- Page 1 Video-117PCI-16 Video-117PCI-32 multimedia accelerator User Manual version 1.00 Copyright © 2002 Jaton Corporation, USA.
- Page 2 NOTICE The information in this document is subject to change in order to improve reliability, design, or function without prior notice and does not represent a commitment on the part of the company. In no event will the company be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or the inability to use the product or documentation, even if advised of the possibility of such damages.
-
Page 3: Table Of Contents
1. INTRODUCTION...5 2. FEATURES...6 2.1 PCI B NTERFACE 2.2 P (@800 MH ERFORMANCE 2.3 3D G RAPHICS NGINE 2.4 DVD S ...8 UPPORT 2.5 V ...8 IDEO NGINE 2.6 A DVANCED OWER 2.7 M EMORY NTERFACE 2.8 D 7.0...9 IRECT 2.9 S ...9 OFTWARE... - Page 4 10.2 C ONVERSION ABLE 10.3 9- -15 P ONVERSION 10.4 A NALOG IDEO 11. FCC SHIELDED CABLE WARNING ..42 11.1 T ECHNICAL UPPORT 12. LIMITED WARRANTY..44 12.1 O ...44 THER IMITS 12.2 E XCLUSIVE BLIGATION 12.3 O THER TATEMENTS 12.4 T ERMS AND...
-
Page 5: Introduction
1. Introduction Video-117PCI-16 and Video-117PCI-32 are based on Trident Blade T16/T64 (9970) Graphics Processor with PCI bus and DVD playback. With 128-bit memory bus at 143 MHz clock on PCI bus aggregation, the performance of these multimedia accelerators are beneficial to brings the DVD playback in real-time and the high density... -
Page 6: Features
2. Features 2.1 PCI Bus Interface PCI Bus Support at up to 1.06 GByte/sec transfer rate DMA bus mastering support with Scatter Gather Execute Mode for Direct Textures, Video, and DVD 2.2 Performance (@800 MHz PIII with 32MB of memory) Pixel processing rate: 800 Million pixels/sec Texel access rate: 1,200 Million pixels/sec Supports 16MB/32MB of SDRAM at up to 143 MHz... - Page 7 2.3.1.1.3 Texturing 2.3.1.1.4 2D GUI Single-pass processing of diffused, specular lighting and fog Enhanced Gouraud Shading & Phong-like environmental lighting Fast order-independent scene anti-aliasing support Fully OpenGL-compliant blending including fog & depth cueing Hidden surface removal with 16, 24, or 32-bit Z buffer or W buffer Color format includes 16, 24, or 32-bit per pixel Supports 8-bit stencil buffer...
-
Page 8: Dvd Support
2.4 DVD Support THAMA™ architecture enables full DVD player support Requires no extra frame buffer and minimum PCI bus bandwidth Includes both Motion Compensation and IDCT hardware assist Real-time playback (30fps) of 9.8 Mbps MPEG-2 video bitstream with 80% CPU headroom for other application Alpha blending for subpicture Advanced error recovery &... -
Page 9: Advanced Power Management
Dual color space converters (CSC) Accelerates YUV planar format 2.6 Advanced Power Management 7 GPIOs, suspend and standby modes Internal clock gating on each functional block PCIPM (H/W PCI initiated) AGP Clock Busy/Stop and PCI Clock Run ACPI and DPMS support 2.7 Memory Bus Interface 64-bit SDRAM/SGRAM memory bus at 143 MHz clock Up to 32 Mbytes of local frame buffer... -
Page 10: Check List
OpenGL ICD 1.0 and 1.2 3. Check List The package you have purchased should contain the following: þ Video-117PCI-16, or Video-117PCI-32 multimedia accelerator þ Software and Document CD þ Quick Start Guide (Printed) If any of these items is missing or damaged, contact your dealer. -
Page 11: Hardware Description
TVout optional Composite Video DB 15 VGA S_Video TVout optional Product's Name PCB version Video-117PCI-16 82117K Video-117PCI-32 82117K 6. Hardware installation 6.1 Installation Procedures The manufacturer assumes no liability for any damage, caused directly or indirectly, by improper installation of any components by unauthorized service personnel. -
Page 12: Steps
6.2 Steps: Turn OFF all powers to your system, including any peripherals (printer, external drives, modem, etc.). Disconnect the power cord and the monitor cable from the back of the computer. Unfasten the cover mounting screws on your system and remove the system cover. - Page 13 Autorun feature pops-up “Welcome” screen from software’s CD, click on the "Display Driver" selectable text to start installation.
- Page 14 Tab to “Settings” screen, then click on “ Advance” button.
- Page 15 Click on “Next” button with [Advanced] selectable option.
- Page 16 You may proceed the search wizard with “Display a list of all the driver in a specific location, so you can select the driver you want.” option, then click on “Next” button. Click on “Have Disk…” button to continue.
- Page 17 You may type E:\V-117\Win9x into the dialog box as shown above, or browse on CD, unfold these folders; and click on “OK”. (If E is not your CD-ROM drive , substitute E with the correct drive letter.) Wizard has selected “Video-117PCI (Trident Blade T16/T64)” then press on “OK”...
- Page 18 Windows is ready to install the driver for your hardware from CD-ROM drive, please click on “Next” to do so. Windows system transmit all files to your local hard disk drive, please wait until the process is over.
-
Page 19: Microsoft Windows Nt™4.0
10. Click on “Finish” to complete the driver installation. ÿ ÿ 7.1.1 NT™4.0 ICROSOFT INDOWS Windows NT dose not identify the new PCI video adapter, and always placed a default VGA video setting when system boots up. To maximum the video board acceleration and performance, you should install the video driver that is provide from video adapter manufacturer. - Page 20 Autorun feature brings-up “Welcome” screen, CLICK on “Display Driver” selectable text to start the installation.
- Page 21 SELECT the “Settings” tab screen.
- Page 22 SELECT “Change...” button from the Adapter type section. SELECT “Have Disk...” button from the Change Display page.
- Page 23 Microsoft Windows NT 4.0 will prompt you for the correct path where the video files are located. ENTER “E:\V-117\Winnt4\” where E: is the CD ROM drive that the Software & Documents CD has been inserted. If the driver “ Video-117PCI (Trident Video T16/T64)” is listed under the Display list, SELECT the “OK”...
-
Page 24: Microsoft Windows 2000
Windows system has transmit all files to your local hard disk drive, please wait until the process is over. Once all driver files are copied, RESTART Microsoft Windows NT 4.0 for the changes to take effect. SELECT on “OK” to do so. ÿ... - Page 25 Insert the software CD into your CD-ROM drive. Autorun feature pops-up “Welcome” screen as above, click on “Display Driver” selectable text to start the installation. Click on “Next” button to continue.
- Page 26 Click on “Next” button with [Recommended] selectable option. Checked specify a location then click on “Next” button again.
- Page 27 You may type E:\V-117\Win2000 into the dialog box as shown above, or browse on CD, unfold these folders, and click OK. (If E is not your CD- ROM drive, substitute E with the correct drive letter.) Wizard confirms the driver files for hardware from your CD-ROM, click on “Next”...
- Page 28 Click on “Yes” to continue the installation. Windows system has transmit all files to your local hard disk drive, please wait until the process is over. Click on “Finish” button and restart your computer after that.
-
Page 29: Microsoft Windows® Xp
ÿ ÿ 7.1.3 ® XP ICROSOFT INDOWS Microsoft Windows® XP detects this device and placed appropriate display driver from its operating system automatically, it doesn’t matter you have add a new or change the existing one. To maximum the video board acceleration and breadth its performance, you may install the manufacturer display driver as the followings: 1. - Page 30 2. Click on “Next” button to continue. 3. New Hardware Wizard searches device has been install.
- Page 31 4. Click on “Next” button with [Advanced] selectable option. 5. You may type E:\V-117\winxp into the dialog box as shown above, or browse on CD, unfold these folders, and click on “Next” button.
- Page 32 6. Wizard searches for new device and driver files. 7. Click on “Continue Anyway” to keep up the driver installation.
-
Page 33: Technical Assistance (Q & A)
Windows system has transmit all driver files to your local hard disk drive, please wait until the process is over, then click on “Finish” button. 8. Technical Assistance (Q & A) Q: Why is the display shifted or changed sizes when I switch display modes? Some monitors lack auto-sizing features or just do not synchronize properly to the video board output. - Page 34 To display 800x600 resolution at 60Hz refresh rate, the monitor must be capable of synchronizing a 31.5KHz horizontal scan rate (e.g., NEC 2A, 3D). At 72Hz refresh rate, the monitor must be capable of synchronizing a 48.0KHz scan rate (e.g., Sony HG 1304, NEC 4D, 5D, Seiko 1450).
- Page 35 their WEBsite, there are many technical articles to help users with this subject, such as troubleshooting with VXD errors, virus, Fatal exceptions, etc., more details cover on each issue are descriptive and familiar with, and exclusively further to our support. Q: System hangs-up after installing video driver.
-
Page 36: Tips
automatically setup the display frequency without loading video driver. Try to turn it off, or change settings of monitor type in your system. Q: Selection of color, resolution and refresh rate combination that always back to default after restart the system. Accordingly, there must be a bug (defected source-code) in video driver, or in the system. -
Page 37: Standard Modes
9.1 Standard Modes Mode Resolution -Colors 0h,1h 320x200-16 2h,3h 640x400-16 4h,5h 320x200-4 640x200-2 720x350-Mono 320x200-16 640x200-16 640x350-2 640x350-16 640x480-2 640x480-16 320x200-256 Horz Vert 31.4 31.4 31.4 31.4 31.5 31.4 31.4 31.4 31.4 31.4 31.4 31.4 Text Mode Scan Res. Type Type 40x25 Text... -
Page 38: Extended Modes
9.2 Extended Modes Mode Resolution -Colors 640x480-16 640x473-16 640x480-16 1056x350-16 1056x480-16 1056x473-16 1056x480-16 1188x350-16 1188x480-16 1188x473-16 1188x480-16 5Bh_1 800x600-16 640x400-256 5Dh_4 640x480-256 5Dh_3 640x480-256 5Dh_2 640x480-256 5Dh_1 640x480-256 5Eh_3 800x600-256 5Eh_2 800x600-256 5Eh_1 800x600-256 5Fh_5 1024x768-16 5Fh_4 1024x768-16 5Fh_3 1024x768-16 5Fh_2 1024x768-16 5Fh_1... - Page 39 Mode Resolution -Colors 66h_1 1600x1200-256 6Ah_1 800x600-16 640x400-16M 6Ch_4 640x480-16M 6Ch_3 640x480-16M 6Ch_2 640x480-16M 6Ch_0 640x480-16M 6Dh_3 800x600-16M 6Dh_2 800x600-16M 6Dh_1 800x600-16M 66h_2 1600x1200-256 6Eh_5 1024x768-16M 6Eh_4 1024x768-16M 6Eh_3 1024x768-16M 6Eh_2 1024x768-16M 6Eh_1 1024x768-16M 72/3h 640x400-32K/64K 74/5h_4 640x480-32K/64K 74/5h_3 640x480-32K/64K 74/5h_2 640x480-32K/64K 74/5h_1...
- Page 40 Mode Resolution -Colors 3Ch_0 320x240-16M 3Dh_3 400x300-16M 3Dh_2 400x300-16M 3Dh_1 400x300-16M 42/3h 320x200-32K/64K 44/5h_4 320x240-32K/64K 44/5h_3 320x240-32K/64K 44/5h_2 320x240-32K/64K 44/5h_1 320x240-32K/64K 46/7h_4 400x300-32K/64K 46/7h_3 400x300-32K/64K 46/7h_2 400x300-32K/64K 1. VESA mode. Same as 5Bh_1. 2. The “I” and “NI” in the vertical frequency column denote “interlaced” and “Non-interlace”, respectively.
-
Page 41: Pinout And Sync Frequencies
10. Pinout and Sync Frequencies 10.1 Analog Color Display Pinouts (DB 15) Note: Analog monochrome type monitors use green video for all video input and ignore red and blue video. 10.2 Conversion Table: Pin Adapters If you will be using a 9-to-15 pin adapter cable to link your 9 pin monitor connector to the 15 pin accelerator card connector, check Table carefully before you install the cable. -
Page 42: 9-To-15 Pin Conversion Table
10.3 9-to-15 Pin Conversion Table 9 PIN SIGNALS Green Blue Horz Sync Vert Sync Red Ground Green Ground Blue Ground Sync Ground 10.4 Analog Video Signals Black Level = 0 V Full Intensity (White) Level = +0.7 V 11. FCC SHIELDED CABLE WARNING This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. -
Page 43: Technical Support
In the event you have a technical problem with this product, please read the README files in the software CD-ROM. Updated drivers are available through Jaton BBS and Web site. Have following information handy when you contact technical support: þ... -
Page 44: Limited Warranty
(2) years from manufacturing date. This limited warranty applies only to the original purchaser of Jaton Product and is not transferable. This limited warranty does not apply if failure to the Product Registration, or over thirty (30) days from purchase (original invoice date). -
Page 45: Exclusive Obligation
Reseller/ Vendor: Registered User: Others: This warranty applies only for a period of two (2) years from purchase date of Jaton original invoice. This warranty applies only for a period of two (2) years from manufacturing date. This warranty applies only for a period of... -
Page 46: Services Agreement
12.5 Services agreement: (1) All applicants shall completed service request form from Manufacturer. (2) All returned checks would be charged a $20.00 fee by Manufacturer. (3) All repair and replacement services allow 4-6 weeks from the date of receiving by Manufacturer. (4) All products without warranties require service processing fee $20 (payment in advance), which is not refundable. - Page 47 Buy industry standard products where compatibility issue are more likely to surface; If you are unsure about installation for a new product, contact your dealer’s service department. We believe it is important for you to know and understand what your warranty coverage provides and what it does not.
