INVERTER
FR-A800-ELV (Elevator function)
INSTRUCTION MANUAL (STARTUP)
FR-A840-00126(3.7K)-00770(30K)-ELV
Thank you for choosing Mitsubishi Electric inverter.
This Instruction Manual (Startup) provides handling information and precautions for use of this product.
Do not use the product until you have full knowledge of the product mechanism, safety information and
instructions.
Please forward this Instruction Manual (Startup) to the end user.
For details on installation, operation, functions, and maintenance, refer to the Elevator Function Manual, the
Instruction Manual (Detailed), and the Safety Stop Function Instruction Manual. The manuals can be downloaded
in PDF form from the Mitsubishi Electric FA Global Website.
https://www.MitsubishiElectric.com/fa/products/drv/inv/support/a800/a800elv.html
1
INVERTER INSTALLATION AND PRECAUTIONS ...................................................... 4
800-ELV
2
WIRING........................................................................................................................... 5
3
FAILSAFE SYSTEM WHICH USES THE INVERTER ................................................. 12
4
PRECAUTIONS FOR USE OF THE INVERTER ......................................................... 12
5
BASIC OPERATION .................................................................................................... 14
6
TROUBLESHOOTING ................................................................................................. 22
7
SPECIFICATIONS........................................................................................................ 24
─CONTENTS─
