HOMCOM RFS-05R Assembly Instruction Manual page 3

PERFORMANCE PARAMETERS
Model Rating Power
RFS- 05R 220~240V 50Hz
FUNCTIONS
l Principle of Cooling: Water is taken from the water tank by pump to the top,
then the water drops into paper evaporator . When the water in paper
evaporator evaporates to water vapor, the air is cooled. People will feel cool
wind when the cool air is delivered by fan.
l Electronics control: safe and durable, attractive appearance.
l Adjustable speed and fan mode: have three speeds and fan types, blow at a
wide angle.
l Cool: adopt the technology of ice crystal cooling and air humidifying, fall down
the temperature from air vent and raise relative humidity, prevent air drying.You
could put the ice box into the top tank and down tank to make the cooling be
better.
l Deliver wind at a wide angle: swing the blades automatically, deliver wind at
horizontal wide angle. Swing the blades transversely manually, select the
direction discretionarily.
l Far-range remote control: 6 meters far-range remote control, receive at 60
degree wide angle.
l Buzzer: vocalise when operating the effective keypad, use conveniently.
ASSEMBLING AND WATERING
Watering: pull 1/3 water tank, then add clean water (map 1)
Attention:
a. Pay attention to the level of water tank when add water.(map 2)
b. The level of water tank should not over "MAX" scale at any time, when
humidifying, the total level of water tank should not below "MIN" scale.
c. Put ice or frozen ice box to the water tank if you want to strengthen the
efficiency of cooling. But the total level of water tank should not over "MAX"
scale.
MAP 1
Power Max Water Injection Rate
75W
MAP 2
2
Specification
Cooling only
4L
MAP 3
EN
