  • Page 1 Video-67Pro-3D Multimedia Accelerator User’s Manual version 2.00 COPYRIGHT ©1999 JATON CORPORATION, USA...
  • Page 2 NOTICE The information in this document is subject to change in order to improve reliability, design, or function without prior notice and does not represent a commitment on the part of the company. In no event will the company be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or the inability to use the product or documentation, even if advised of the possibility of such damages.
  • Page 3 Table of Contents 1. INTRODUCTION................ 5 1.1 C ................5 OMPATIBILITY 1.2 C .................. 5 HECK 1.3 F ..................5 EATURES 1.3.1 Resolution and Color Selection ..........9 1.3.2 3D and 2D GUI Accelerator ..........9 1.3.3 VESA DPMS and VESA DDC2B supported ......10 1.3.4 DirectDraw Supported ............10 1.3.5 Geometry Processor.............10 2.
  • Page 4 9.4 T ..............27 ERMS AND ONDITIONS 9.5 S : ..............28 ERVICES AGREEMENT 9.6 E ..............28 NTIRE BLIGATION 10. REDUCING WARRANTY CLAIM REJECTIONS....28...
  • Page 5 1. Introduction Congratulation on your purchase of the Jaton 2D and 3D Graphics & Video Accelerator Video-67Pro. The Video-67Pro uses advanced 3DImàge975x 3D/2D Graphical User Interface (GUI) accelerator with built-in high-speed 24-bit True Color DAC and video acceleration circuitry and Synchronous Graphics RAM and PCI Bus design.
  • Page 6 þ PCI Specification V2.1 compliant I/O Bus þ VESA Super VGA BIOS Extension Standard, VBE Version 2.0 þ Integrated VESA feature connector 2D Graphics Acceleration Optimized single cycle 2D graphics engine with a complete feature set in all 8, 16 and True Color modes: þ...
  • Page 7 þ þ Z-buffering at 16/32 bpp MPEG and Video Acceleration þ On-chip Color Space Conversion (CSC), horizontal and vertical interpolated scaling, and overlay control for 30 fps software MPEG/video CODEC acceleration þ Anti-tear support þ Direct Draw /DCI/ENDIVE acceleration with independent x and y minimization/zoom and color space conversion Graphic Display Colors, Refresh rates and Resolutions*...
  • Page 9 Compatibility þ Pentium® or compatible system with PCI slot þ Interlace or non-interlace analog monitor þ Multi-sync or PS/2 monitors þ VESA DDC1 and DDC2B monitors detection þ PC97 Graphics Compliant Software Driver þ MS Windows®95/98 MS Windows NT ® 4.0 þ...
  • Page 10 1.3.3 VESA DPMS VESA DDC2B SUPPORTED Supports VESA Display Power management Signaling (DPMS) which decreases energy consumption when used with a monitor that meets the VESA standards for power management. Supports VESA DDC 2b standards for automatically selecting the correct display setup on a monitor that meets the VESA DDC standard.
  • Page 11 2. Adapter Installation 2.1.1 A DAPTERS AYOUTS Adapter's Plate Video - 67Pro - 3D PCB - 82067K CON1 DB 15 VGA Display memory Trident 3DImage975x Figure 2-1 8267K Board Layout 2.1.2 H ARDWARE NSTALLATION !! WARNING !! Discharge static electricity by touching the GROUND such as metal part of your case connected with good...
  • Page 12 To install the adapter into your system, follow these steps: 1. Turn OFF all power to your system, including any peripherals (printer, external drives, modem, etc.). 2. Disconnect the power cord and the monitor cable from the back of the computer. 3.
  • Page 13 2. Insert the display Driver CD into your CD-ROM drive (e.g. X:). 3. Autorun file pops up “Welcome” screen from Jaton’ CD. 4. Click on the “Display Driver” selection bar. 5. Tab to the “Settings” then click on “ Advance” button.
  • Page 14 6. Click on “Change”, then “Have Disk”. 7. Path into “X: \V-67Pro\WIN95\Video67P.INF” (X is the letter of your CD-ROM drive), and click OK. 8. The display device selected “Video-67Pro, 3DImàge975 PCI/AGP ( vXXXXXX), then press on OK button. 9. Close and apply to finish PCI’s display driver installation.
  • Page 15 Note: The procedure of display driver installation it required setup with service pack3 (Microsoft® Windows NT™4.0) first. 4. Frequently Asked Questions (FAQ) Q1 Why do we need 3D graphics capability in our PC? Answer 3D technology is becoming increasingly important (and common) not only in games, but also in other applications such as VRML, which allows 3D scene descriptions in Web applications.
  • Page 16 filtering are very intensive operations at the pixel level in terms of CPU operations and demands for memory bandwidth. Without a set-up engine in a graphics controller, the CPU has to calculate the delta values for edges, color, and textures; the drivers need to handle ten (10) times more extensive data.
  • Page 17 Q8 What is the advantage of SGRAM as compared to ordinary DRAM? Answer SGRAM is now capable of running at much higher speeds than Fast Page Mode or EDO DRAM. Also, SGRAM is able to execute a small number of frequently executed operations, such as buffer clears, specific to graphics applications, independently of the controller.
  • Page 18 Problem: Can't display certain modes. Solution A: Run the SVM program (See the User's Guide for more information on the SVM program). If the SVM program fails, go to Solutions B, and C. Solution B: Check to see that there is enough memory on the GUI accelerator to run this mode.
  • Page 19 6. Appendix A: Video Mode Table The adapter’s video modes include all of the following: TABLE 6-1: STANDARD VGA MODE SUPPORT Mode Mode Resolution Resolution Horz Horz Vert Vert Text Text Mode Mode -Colors -Colors Hz Hz Res. Res. Type Type 0h,1h 320x200-16...
  • Page 20 TABLE 6-2: EXTENDED VGA MODE SUPPORT Mode Mode Resolution Resolution Horz Horz Vert Vert Text Res. Text Res. Mode Mode -Colors -Colors Type Type 320x200-256 31.6 512K 40x12 Graph 2Dh_4 320x240-256 43.3 512K 40x15 Graph 2Dh_3 320x240-256 37.5 512K 40x15 Graph 2Dh_2 320x240-256...
  • Page 21 Mode Mode Resolution Resolution Horz Horz Vert Vert Text Res. Text Res. Mode Mode -Colors -Colors Type Type 5Dh_2 640x480-256 37.8 512K 80x30 Graph 5Dh_1 640x480-256 31.4 512K 80x30 Graph 5Eh_3 800x600-256 53.7 512K 100x37 Graph 5Eh_2 800x600-256 46.8 512K 100x37 Graph 5Eh_1...
  • Page 22 Mode Mode Resolution Resolution Horz Horz Vert Vert Text Res. Text Res. Mode Mode -Colors -Colors Type Type 6Eh_1 1024x768-16M 35.5 128x48 Graph 72/3h 640x400-32K/64K 31.6 80x25 Graph 74/5h_4 640x480-32K/64K 43.2 80x30 Graph 74/5h_3 640x480-32K/64K 37.5 80x30 Graph 74/5h_2 640x480-32K/64K 37.8 80x30 Graph...
  • Page 23 7. Appendix B: Pinout and Sync Frequencies 7.1 Analog Color Display Pinouts (DB 15) FUNCTION Red Video 1 Green Video 1 Blue Video 1 Not Used Ground Red Return (ground) Green Return (ground) Blue Return (ground) Vcc (+5v DDC Power) Sync Return (ground) Monitor ID (not used) SDA (DDC support)
  • Page 24 The adapter cable requires a D-shaped 9 pin female connector and a D-shaped 15 pin male connector. TABLE 7-2. 9-TO-15 PIN CONVERSION TABLE 9 PIN SIGNALS PIN NO. 15 PIN SIGNALS PIN NO. Green Green Blue Blue Horz Sync Horz Sync Vert Sync Vert Sync Red Ground...
  • Page 25 Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult an experienced radio/TV technician for help. The user may find the following booklet prepared by the Federal Communications Commission helpful: “How to Identify and Resolve Radio/TV Interference Problems”. This booklet is available from the U.S.
  • Page 26 (30) days from purchase (original invoice date). This Limited Warranty does not cover any incompatibilities due to the user’s computer, hardware, software or any related system configuration in which the Jaton Products interfaces. Proof of purchase will be require before any consideration by Manufacturer occurs. 9.1 Other Limits.
  • Page 27 WARRANTIES, shall not be relied upon by Buyer, and are not a part of the contract for sale or this Limited Warranty. 9.4 Terms and Conditions. Direct Jaton Customer: This warranty applies only for a period of two (2) years from purchase date of Jaton original invoice.
  • Page 28 Others: If the products do not conform to this Limited Warranty (as herein above described), Manufacturer should charge services such as repair, replacement whether based on its costs. Shipping and installation of the replacement Products or replacement parts shall be at User’s expanse.
  • Page 29 • read your manuals before installing peripherals and/or before making changes to the machine’s configuration; • ask your dealer if there are any known problems with the system requirements or installation procedures for any add-on products that your are purchasing; •...
