Acromag VPX4840 User Manual

6u vpx dual xmc carrier cards
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
VPX4840/VPX4850
6U VPX Dual XMC Carrier Cards
USER'S MANUAL
ACROMAG INCORPORATED
30765 South Wixom Road
Wixom, MI 48393-2417 U.S.A.
Tel: (248) 295-0310
Email: solutions@acromag.com
Copyright 2022, Acromag, Inc., Printed in the USA.
Data and specifications are subject to change without notice.
8501183A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VPX4840 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Acromag VPX4840

Summary of Contents for Acromag VPX4840

  • Page 1 6U VPX Dual XMC Carrier Cards USER’S MANUAL ACROMAG INCORPORATED 30765 South Wixom Road Wixom, MI 48393-2417 U.S.A. Tel: (248) 295-0310 Email: solutions@acromag.com Copyright 2022, Acromag, Inc., Printed in the USA. Data and specifications are subject to change without notice. 8501183A...

  • Page 2: Table Of Contents

    3.3.2 I2C Addressing ..........................25 3.4 LED Status Indicators ....................26 3.5 VPX Profile ......................... 27 3.6 Expansion Sites ......................29 3.6.1 XMC Expansion Site ......................... 29 3.6.2 Processor XMC ..........................29 Acromag, Inc. Tel: 248-295-0310 - 1 - - 1 - https://www.acromag.com http://www.acromag.com...
  • Page 3 5.2.2.5.2 VPX4851/VPX4852 Variants ..................40 5.2.3 JTAG Programming/Debug Connectors ..................41 5.2.3.1 XMC Site JTAG Connectors .................... 41 5.3 Power Requirements ....................42 5.3.1 VPX4840/VPX4850 Internal Power ....................42 5.4 Environmental Considerations ..................43 5.4.1 Operating Temperature ........................43 5.4.2 Relative Humidity ..........................43 5.4.3 Vibration and Shock Standards .......................
  • Page 4 USER’S MANUAL VPX484x/VPX485x 6.0 CERTIFICATE OF VOLATILITY ................45 REVISION HISTORY ......................45 Acromag, Inc. Tel: 248-295-0310 - 3 - - 3 - https://www.acromag.com http://www.acromag.com...

  • Page 5: General Information

    1.1 Intended Audience This user’s manual was written for technically qualified personnel who will be working with I/O devices using the VPX4840 or VPX4850 carrier cards. It is not written for a general, non-technical audience unfamiliar with embedded I/O devices and their applications.

  • Page 6: Product Summary

    VITA 46.9-defined Rear I/O mappings to support a wide range of applications. The VPX4840 products provide Rear I/O support for both the XMC Jn6 connector and the legacy PMC Jn4 connector by implementing the P64s+X8d+X12d Rear I/O Signal Mapping defined in VITA 46.9. This provides for 64 single-ended I/O signals from Jn4 and 20 differential I/O signals from Jn6.

  • Page 7: Ordering Information

    Jn6 Only VPX4852-42-50 VITA 42 Conduction-Cooled Jn6 Only VPX4852-61-20 VITA 61 Air-Cooled Jn6 Only VPX4852-61-30 VITA 61 Ext Temp Cooled Jn6 Only VPX4852-61-50 VITA 61 Conduction Cooled Jn6 Only Acromag, Inc. Tel: 248-295-0310 - 6 - - 6 - https://www.acromag.com http://www.acromag.com...

  • Page 8: Key Components And Features

    1.5 Key Components and Features The VPX484x/VPX485x block diagrams are shown below which illustrate key components and features that are summarized on the following pages. Fig 1.5.a: VPX4841 Block Diagram Fig 1.5.b: Acromag, Inc. Tel: 248-295-0310 - 7 - - 7 - https://www.acromag.com http://www.acromag.com...
  • Page 9 USER’S MANUAL VPX484x/VPX485x VPX4842 Block Diagram Acromag, Inc. Tel: 248-295-0310 - 8 - - 8 - https://www.acromag.com http://www.acromag.com...
  • Page 10 USER’S MANUAL VPX484x/VPX485x Fig 1.5.c: VPX4851 Block Diagram Fig 1.5.d: Acromag, Inc. Tel: 248-295-0310 - 9 - - 9 - https://www.acromag.com http://www.acromag.com...
  • Page 11 USER’S MANUAL VPX484x/VPX485x VPX4852 Block Diagram Acromag, Inc. Tel: 248-295-0310 - 10 - - 10 - https://www.acromag.com http://www.acromag.com...

  • Page 12: Broadcom Pex8734 Pcie Switch

    VPX484x/VPX485x 1.5.1 Broadcom PEX8734 PCIe Switch The VPX4840 series and VPX4850 series each provide PCIe support for up to 16 lanes of PCIe Gen3, with link configurations selectable as 1x16, 2x8, or 4x4 ports. The VPX4841/4851 models make this connection through the data plane, while the VPX4842/4852 make it through the expansion plane.
  • Page 13 The VPX4851 and VPX4852 boards provide support for Rear I/O connections on the Jn6 connectors with the P3w3-X38s+P4w1-X12d+X8d+P5w3- X38s+P6w1-X12d+X8d Rear I/O Signal Mapping defined in VITA 46.9 as shown at left. Acromag, Inc. Tel: 248-295-0310 - 12 - - 12 - https://www.acromag.com...

  • Page 14: Preparation For Use

    It is important that the user employ satisfactory overall system design. It is understood and agreed by the Buyer and Acromag that this is the Buyer's responsibility. WARNING: This board utilizes static sensitive components and should only be handled at a static-safe workstation.

  • Page 15: Installing Into A Vpx Backplane

    2. Verify that all DIP switch settings are correct. 3. Verify that the card cage slot is clear and accessible. 4. Install the VPX4840/VPX4850 in the card cage by centering the unit on the guides in the slots (P0 connector facing up). Push the board slowly toward the rear of the chassis until the VPX connectors engage.

  • Page 16: Hardware Information And Configuration

    USER’S MANUAL VPX484x/VPX485x 3.0 HARDWARE INFORMATION AND CONFIGURATION VPX4841-xx-50 Top (left) and Bottom (right) View (Conduction-Cooled Assembly, VPX4851 is similar) Acromag, Inc. Tel: 248-295-0310 - 15 - - 15 - https://www.acromag.com http://www.acromag.com...
  • Page 17 USER’S MANUAL VPX484x/VPX485x VPX4841-xx-20,30 Top (left) and Bottom (right) View (Air-Cooled Assembly, VPX4851 similar) Acromag, Inc. Tel: 248-295-0310 - 16 - - 16 - https://www.acromag.com http://www.acromag.com...

  • Page 18: Module Hardware Switch Configuration

    RESERVED Note 1: Default (Data Plane variant) settings are in BOLD. Note 2: Expansion Plane variant will by default be set to x8, x8 X = Don’t Care Acromag, Inc. Tel: 248-295-0310 - 17 - - 17 - https://www.acromag.com http://www.acromag.com...

  • Page 19: Configuration Switch Sw2

    If SW1 is configured for x8,x4,x4, VPX ports correspond with VPX FAT PIPE A, C, D. If SW1 is configured for x4,x4,x4,x4, VPX ports correspond with VPX FAT PIPE A, B, C, D. Acromag, Inc. Tel: 248-295-0310 - 18 - - 18 - https://www.acromag.com...

  • Page 20: Configuration Switch Sw3

    Table 3.1.c: Configuration Switch SW3 Configuration Function Description Switch SW3 RESERVED RESERVED RESERVED Reserved RESERVED RESERVED RESERVED DISABLED Note: Default settings are in BOLD. X = Don’t Care Acromag, Inc. Tel: 248-295-0310 - 19 - - 19 - https://www.acromag.com http://www.acromag.com...

  • Page 21: Configuration Switch Sw4

    Switch Setting Position Function Description Common System Clock Select Non-Common GEN 1 PCIe Switch Gen Speed GEN 2 GEN 3 Reserved Reserved Reserved Note: Default settings are in BOLD. Acromag, Inc. Tel: 248-295-0310 - 20 - - 20 - https://www.acromag.com http://www.acromag.com...

  • Page 22: Configuration Switch Sw5

    Switch SW5 Configuration Switch SW5 Function Description Enabled System Reset Delay Generator Disabled Description 20ms 200ms System Reset Delay Time 575ms 775ms Note: Default settings are in BOLD. Acromag, Inc. Tel: 248-295-0310 - 21 - - 21 - https://www.acromag.com http://www.acromag.com...

  • Page 23: Configuration Switch Sw6

    Table 3.1.f summarizes the functions, settings, and descriptions for DIP switch SW6. Configuration Switch SW6 Position Function Description +3.3V XMC A VREF +2.5V +3.3V XMC B VREF +2.5V Note: Default settings are in BOLD. Acromag, Inc. Tel: 248-295-0310 - 22 - - 22 - https://www.acromag.com http://www.acromag.com...

  • Page 24: Configuration Switch Sw7

    Configuration Switch SW7 Position Function Description FRU/Temp Sensor uses +3.3V FRU EEPROM & Temp Sensor Voltage Select FRU/Temp Sensor uses +3.3V_AUX Unused Unused Unused Note: Default settings are in BOLD. Acromag, Inc. Tel: 248-295-0310 - 23 - - 23 - https://www.acromag.com http://www.acromag.com...

  • Page 25: Configuration Switch Sw8

    +12V XMCA POWER Power Select +5V XMCA POWER +12V XMCB POWER 8-2: XMC Slot B Power Select +5V XMCB POWER 8-3: NC 8-4: NC Note: Default settings are in BOLD. Acromag, Inc. Tel: 248-295-0310 - 24 - - 24 - https://www.acromag.com http://www.acromag.com...

  • Page 26: Power

    3.2 Power 3.2.1 Power Supply Requirements The VPX4840/VPX4850 boards operate using only the +12V (VS1) and +3.3V_AUX rails on the VPX backplane per the latest guidance in the VITA 65.0 OpenVPX Specification. All other power rails used on board are derived from the +12V (VS1) rail.

  • Page 27: Led Status Indicators

    VPX484x/VPX485x 3.4 LED Status Indicators All VPX4840/VPX4850 models come with seven status LEDs along the front edge of the board, between the two XMC sites. These are easily legible on the faceplate equipped with the air-cooled “-20” models. The LED indications on the faceplate can be seen below.

  • Page 28: Vpx Profile

    12.3.5-2. The module profile complies with OpenVPX slot profile SLT6-PER-1Q- 10.3.5 shown in Figure 3.4.a below. Fig. 3.5.a: OpenVPX Slot Profile SLT6- PER-1Q-10.3.5 The VPX4842/VPX4852 profile closely complies with OpenVPX slot profile SLT6- PER-1Q-10.3.5 shown at right. Acromag, Inc. Tel: 248-295-0310 - 27 - - 27 - https://www.acromag.com http://www.acromag.com...
  • Page 29 USER’S MANUAL VPX484x/VPX485x Fig. 3.5.b: OpenVPX Slot Profile SLT6- PER-4F-10.3.1 The VPX4841/VPX4851 profile complies with OpenVPX slot profile per SLT6-PER-4F-10.3.1 shown at right. Acromag, Inc. Tel: 248-295-0310 - 28 - - 28 - https://www.acromag.com http://www.acromag.com...

  • Page 30: Expansion Sites

    USER’S MANUAL VPX484x/VPX485x 3.6 Expansion Sites The VPX4840/VPX4850 contains two XMC expansion sites with a PCIe x8 Gen 3 interface. These sites can be used to support a wide variety of industry standard VITA 42 mezzanine cards (FPGA, I/O, Ethernet, etc.).

  • Page 31: Service And Repair

    4.3 Where to Get Help If the problem persists, the next step should be to visit the Acromag worldwide web site at https://www.acromag.com. Our web site contains the most up-to-date product and software information.

  • Page 32: Specifications

    USER’S MANUAL VPX484x/VPX485x 5.0 SPECIFICATIONS 5.1 Physical The VPX4840/VPX4850 is a 6U VPX module that conforms to the 1" backplane spacing set forth by the VITA 48 specification. Height 233.35 mm (9.187 in) Depth 160.0 mm (6.299 in) PCB Thickness 1.68 mm (0.066 in)

  • Page 33: P1 Vpx Connector (Vpx4841/Vpx4851 Only)

    PCIE_EP_TX14_P PCIE_EP_TX14_N PCIE_EP_RX15_P PCIE_EP_RX15_N PCIE_EP_TX15_P PCIE_EP_TX15_N Note 1: For applications that require use of Auxiliary Reset and Expansion Plane Clocks, please consult the factory for available configuration options. Acromag, Inc. Tel: 248-295-0310 - 32 - - 32 - https://www.acromag.com http://www.acromag.com...

  • Page 34: P3 Vpx Connector

    USER’S MANUAL VPX484x/VPX485x 5.2.1.4 P3 VPX Connector 5.2.1.4.1 VPX4840 Series Wafer J14-4 J14-2 J14-3 J14-1 J14-8 J14-6 J14-7 J14-5 J14-12 J14-10 J14-11 J14-9 J14-16 J14-14 J14-15 J14-13 J14-20 J14-18 J14-19 J14-17 J14-24 J14-22 J14-23 J14-21 J14-28 J14-26 J14-27 J14-25 J14-32...

  • Page 35: P4 Vpx Connector (All Variants)

    J16-E1 J16-D1 J16-B1 J16-A1 J16-E3 J16-D3 J16-B3 J16-A3 J16-E11 J16-D11 J16-B11 J16-A11 J16-E13 J16-D13 J16-B13 J16-A13 5.2.1.6 P5 VPX Connector 5.2.1.6.1 VPX4840 Series Wafer J24-4 J24-2 J24-3 J24-1 J24-8 J24-6 J24-7 J24-5 J24-12 J24-10 J24-11 J24-9 J24-16 J24-14 J24-15 J24-13...

  • Page 36: Vpx4850 Series

    J26-E15 J26-D15 J26-B15 J26-A15 J26-E17 J26-D17 J26-B17 J26-A17 J26-E19 J26-D19 J26-B19 J26-A19 J26-E1 J26-D1 J26-B1 J26-A1 J26-E3 J26-D3 J26-B3 J26-A3 J26-E11 J26-D11 J26-B11 J26-A11 J26-E13 J26-D13 J26-B13 J26-A13 Acromag, Inc. Tel: 248-295-0310 - 35 - - 35 - https://www.acromag.com http://www.acromag.com...

  • Page 37: Xmc Connectors

    XMCA_RIO18_P XMCA_RIO19_P XMCA_RIO18_N XMCA_RIO19_N XMCA_RIO20_P XMCA_RIO21_P XMCA_RIO20_N XMCA_RIO21_N XMCA_RIO22_P XMCA_RIO23_P XMCA_RIO22_N XMCA_RIO23_N XMCA_RIO24_P XMCA_RIO25_P XMCA_RIO24_N XMCA_RIO25_N XMCA_RIO26_P XMCA_RIO27_P XMCA_RIO26_N XMCA_RIO27_N XMCA_RIO28_P XMCA_RIO29_P XMCA_RIO28_N XMCA_RIO29_N XMCA_RIO30_P XMCA_RIO31_P XMCA_RIO30_N XMCA_RIO31_N Acromag, Inc. Tel: 248-295-0310 - 36 - - 36 - https://www.acromag.com http://www.acromag.com...

  • Page 38: J24 Xmc Connector

    XMCB_RIO18_P XMCB_RIO19_P XMCB_RIO18_N XMCB_RIO19_N XMCB_RIO20_P XMCB_RIO21_P XMCB_RIO20_N XMCB_RIO21_N XMCB_RIO22_P XMCB_RIO23_P XMCB_RIO22_N XMCB_RIO23_N XMCB_RIO24_P XMCB_RIO25_P XMCB_RIO24_N XMCB_RIO25_N XMCB_RIO26_P XMCB_RIO27_P XMCB_RIO26_N XMCB_RIO27_N XMCB_RIO28_P XMCB_RIO29_P XMCB_RIO28_N XMCB_RIO29_N XMCB_RIO30_P XMCB_RIO31_P XMCB_RIO30_N XMCB_RIO31_N Acromag, Inc. Tel: 248-295-0310 - 37 - - 37 - https://www.acromag.com http://www.acromag.com...

  • Page 39: J15/J25 Xmc Connector

    PER0n1 VPWR GA1# MPRESENT# PER0p2 PER0n2 +3.3V_AUX PER0p3 PER0n3 VPWR GA2# SMB_DATA PER0p4 PER0n4 PER0p5 PER0n5 VPWR NVRAM_LOCK SMB_CLK PER0p6 PER0n6 PER0p7 PER0n7 REF_CLK P REF_CLK N ROOT# Acromag, Inc. Tel: 248-295-0310 - 38 - - 38 - https://www.acromag.com http://www.acromag.com...

  • Page 40: J16 Xmc Connector

    XMCA_RIO06_P XMCA_DP13_P XMCA_DP13_N XMCA_RIO07_P XMCA_RIO04_N XMCA_RIO05_N XMCA_DP14_P XMCA_DP14_N XMCA_RIO04_P XMCA_DP15_P XMCA_DP15_N XMCA_RIO05_P XMCA_RIO02_N XMCA_RIO03_N XMCA_DP16_P XMCA_DP16_N XMCA_RIO02_P XMCA_DP17_P XMCA_DP17_N XMCA_RIO03_P XMCA_RIO00_N XMCA_RIO01_N XMCA_DP18_P XMCA_DP18_N XMCA_RIO00_P XMCA_DP19_P XMCA_DP19_N XMCA_RIO01_P Acromag, Inc. Tel: 248-295-0310 - 39 - - 39 - https://www.acromag.com http://www.acromag.com...

  • Page 41: J26 Xmc Connector

    XMCB_RIO06_P XMCB_DP13_P XMCB_DP13_N XMCB_RIO07_P XMCB_RIO04_N XMCB_RIO05_N XMCB_DP14_P XMCB_DP14_N XMCB_RIO04_P XMCB_DP15_P XMCB_DP15_N XMCB_RIO05_P XMCB_RIO02_N XMCB_RIO03_N XMCB_DP16_P XMCB_DP16_N XMCB_RIO02_P XMCB_DP17_P XMCB_DP17_N XMCB_RIO03_P XMCB_RIO00_N XMCB_RIO01_N XMCB_DP18_P XMCB_DP18_N XMCB_RIO00_P XMCB_DP19_P XMCB_DP19_N XMCB_RIO01_P Acromag, Inc. Tel: 248-295-0310 - 40 - - 40 - https://www.acromag.com http://www.acromag.com...

  • Page 42: Jtag Programming/Debug Connectors

    TDI – JTAG Test Data In. This pin outputs the serial data stream transmitted to the TDI pin on the first device in a JTAG chain. VREF – The target reference voltage V is selectable between +3.3V and +2.5V using SW6. GND – Signal Return Acromag, Inc. Tel: 248-295-0310 - 41 - - 41 - https://www.acromag.com http://www.acromag.com...

  • Page 43: Power Requirements

    5.3.1 VPX4840/VPX4850 Internal Power The currents specified in the table below are for the VPX4840/VPX4850 carrier boards only. Additional power required by XMC mezzanine boards must be considered separately.

  • Page 44: Environmental Considerations

    5.4.2 Relative Humidity 5% to 95% Non-condensing 5.4.3 Vibration and Shock Standards The VPX4840/VPX4850 products are designed to comply with the following Vibration and Shock standards. Vibration, Random Operating: Designed to comply with VITA 47 Class V1. Shall withstand vibration from 5 to 100Hz. with Power Spectral Density (PSD) = 0.04g...

  • Page 45: Emc Directives

    USER’S MANUAL VPX484x/VPX485x 5.4.4 EMC Directives The VPX4840/VPX4850 is designed to comply with EMC Directive 2004/108/EC. • Immunity per EN 61000-6-2: Electrostatic Discharge Immunity (ESD), per IEC 61000-4-2. Radiated Field Immunity (RFI), per IEC 61000-4-3. Electrical Fast Transient Immunity (EFT), per IEC 61000-4-4.
  • Page 46 248-295-0310 248-624-9234 Revision History The following table shows the revision history for this document: Release Date Version EGR/DOC Description of Revision 21 FEB 2024 GJB/AMM Initial Release Acromag, Inc. Tel: 248-295-0310 - 45 - - 45 - https://www.acromag.com http://www.acromag.com...
