Sigenergy SigenStor-5S-5 Installation Manual

Hide thumbs Also See for SigenStor-5S-5:

Advertisement

Table of Contents

SigenStor-5S-(5-16), SigenStor-6S-(8-24)
Installation Guide
Version: Draft A
Release date: 2024-06-01

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SigenStor-5S-5 and is the answer not in the manual?

Questions and answers

Related Manuals for Sigenergy SigenStor-5S-5

Summary of Contents for Sigenergy SigenStor-5S-5

  • Page 1 SigenStor-5S-(5-16), SigenStor-6S-(8-24) Installation Guide Version: Draft A Release date: 2024-06-01...

  • Page 2: Product Introduction

    Product Model No. SigenStor-5S-(8-40) Model No. Energy Controller Model No. of SigenStor No. of SigenStor Bat 5.0 Bat 8.0 SigenStor-5S-5 SigenStor EC 5.0 SP SigenStor-5S-8 SigenStor EC 5.0 SP The SigenStor- SigenStor-5S-10 SigenStor EC 5.0 SP SigenStor EC 5.0 SP 5S-16 serves as SigenStor-5S-13 SigenStor EC 5.0 SP...
  • Page 3 SigenStor EC 5.0/6.0 SP Left View S/N Name Marking DC switch DC SWITCH Decorative cover light strip connector Antenna interface Cable interface RJ45 1/ RJ45 2 AC output interface Ground screw Communication interface Sigen CommMod interface DC input interface PV1+/PV2+/ PV1-/PV2- Switch button ON/OFF...

  • Page 4: Pre-Installation Check

    2 Pre-installation Check According to the packing list, check whether the components are complete and in good appearance. If any abnormality occurs, contact your • sales agent in time. • Check personal protective equipment and installation tools to ensure that they are complete; If not, please make them up. •...
  • Page 5 Installer-provided cable Cable name Recommended specifications Protective ground cable of inverter housing Outdoor single-conductor copper cable Cross-sectional area of core conductor: 4–6 mm²; Outer diameter: 4–8 mm AC cable The inverter connected to the Outdoor three-core copper cable (L, N, PE) distribution panel Cross-sectional area of core conductor: 4–6 mm²;...

  • Page 6: Equipment Installation

    3 Equipment Installation Mounting surface The warranty applies when the equipment has been installed properly for its Do not install the equipment on a flammable carrier. • intended use and in accordance with the operating instructions. • The installation carrier must meet load-bearing requirements. Solid brick- concrete structure, concrete walls, and ground are recommended.

  • Page 7: Floor Installation

    4 Installation of inverter and battery pack There are two installation methods for the Base. Please refer to the actual product received for detailed instructions. Option 1: • At least two people are required to install the equipment. Up to six SigenStor BATs are supported for floor installation and up to •...
  • Page 8 INV1 is the hole punching point for the Inverter wall fastener on the left side, and INV2 is the hole punching point for the Inverter wall fastener on the right side. Option 2: SigenStor BAT units L1 length L2 length three 1120–1125 mm 1115–1120 mm...
  • Page 9 Before installing the handle, please use a Torque socket wrench For details about how to place the second SigenStor BATs, see to measure the screws and confirm that the screws on Sigen BAT Steps are securely tightened with a torque of 4.5 N·m (±0.45 N·m). If three or more SigenStor BATs are to be installed, use a Lift.
  • Page 10 Arrange SigenStor EC, SigenStor AC or Sigen Hybrid. SigenStor EC or SigenStor AC For details, see Step Sigen Hybrid Remove the IP protection cover at the bottom, install the chuck screws of the decorative parts, and arrange them as described in Step The chuck screws are packed in the extension package.
  • Page 11 The whole system is stacked and installed as the below picture shows, all the connection of electrical and communication between the controller and the battery packs is through the floating terminal, and the terminal description shows how the connection built. A.
  • Page 12 Base bracket has two versions in terms of appearance. The actual product shall prevail. The installation method for both versions remains the same. Appearance 1:...
  • Page 13 Appearance 2:...
  • Page 15 4.2 Wall Installation There are two installation methods for the tripod. Please refer to the actual product received for detailed instructions. Option 1: Option 2:...
  • Page 16 For details about how to place the SigenStor BAT, see Steps in Section 4.1 Floor installation. SigenStor BAT units L1 length L2 length For details about how to place the inverter, see Steps in Section 580–585 mm 575–580 mm 4.1 Floor installation. 850–855 mm 845–850 mm For the installation of the Base bracket , please refer to Step...
  • Page 17 5 Cable Connection and Component Installation Scheme II Before connecting cables, ensure that DC SWITCH is in the OFF state, and the front switch of the AC line is off. • The cable colors in the figure are used only to distinguish different lines.
  • Page 18 5.2 Protective Ground Cable of Inverter 5.3 AC Output Cable of Inverter When connecting to the Gateway or Distribution panel, L1, L2, L3, and N must The protective ground wire should be grounded in close proximity. be connected in order and cannot be mixed. Unit: mm Unit: mm...
  • Page 19 In the event of a fault, an alarm will be sent via the mySigen App with the description of how to solve the fault. For the meaning of the alarm code, please refer to Alarm List, which explains what e Click ach code means.
  • Page 20 5.4 RS485 Signal Cable If a power sensor is used, one end of the RS485 signal cable is connected to the inverter while the other end to the power sensor. 5.4.1 Introduction to Correspondence COM terminal of the inverter The appearance and specific wiring of the power sensor can be found in the instruction manual delivered with the case.
  • Page 21 5.4.2 DRM (Australia AS4777) COM terminal of According to Australia AS/NZS 4777.2:2020+A1:2021, solar inverters need the inverter to support thefunction of demand response mode (DRM), and DRM0 is a mandatory requirement. DRED Auxillary test Circuit DRED Description Interface definition COM terminal Requirement of the inverter ●...
  • Page 22 5.4.3 RS485 Signal Cable of inverter Unit: mm Shielding layer 0.08–10 mm² Click Click...
  • Page 23 5.5 RJ45 Cable of Inverter 5.6 Sigen CommMod Installation Sigen CommMod is required for 4G communication. • Two RJ45 network ports: One for the router. • RJ45 cables are EIA/TIA 568B standard cable. S/N Indicator Description Power indicator Network • Slow flashing (200ms state on/1800ms off): The network is...
  • Page 24 5.7 WLAN antenna stick Installation 5.8 DC input cable of Inverter The DC cable is connected to the inverter from the PV string. WLAN communication requires the installation of WLAN antenna The equipment is not suitable for using with functionally earthed stick.

  • Page 25: Post-Installation Check

    6 Post-installation Check Check Item The equipment has been securely installed. Ground cables, DC cables, signal cables, etc. are installed accurately without leftovers. The cable fastening screws or terminals are properly installed. There are no sharp spikes or acute angles at the cut point of the cable tie.
  • Page 26 7 Installation of the Decorative Cover The end waterproofing plug for the strip light Click The end waterproofing plug for the strip light in step is at the lower end of the decorative cover on the left side of the inverter, please remove it for spare. •...

  • Page 27: Equipment Power-On

    8 Equipment Power-On 1. Turn on the front switch of the equipment. Indicator Color State Description 2. Rotate DC SWITCH to ON. (This step is not necessary for SigenStor AC) Always on All SigenStor BATs are connected 3. Observe the indicators on the front side of the inverter to learn about the but not running.
  • Page 28 9 Download and create new system for mySigen APP Please enter the “Partner" → “Register Now" at the Company's official website (https://www.sigenergy.com), and complete the account registration based on facts. Download the mySigen App and create new system for the device.
  • Page 29 Daylight Saving Time Scan the SN code label on the accompanying box Locate the address manually If an upgrade is required, material. If the SN is lost, and complete the Total Panel perform the upgrade. scan the SN on the side of Capacity and Owner Details.
  • Page 30 You can manually set and modify some function parameters of the power station. Upon completion of the new system creation, the installer shall inform the owner to check its "sigencloud" e-mail within 24 hours and proceed with activating its account.
  • Page 31 Sigenergy Technology Co., Ltd. Copyright © Sigenergy Technology Co., Ltd. 2023. All rights reserved. Description in this document may contain predictive statements regarding financial and operating results, product portfolio, new technology, configurations and features of product. Several factors could cause difference between actual results and those expressed or implied in www.sigenergy.com...
