SigenStor-5S-(5-16),
SigenStor-6S-(8-24)
Installation Guide
Version: 01
Release date: 2024-08-01

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SigenStor-5S-5 and is the answer not in the manual?

Questions and answers

Summary of Contents for Sigenergy SigenStor-5S-5

  • Page 1 SigenStor-5S-(5-16), SigenStor-6S-(8-24) Installation Guide Version: 01 Release date: 2024-08-01...
  • Page 2: Product Description

    1 Product Description Model Designation Appearance and Dimensions Model Inverter model Number of Number of SigenStor EC SigenStor BATs SigenStor BATs SigenStor-5S-5 SigenStor-5S-8 SigenStor BAT SigenStor-5S-10 SigenStor EC 5.0 SP SigenStor-5S-13 SigenStor-5S-16 SigenStor-6S-8 SigenStor BAT SigenStor-6S-10 SigenStor-6S-13 SigenStor EC 6.0 SP...
  • Page 3: Port Descriptions

    1.3 Port Descriptions SigenStor EC Left View Modular Floating Stacked Connector S/N Name Marking DC switch DC SWITCH Decorative cover light strip connector LED Antenna interface Cable interface RJ45 1/ RJ45 2 AC output interface Ground screw – Meaning Communication interface BAT- Sigen CommMod interface Communication interface...
  • Page 4: Pre-Installation Check

    2 Pre–installation Check • Check whether the components are entirely supplied against the packing list and whether the appearance is in good condition. For any problem, contact your sales representative. • Parts and accessories supplied with the packing box are personal assets of the owner and must not be taken away from the installation site. •...
  • Page 5 • The specifications of the Installer–provided cable must comply with the cable regulations and standards of the country or region standards. • L, N and PE should be connected to other equipment in sequence without mixing. Installer–provided cable Cable name Recommended specifications Protective ground cable of inverter housing Outdoor single core copper cable...
  • Page 6: Site Selection Requirements

    3 Site Selection Requirements • The equipment can be installed indoors and outdoors. Install the equipment in strict accordance with installation instructions given in this section and local laws and regulations. • The warranty applies when the equipment has been installed properly for its intended use and in accordance with the operating instructions. •...
  • Page 7 Mounting surface • Do not install the equipment on a flammable installation base. • The installation base should meet the load–bearing requirement. Solid brick–concrete structures, concrete walls, and floors are recommended. • The surface of the installation base must be smooth and the installation area must meet the installation space requirements. •...
  • Page 8: Floor Installation

    4 Installation of inverter and battery pack There are two installation methods for the Base. Please refer to the actual product received for detailed instructions. • For floor installation of SigenStor-6S-24, please use a crane to Option 1 install the 3rd SigenStor BAT. If the floor is prone to stagnant water, please set up a •...
  • Page 9 This step applies only to SigenStor-6S-24. Skip this step for other Option 2 models. INV1 is the mounting hole on the left side of the inverter for wall installation, while INV2 is the mounting hole on the right side for wall installation.
  • Page 10 Before installing the handle, please use a Torque socket wrench to SigenStor BAT is kept horizontally and mounted vertically measure the screws and confirm that the screws on Sigen BAT are downwards. securely tightened with a torque of 4.5 N·m (±0.45 N·m). •...
  • Page 11 This step applies only to SigenStor-6S-24. Skip this step for other For information on how to place SigenStor EC, please refer to models. step To install three or more SigenStor BATs, please use a crane. During lifting operations, the area where the sling comes in contact with the equipment should be wrapped with a protective layer to avoid damage to the equipment.
  • Page 12 Base bracket has two versions in terms of appearance. The actual product shall prevail. The installation method for both versions remains the same. Appearance 1...
  • Page 13 Appearance 2...
  • Page 14 This step applies only to SigenStor-6S-24. Skip this step for other models. Steps are optional and can effectively prevent theft.
  • Page 15 4.2 Wall Installation There are two installation methods for the Angle Bracket. Please refer to the actual product received for detailed instructions. Option 1 Wall Option 2 Wall...
  • Page 16 For details about how to place the SigenStor BAT, see Steps in Section 4.1 Floor installation. Calculation formula for punch height: For details about how to place the inverter, see Steps in Section L1 and L2 should be measured from the upper surface of the base: 4.1 Floor installation.
  • Page 17 5 Cable Connection and Component Installation Scheme II • Before connecting cables, ensure that DC SWITCH is in the OFF state, and the front switch of the AC line is off. • Do not perform operations on the equipment with power on. Before operation, please make sure all power supplies to the equipment have been disconnected, including but not limited to the grid side, inverter and diesel generator power switches.
  • Page 18 5.2 Protective Ground Cable of Inverter 5.3 AC Output Cable of Inverter The protective ground wire should be grounded in close proximity. Unit: mm...
  • Page 19 Click...
  • Page 20 5.4 COM terminal of the inverter Introduction • Power sensors need to be purchased from our official channel. • The appearance and specific wiring of the power sensor can be found in the instruction manual delivered with the case. • According to AS/NZS 4777.2:2020+A1:2021, connecting SigenStor to the power grid must meet the Demand Response Mode (DRM) function, of which DRM0 is mandatory.
  • Page 21 5.4.1 RS485 Signal Cable of inverter Click Unit: mm Shielding layer Click 20–25 12–14...
  • Page 22 5.4.2 Demand Response Enabling Device (DRED) Connection Click Unit: mm Click • Switches S5a, S1a, and S9 of DRED are normally closed and S0 is used to control the power on and off of SigenStor. When S0 closes, SigenStor is powered off, and when S0 opens, SigenStor is powered on. •...
  • Page 23 5.5 RJ45 Cable of Inverter 5.6 (Optional) Replacing SIM card of Sigen CommMod • RJ45 cables are EIA/TIA 568B standard cables. If 4G communication is required, Sigen CommMod must be • • Two RJ45 Ethernet ports, one of which is connected to the router, and separately purchased.
  • Page 24 5.8 WLAN antenna stick Installation 5.7 Sigen CommMod Installation Sigen CommMod is required for 4G communication. Sigen CommMod WLAN communication requires the installation of WLAN antenna • must be separately purchased. stick. • To ensure good communication, tighten the antenna rod up clockwise.
  • Page 25 5.9 DC input cable of Inverter Please make sure that the circuit breaker on the PV side is • electrically neutral before connection. • The DC cable is connected to the inverter from the PV string. Positive metal terminal 8–10 mm •...
  • Page 26: Post-Installation Check

    6 Post–installation Check Check Item The equipment has been securely installed. Ground cables, DC cables, signal cables, etc. are installed accurately without leftovers. The cable fastening screws or terminals are properly installed. There are no sharp spikes or acute angles at the cut point of the cable tie.
  • Page 27 7 Installation of the Decorative Cover Male connector Female connector The end waterproofing plug Click for the strip light • The end waterproofing plug for the strip light in step is at the lower end of the decoration on the left side of the inverter, please remove it for spare. If the strip light shows abnormal status when the device is powered on, check if the pins in the male connector are tilted.
  • Page 28: Equipment Power-On

    8 Equipment Power–On 1. Turn on the upstream switch of equipment. Indicator Color State Description 2. Rotate DC SWITCH to ON. 3. Observe the indicators on the front side of the inverter to learn about Always on All SigenStor BATs are connected the equipment status.
  • Page 29 After powering on the equipment, install the remaining decorative covers. Chuck screw...
  • Page 30 9 Download and create new system for mySigen APP Please enter the “Partner" → “Register Now" at the Company's official website (https://www.sigenergy.com), and complete the account registration based on facts. Download the mySigen App and create new system for the device.
  • Page 31 Already connected to the internet: Daylight Saving Time Manually locate the You can manually set Perform upgrades and modify some address, set the where necessary. function parameters of Timezone, and enter the power station. Owner Details. Upon completion of the new system creation, the installer shall inform the owner to check its "sigencloud" e–mail within 24 hours and proceed with activating its account.
  • Page 32 Not connected to the internet (that is, FE and 4G communication fault): If the equipment has already been connected to the internet, click this button and go to the Create New System page and perform operations by referring to the description in the "already connected to the internet"...
  • Page 33 Daylight Saving Time Manually locate the You can manually set Perform upgrades and modify some address, set the where necessary. function parameters of Timezone, and enter the power station. Owner Details. Upon completion of the new system creation, the installer shall inform the owner to check its "sigencloud" e–mail within 24 hours and proceed with activating its account.
  • Page 34 Sigenergy Technology Co., Ltd. Copyright © Sigenergy Technology Co., Ltd. 2024. All rights reserved. Description in this document may contain predictive statements regarding financial and operating results, product portfolio, new technology, configurations and features of product. Several factors could cause difference between actual results and those expressed or implied in www.sigenergy.com...
