Flash
14
14 Battery Latch
15 8
15 Lithium-Ion Battery
Looking After Your Radio
Never leave your radio or battery in extreme temperatures (over
+85°C). For example, behind a windscreen in direct sunlight.
The radio is submersible (compliant with the IP67 standard), but
only with the battery and antenna attached.
To clean your radio, use a moistened or antistatic cloth.
Ensure that no contamination is on the gore port membrane that
is the area labelled as VENT on the back of the radio chassis.
16 Lanyard Hole
Optimal Audio Performance
16
17 Power Button and Screen
Lock/Unlock The radio has three microphones:
18
• A top front microphone for Simplex group, dispatcher, or private
18 GCAI-Mini Connector
calls.
19 Push-To-Talk Button (PTT)
• A top back microphone for optional noise cancellation.
20 One Touch Button 1
• A bottom microphone for Duplex, telephone-like calls.
21 One Touch Button 2
22
USB-C Connector 1. When using high audio, hold your radio
22
vertically with the top microphone 5–10
23 Charging Contacts
cm away from your mouth.
2. Speak into the top microphone.
3. Listen through the speaker.
23
1. When using low audio, hold your radio
as you would a telephone.
2. Speak into the bottom microphone.
3. Listen through the earpiece.
Attaching the Antenna
1. Insert the threaded base of the
antenna into the antenna
terminal on top of your radio.
2. Turn the antenna clockwise until
it is tight.
Installing the Battery
2
1
1. Insert the battery into the compartment until the contacts
align and the battery hooks in place.
2. Press down on the battery until it clicks in place.
Removing the Battery
5–10 cm
1
Simplex Calls
2
1. Slide the Battery Latch to the right and hold it until you can lift
the battery out.
2. Lift the battery from the top and pull the battery upwards to
Duplex Calls
disengage it from the battery hooks.
3. Remove the battery from the compartment.
3
