Sigenergy SigenStor Home Installation Manual

Three-phase system a1
Hide thumbs Also See for SigenStor Home:

Advertisement

Quick Links

Download this manual
SigenStor Home
Installation Guide
Three-phase System
A1
Version: 03
Release date: 2024-05-31

Advertisement

loading
Need help?

Need help?

Do you have a question about the SigenStor Home and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sigenergy SigenStor Home

Summary of Contents for Sigenergy SigenStor Home

  • Page 1 SigenStor Home Installation Guide Three-phase System Version: 03 Release date: 2024-05-31...
  • Page 2 • Trained or experienced electrical personnel are required to operate the equipment. • Operators should be familiar with national and local laws, regulations, and standards, and the compositions and operating principles of relevant systems. • Please read carefully the operating requirements and precautions in this document and “Important Notice” before operating. Failure to do so may result in damage to the equipment that is not covered by the warranty.
  • Page 3 S/N Equipment/component Model/version Function specification PV module – – SigenStor EC SigenStor EC Inverter; it can be used in photovoltaic energy storage scenarios and needs to be 5.0/6.0/8.0/10.0/12.0/15.0/17.0/20.0/25.0 TP used together with PV modules and SigenStor BAT. SigenStor AC SigenStor AC Inverter;...
  • Page 4 S/N Equipment/component Model/version Function specification H Diesel generator – As a backup energy source for long-term off-grid applications, it can work in tandem with the Gateway to provide a smooth transition between PV, storage and diesel generation. Smart loads – All the power equipment in the owner's home can be connected as smart loads.
  • Page 5 1.2 Appearance and Dimensions 1.3 Port Descriptions Inverter and battery pack SigenStor EC/SigenStor AC/Sigen Hybrid Left View SigenStor EC/SigenStor AC/Sigen Hybrid SigenStor BAT SigenStor BAT S/N Name Marking Decorative cover light strip connector Network interface RJ45 1/ RJ45 2 Base DC input interface PV1+/PV2+/ PV3+/PV4+/ PV1- Angle Bracket...
  • Page 6 2 Pre-installation Check • Check whether the components are entirely supplied against the packing list and whether the appearance is in good condition. For any problem, contact your sales representative. • Parts and accessories supplied with the packing box are personal assets of the owner and must not be taken away from the installation site. •...
  • Page 7 • The specifications of the Installer-provided cable must comply with the cable regulations and standards of the country or region standards. • L1, L2, L3, N and PE should be connected to other equipment in sequence without mixing. Installer-provided cable Cable name Recommended specifications Protective ground cable of...
  • Page 8 Cable name Recommended specifications RS485 signal cable Outdoor two-core shielded twisted pair Cross–sectional area of core conductor: 0.5–0.75 mm² (multi–core flexible conductor, Tubular terminal needed) 0.5–1 mm² (single–strand hard conductor, no tubular terminal needed) Outer diameter: 4.5–6.5 mm Cable length: ≤ 1000 m Baud rate: ≤...
  • Page 9 3 Site Selection Requirements The warranty applies when the equipment has been installed properly for its intended use and in accordance with the operating instructions. Installation position Installation environment • Do not tilt or overturn the equipment to ensure that it is installed Do not install the equipment in smoky, flammable, or explosive •...
  • Page 10 Mounting surface • Do not install the equipment on a flammable installation base. • The installation base should meet the load–bearing requirement. Solid brick–concrete structures, concrete walls, and floors are recommended. • The surface of the installation base must be smooth and the installation area must meet the installation space requirements.
  • Page 11 4 Installation of inverter and battery pack There are two installation methods for the Base. Please refer to the actual product received for detailed instructions. • Up to six SigenStor BATs are supported for floor installation and up to two for wall installation. Option 1 •...
  • Page 12 INV1 is the mounting hole on the left side of the inverter for wall installation, while INV2 is the mounting hole on the right side for Option 2 wall installation. Calculation formula for punch height: L1 and L2 should be measured from the upper surface of the base: L1 = N x 270 mm + 261 mm ±...
  • Page 13 Before installing the handle, please use a Torque socket wrench to SigenStor BAT is kept horizontally and mounted vertically measure the screws and confirm that the screws on Sigen BAT are downwards. securely tightened with a torque of 4.5 N·m (±0.45 N·m). •...
  • Page 14 If three or more SigenStor BATs are to be installed, use a Lift. For Arrange SigenStor EC, SigenStor AC or Sigen Hybrid. details about the hoisting rope binding scheme, see the figure. SigenStor EC or SigenStor AC For details, see Step Sigen Hybrid Remove the IP protection cover at the bottom.
  • Page 15 Install the chuck screws of the decorative parts, and arrange them as described in Step The chuck screws are packed in the extension package.
  • Page 16 Base bracket has two versions in terms of appearance. The actual product shall prevail. The installation method for both versions remains the same. Appearance 1...
  • Page 17 Appearance 2...
  • Page 18 Steps are optional and can effectively prevent theft.
  • Page 19 4.2 Wall Mounting There are two installation methods for the Angle Bracket. Please refer to the actual product received for detailed instructions. Option 1 Wall Option 2 Wall...
  • Page 20 For details about how to place the SigenStor BAT, see Steps in Section 4.1 Floor installation. Calculation formula for punch height: For details about how to place the inverter, see Steps in Section L1 and L2 should be measured from the upper surface of the base: 4.1 Floor installation.
  • Page 21 5 Cable Connection and Component Installation Scheme II Before connecting cables, ensure that DC SWITCH is in the OFF state, and • the front switch of the AC line is off. • Do not perform operations on the equipment with power on. Before operation, please make sure all power supplies to the equipment have been disconnected, including but not limited to the grid side, inverter and diesel generator power...
  • Page 22 5.2 Protective Ground Cable of Inverter 5.3 AC Output Cable of Inverter The protective ground wire should be grounded in close proximity. The AC interface on the inverter is available in three appearances, Please select the appearance as needed. Appearance 1 Appearance 2 Appearance 3...
  • Page 23 Appearance 1 Only SigenStor EC / SigenStor AC / Sigen Hybrid (15.0 – 25.0) TP requires Inner hexagon cold shrink tube. (M5 socket) ≤ 60 mm Unit: mm (Optional) (Optional) Cold shrink tubes (Optional) Cold shrink tubes SigenStor EC / SigenStor AC / Sigen Hybrid (5.0 – 12.0) TP : (Optional) SigenStor EC / SigenStor AC / Sigen Hybrid (15.0–...
  • Page 25 Appearance 2 Click...
  • Page 27 Appearance 3 Outer hexagon (8 mm socket) ≤ 60 mm 20 mm ≤ ≤ 30 mm...
  • Page 29 5.4 COM terminal of the inverter introduction • The power sensor needs to be purchased from our company's official channels. The appearance and specific wiring of the power sensor can be • found in the instruction manual delivered with the case. Description Interface definition COM terminal of...
  • Page 30 5.4.1 RS485 Signal Cable of inverter Click Unit: mm Shielding layer Click 20–25 12–14...
  • Page 31 5.4.2 (Optional) Ripple Control Receiver connection Click Unit: mm Click After creating new systems, you can use the mySigen App to set the parameters for Active Dry Contact scheduling or Reactive Dry Contact scheduling. For specific operation steps, please refer to Chapter 2.3 of the mySigen App Installer Manual.
  • Page 32 5.5 DC input cable of inverter Please make sure that the circuit breaker on the PV side is • electrically neutral before connection. • The DC cable is connected to the inverter from the PV string. Ignore this section in case of SigenStor AC inverters. Positive metal terminal 8-10 mm If the voltage is negative, the polarity is incorrect.
  • Page 33 5.6 RJ45 Cable of inverter • RJ45 cables are EIA/TIA 568B standard cables. • Two RJ45 Ethernet ports, one is connected to the router, and the other is connected to other equipment.(e.g., inverter, Gateway etc.) ① White orange ② Orange ③...
  • Page 34 5.8 Sigen CommMod Installation 5.7 (Optional) Replacing SIM card of Sigen CommMod Sigen CommMod is required for 4G communication. • Skip this step when a single inverter is installed. • You must replace the SIM card in Sigen CommMod with a SIM card of your country or region when multiple inverters are S/N Indicator Description...
  • Page 35 5.8 WLAN antenna stick Installation 6 Post-installation Check Check Item WLAN communication requires the installation of WLAN antenna • The equipment has been securely installed. stick. • To ensure good communication, tighten the antenna rod up Ground cables, DC cables, signal cables, etc. are installed clockwise.
  • Page 36 7 Installation of the Decorative Cover Male connector Female connector The end waterproofing plug Click for the strip light • The end waterproofing plug for the strip light in step is at the lower end of the decoration on the left side of the inverter, please remove it for spare. If the strip light display is abnormal after the device is power-on, please check whether the pin in the male connector is tilted.
  • Page 37 8 Equipment Power-On 1. Turn on the upstream switch of equipment. Indicator Color State Description 2. Rotate DC SWITCH to ON. (This step is not necessary for SigenStor AC) Always on All SigenStor BATs are connected 3. Observe the indicators on the front side of the inverter to learn about but not running.
  • Page 38 After powering on the equipment, install the remaining decorative covers. If the installation fails even when you strictly follow the installation instructions, properly adjust the tightness of the chuck screw, as shown in the figure. Chuck screw...
  • Page 39 9 Download and create new system for mySigen APP Please enter the “Partner" → “Register Now" at the Company's official website (https://www.sigenergy.com), and complete the account registration based on facts. Download the mySigen App and create new system for the device.
  • Page 40 Already connected to the internet: Daylight Saving Time V100R001C21TPC101B031 Manually locate the You can manually set Perform upgrades where and modify some address, set the necessary. function parameters of Timezone, and enter the power station. Owner Details. Upon completion of the new system creation, the installer shall inform the owner to check its "sigencloud" e-mail within 24 hours and proceed with activating its account.
  • Page 41 Not connected to the internet (that is, FE and 4G communication fault): If the equipment has already been connected to the internet, click this button and go to the Create New System page and perform operations by referring to the description in the "already connected to the internet"...
  • Page 42 Daylight Saving Time V100R001C21SPC101B031 Manually locate the You can manually set Perform upgrades where and modify some address, set the necessary. function parameters of Timezone, and enter the power station. Owner Details. Upon completion of the new system creation, the installer shall inform the owner to check its "sigencloud" e-mail within 24 hours and proceed with activating its account.
  • Page 43 Sigenergy Technology Co., Ltd. Copyright © Sigenergy Technology Co., Ltd. 2024. All rights reserved. Description in this document may contain predictive statements regarding financial and operating results, product portfolio, new technology, configurations and features of product. Several factors could cause difference between actual results and those expressed or implied in www.sigenergy.com...
