Victorian Plumbing AREZZO Fitting Instructions Manual
Slim frame fixed bath screen
Hide thumbs
Also See for AREZZO:
- Installation instructions manual (17 pages) ,
- Fitting instructions manual (16 pages) ,
- Installation manual (8 pages)
Subscribe to Our Youtube Channel
Related Manuals for Victorian Plumbing AREZZO
Summary of Contents for Victorian Plumbing AREZZO
- Page 1 Slim Frame Fixed Bath Screen Fitting Instructions Please follow them carefully and leave this manual with end user V1.09.24...
- Page 2 Safety Information for User & Installer Before you begin: We recommend that this product is installed by a qualified tradesperson, Victorian Plumbing Ltd. accept no liability for products incorrectly installed or any damage to the floor, walls, plumbing, glass screen, or personal injury during installation.
- Page 3 Diagram: V1.09.24...
- Page 4 Items included: Description Picture Top Cover Cap Small Cover Cap Rawl Plug ST3.9X35 Screw Profile Channel Seal Glass Panel Seal Insertion Tool Tools Required (Not Included): *Ensure the appropriate PPE is used during installation* Tape Screw Driver Spirit Level Silicone Pencil Drill Measure...
- Page 5 Step 1: • Confirm the position of the ‘Profile’, mark the fixing points to the wall ready for drilling. Ensure the markings are level using a spirit level. Step 2: • Place the ‘Profile’ to one side. Using an appropriate sized drill bit, carefully drill the holes in the wall.
- Page 6 Step 3: • Carefully insert the ‘Glass Panel’ into the ‘Profile’ on the wall, then insert the ‘Channel Seal’ into the gap between the panel and the profile. • Using the ‘Seal Insertion Tool’, ensure the ‘Channel Seal’ is fully inserted into the profile and there are no gaps.
- Page 7 Step 6: • Pipe a fine bead of good quality silicone sealant along the back of the profile edge and bottom of the panel (including where the screen and the profile meet.) • Wipe away any excess silicone with a damp cloth and allow 24 hours for the sealant to fully dry.
- Page 8 Cleaning: Do not use steam cleaners, caustic or aggressive cleaning and scouring agents, cleaners that corrode plastics, or solvents containing acetone, turpentine or neat bleach. • Do not use any cleaning agents, which may corrode aluminium or light alloys. • To prevent damage to glass coating system, do not use glass cleaning pastes and micro-fibre cloths.
