Acromag VPX4810-LF User Manual

Vpx pcie pmc/xmc 3u carrier

Advertisement

Quick Links

Xycom VPX4810-LF
Non-Intelligent, Air-Cooled 3U OpenVPX Carrier
Card
A l l t r a d e m a r k s , b r a n d n a m e s , a n d b r a n d s a p p e a r i n g h e r e i n a r e t h e p r o p e r t y o f t h e i r r e s p e c t i v e o w n e r s .
• C r i t i c a l a n d e x p e d i t e d s e r v i c e s
• I n s t o c k / R e a d y - t o - s h i p
Artisan Scientific Corporation dba Artisan Technology Group is not an affiliate, representative, or authorized distributor for any manufacturer listed herein.
Limited Availability
Used and in Excellent Condition
Open Web Page
https://www.artisantg.com/92571-2
• We b u y y o u r e x c e s s , u n d e r u t i l i z e d , a n d i d l e e q u i p me n t
• F u l l - s e r v i c e , i n d e p e n d e n t r e p a i r c e n t e r

Advertisement

loading
Need help?

Need help?

Do you have a question about the VPX4810-LF and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Acromag VPX4810-LF

  • Page 1 Xycom VPX4810-LF Non-Intelligent, Air-Cooled 3U OpenVPX Carrier Card Limited Availability Used and in Excellent Condition Open Web Page https://www.artisantg.com/92571-2 A l l t r a d e m a r k s , b r a n d n a m e s , a n d b r a n d s a p p e a r i n g h e r e i n a r e t h e p r o p e r t y o f t h e i r r e s p e c t i v e o w n e r s .
  • Page 2 VPX PCIe PMC/XMC 3U Carrier USER’S MANUAL ACROMAG INCORPORATED 30765 South Wixom Road Wixom, MI 48393-2417 U.S.A. Tel: (248) 624-0310 Fax: (248) 624-9234 Copyright 2017, Acromag, Inc., Printed in the USA. Data and specifications are subject to change without notice. 8500908G...
  • Page 3 JTAG Connector – JTAG Header ..................15 Installing and Removing PMC/XMC Modules ..............17 VPX4810 Air-Cooled ........................... 17 VPX4810CC Conduction Cooled ......................... 19 VPX4810REDI VITA 48 ..........................21 Acromag, Inc. Tel: 248-295-0310 - 1 - - 1 - www.acromag.com http://www.acromag.com...
  • Page 4 This is very important where property loss or human life is involved. It is important that you perform satisfactory overall system design and it is agreed between you and Acromag, that this is your responsibility.
  • Page 5 Model VPX4810 is an air-cooled product which can be used for front and rear I/O XMC/PMC mezzanine I/O modules. Model VPX4810CC is an extended temperature conduction-cooled product which supports all Acromag FPGA modules. It only supports Rear I/O. Model VPX4810REDI is a VITA 48 Ruggedized Enhanced Design Implementation (REDI) model that does not support Front I/O and will only fit in REDI chassis.
  • Page 6 VPX4810 PCIe PMC/XMC 3U Carrier USER’S MANUAL References The following two whitepapers related to VPX are available for download on Acromag’s website or by contacting your sales representative. Introduction to VPX: VITA 46, 48, and 65. Will Acromag’s VPX4810 work in my system? Acromag, Inc.
  • Page 7 Each of Acromag’s VPX carriers are in a different pitch as determined by the cooling technique. The VPX4180 is a 1.0” pitch board, the VPX4810CC is 1.0” pitch, and the VPX4810REDI is a 1.00” pitch board. Verify your chassis compliance to accommodate the various board pitches.
  • Page 8 For more information on backplane compatible please refer to the Acromag VPX4810 Compatibility Whitepaper. WARNING: THE VPX4810 CAN ONLY BE USED ON A 3U BACKPLANE. PLUGGING THIS MODULE INTO A 6U BACKPLANE MAY RESULT IN DAMAGE TO THIS BOARD DUE INCOMPATIBLE POWER SUPPLIES.
  • Page 9 Ground PCI-RSVD* Ground Ground GNT* REQ* V(I/O) AD(31) AD(28 AD(27) AD(25) Ground Ground C/BE(3)* AD(22) AD(21) AD(19) V(I/O) AD(17) FRAME* Ground Ground IRDY* DEVSEL* Ground LOCK* SDONE* SBO* Acromag, Inc. Tel: 248-295-0310 - 7 - - 7 - www.acromag.com http://www.acromag.com...
  • Page 10 USER’S MANUAL Ground V(I/O) AD(15) AD(12) AD(11) AD(09) Ground C/BE(0)* AD(06) AD(05) AD(04) Ground V(I/O) AD(03) AD(02) AD(01) AD(00) Ground REQ64* * Indicates that the signal is active low. Acromag, Inc. Tel: 248-295-0310 - 8 - - 8 - www.acromag.com http://www.acromag.com...
  • Page 11 AD(14) AD(13) M66EN AD(10) AD(08) +3.3V AD(07) PMC-RSVD +3.3V PMC-RSVD PMC-RSVD Ground PMC-RSVD PMC-RSVD Ground PMC-RSVD ACK64* +3.3V Ground PMC-RSVD * Indicates that the signal is active low. Acromag, Inc. Tel: 248-295-0310 - 9 - - 9 - www.acromag.com http://www.acromag.com...
  • Page 12 Ground AD(40) AD(39) AD(38) AD(37) Ground Ground AD(36) AD(35) AD(34) AD(33) Ground V(I/O) AD(32) PCI-RSVD PCI_RSVD PCI-RSVD Ground Ground PCI- * Indicates that the signal is active low. Acromag, Inc. Tel: 248-295-0310 - 10 - - 10 - www.acromag.com http://www.acromag.com...
  • Page 13 Rear Jn4-51/P2-D13 Rear Jn4-52/P2-A13 Rear Jn4-53/P2-F14 Rear Jn4-54/P2-C14 Rear Jn4-55/P2-E14 Rear Jn4-56/P2-B14 Rear Jn4-57/P2-E15 Rear Jn4-58/P2-B15 Rear Jn4-59/P2-D15 Rear Jn4-60/P2-A15 Rear Jn4-61/P2-F16 Rear Jn4-62/P2-C16 Rear Jn4-63/P2-E16 Rear Jn4-64/P2-B16 Acromag, Inc. Tel: 248-295-0310 - 11 - - 11 - www.acromag.com http://www.acromag.com...
  • Page 14 MBIST# PCIeR1p PCIeR1n +5.0V MPRESENT# PCIeR2p PCIeR2n +3.3V AUX PCIeR3p PCIeR3n +5.0V MSDA PCIeR4p PCIeR4n PCIeR5p PCIeR5n +5.0V MVMRO MSCL PCIeR6p PCIeR6n PCIeR7p PCIeR7n REFCLK+ REFCLK- Wake# Root# Acromag, Inc. Tel: 248-295-0310 - 12 - - 12 - www.acromag.com http://www.acromag.com...
  • Page 15 L7-TX+ L7-RX- L7-RX+ P1-SE4 L8-TX- L8-TX+ L8-RX- L8-RX+ L9-TX- L9-TX+ L9-RX- L9-RX+ P1-SE5 L10-TX- L10-TX+ L10-RX- L10-RX+ Note: BOLD ITALIC signals are NOT USED by this carrier board. Acromag, Inc. Tel: 248-295-0310 - 13 - - 13 - www.acromag.com http://www.acromag.com...
  • Page 16 Note: BOLD ITALIC signals are NOT USED by this carrier board. Rear I/O pin mapping diagram as defined in VITA 46.9. This product is complaint to rear I/O routing P2w1-P64s. Acromag, Inc. Tel: 248-295-0310 - 14 - - 14 - www.acromag.com http://www.acromag.com...
  • Page 17 VPX4810 PCIe PMC/XMC 3U Carrier USER’S MANUAL JTAG Connector – JTAG Header Pin Number Description JTAG_TDI JTAG_TDO JTAG_TCK JTAG_TMS JTAG_VREF Board Layout Acromag, Inc. Tel: 248-295-0310 - 15 - - 15 - www.acromag.com http://www.acromag.com...
  • Page 18 “reduced lanes” because of the design. The D status in not available on the VPX4810. The table below describes what the LED On/Off patterns indicate about the corresponding port states. Port Status LED On/Off Patterns, by State Acromag, Inc. Tel: 248-295-0310 - 16 - - 16 - www.acromag.com...
  • Page 19 The procedure for installing and XMC/PMC module into the VPX4810 series carrier varies depending on the carrier type. Please note that if you purchase the VPX4810 and one of Acromag’s PMC or XMC modules separately you may require one of the following additional hardware kits to complete mounting.
  • Page 20 Step 3: Flip the VPX4810 over and install 4x M2.5 x 5 screws into the locations noted in the picture below. These correspond to the standoffs and the front PMC panel on the attached module. 4x M2.5 x 5 screws Acromag, Inc. Tel: 248-295-0310 - 18 - - 18 - www.acromag.com...
  • Page 21 Loosen standoff screws. mating connectors. Press downward, turning standoffs (2x) if needed. Note: Consult the factory for any components on a non-Acromag PMC/XMC module that might interfere with the secondary thermal interface areas, before assembly. Acromag, Inc. Tel: 248-295-0310 - 19 - - 19 - www.acromag.com...
  • Page 22 Optionally users can install another 10x M2 x 6 screws into the bottom to further secure the VPX carrier to the metalwork. Install 2x M2.5 x 5 screws Optional 10x M2 x 6 screws. Note that only five are shown. Acromag, Inc. Tel: 248-295-0310 - 20 - - 20 - www.acromag.com http://www.acromag.com...
  • Page 23 The standoffs are pre-installed on the VPX4810REDI. Note that you will need the PMC-KIT-CC to complete mounting. Step 2: Remove the top cover by removing the 4 corner screws. Then, if necessary, change the jumper settings. Remove the 4 corner screws Acromag, Inc. Tel: 248-295-0310 - 21 - - 21 - www.acromag.com...
  • Page 24 Install 10x M2 x 6 screws Install 8x M2.5 x 5 screws Step 4: Replace the cover and reinstall the 4 corner screws. Acromag, Inc. Tel: 248-295-0310 - 22 - - 22 - www.acromag.com...
  • Page 25 This device also will report board temperature from a thermocouple on the board. Please contact the factory for further information on the bus operation. Acromag, Inc. Tel: 248-295-0310 - 23 - - 23 - www.acromag.com...
  • Page 26 WARNING: POWER MUST BE TURNED OFF BEFORE REMOVING OR INSERTING BOARDS. Where to Get Help If you continue to have problems, your next step should be to visit the Acromag worldwide web site at http://www.acromag.com. Our web site contains the most up-to-date product and software information.
  • Page 27 0.50 pounds (0.23 Kg) Model VPX4810REDI 0.95 pounds (0.43 Kg) FRONT PANEL VPX4810-LF front panel is 1.0” based on VITA 48.1. Please contact factory for IEEE 1101.10 1.0” and 0.8” front panel options. POWER REQUIREMENTS 3.3 VDC (5%)* Typical 900 mA Max.
  • Page 28 Shock 20g Model VPX4810CC and VPX4810REDI • Environmental Class ECC3 • Operating Temperature: CC4 (-40 to 85 • Non Operating Class: C3 • Vibration Class: V3 • Shock 40g Acromag, Inc. Tel: 248-295-0310 - 26 - - 26 - www.acromag.com http://www.acromag.com...
  • Page 29 PCI Express 2.0: up to 8 lane PCI Express electrical and protocol standards. Performs 5.0 Gbps data rate per lane and per direction. Supports ANSI/VITA 42.0 and 42.3 Compliant XMC modules. Reliability Prediction Mean Time Between Failures: 2,652,569 hours @ 25 C, Using MIL-HDBK-217F, Notice 2. Acromag, Inc. Tel: 248-295-0310 - 27 - - 27 - www.acromag.com http://www.acromag.com...
  • Page 30 ■ Yes via I2C bus. 256x8-bit Memory is embedded Clear Memory by EEPROM as part of I/O erasing. Note device is □ No expander. empty when first shipped. Acromag, Inc. Tel: 248-295-0310 - 28 - - 28 - www.acromag.com http://www.acromag.com...
  • Page 31 Add Certificate of Volatility 02 SEP 15 DAG/ARP PCB updated. Switches changed to jumpers. Some new features from the VPX4812 were added. 09 NOV 2017 CAB/ARP Clarify front panel specifications. Acromag, Inc. Tel: 248-295-0310 - 29 - - 29 - www.acromag.com http://www.acromag.com...
