- Page 1 USER MANUAL DESD8LW-V2 8L SMART DESICCANT DEHUMIDIFIER WITH HEATER Thank you for choosing electriQ. Please read this user manual before using this innovative dehumidifier and keep it safe for future reference.
- Page 3 CONTENTS SAFETY Safety instructions Safety protection tips Visual safety guide OVERVIEW Features and Indicators Before use Positioning the dehumidifier Setting up water drainage Parts OPERATION Control panel and functions Display Quick reference guide CONNECTION Setting up the wi-fi app Registering app Setting up home on app Quick connection AP mode connection...
- Page 4 agent or similarly qualified persons in order SAFETY INSTRUCTIONS to avoid a hazard. IMPORTANT • R290 refrigerant gas complies with European • Carefully read the instructions before operating environmental directives. the unit. • R290 has a low GWP (Global Warming •...
- Page 5 dehumidifiers where flammable gases or (approximately). Do not use the unit without the VOC can be released or accumulate. mesh air filter, as this will allow dirt to gather • Do not use or store the unit in a room smaller inside the dehumidifier, which could invalidate the warranty.
- Page 6 Desiccant dehumidifiers are ideal both at standard and low temperatures, working in an ambient temperature range of between 5-35°C. The DESD8LW-V2 is light and easy to move, as it does not contain a heavy compressor. It also works intelligently as it is designed to extract unwanted humidity while saving money due to its advanced power-saving logic.
- Page 7 Do not use outdoors. Your electriQ dehumidifier will begin to protect your space from the harmful effects of excessive moisture as soon as it is turned on. Excess moisture is dispersed throughout your home. For this reason, the dehumidifier should be positioned in a central and clear location so that it can draw this moist air towards it from all over the home.
- Page 8 NOTE: Forcing the castors over an uneven floor or thick carpet can damage them; always lift the unit with the handle instead. Do not move the unit with the tank full; always empty prior to moving to avoid spillages. WATER DRAINAGE When the water tank is full, the unit stops operating.
- Page 9 PARTS Air Deflector Outlet Handle LED Indicator Water Tank Control Panel Handle Intake Power Cord...
- Page 10 CONTROL PANEL POWER BUTTON Turn the appliance ON/OFF. Please note that after turning off the unit, it will take around 10 minutes to dry the zeolite disk before the operation stops. FAN SPEED This allows the user to adjust the fan speed. Press the fan speed button to change the fan speed from Low →...
- Page 11 HUMIDITY Press the button to set the desired humidity. The order is shown below: CO→40%→45%→50%→55%→60%→65%→70%→75%→80%. CO is for continuous operation. In this setting, the unit will continue dehumidifying regardless of the humidity. BUTTON SOUND BUTTON Turn on/off the button beep. When the unit is working, press and hold the &...
- Page 12 WHEN THE APPLIANCE IS RUNNING 1. When the room humidity level is lower than the target humidity, the heater will stop, and the fan will continue to run at a low speed for air circulation. 2. When the room humidity exceeds the desired level, the heater will reactivate to work for 4 hours and stop for 30 minutes as a circulation to extract the moisture.
- Page 13 CHANGING BETWEEN CONNECTION MODES / WIFI RESET To change the unit between the two connection types, hold the SWING button for 3 seconds. The frequency of the flashing Smart light signifies the connection mode. This will also remove any previous WIFI configuration. Connection Type Frequency of Flashes CF (Quick Connection)
- Page 14 SETTING UP YOUR HOME WITHIN THE APP TUYA is designed to work with a large number of compatible smart devices within your home and multiple devices within different houses. As such, during the setup process, the app requires that different areas be created and named to allow easy management of all your devices. When devices are added, they are assigned to one of the rooms you have created.
- Page 15 CONNECTING USING QUICK CONNECTION Before initiating the connection, ensure the unit is in standby mode, with the WIFI light flashing once per second. If not, follow the instructions for changing the connection mode. Ensure your phone is connected to the WIFI network. (We advise turning mobile data off during setup) 1.
- Page 16 CONNECTING USING AP MODE (ALTERNATIVE METHOD) Before initiating the connection, ensure the unit is in standby mode, with the WIFI light flashing twice per second. If not, follow the instructions for changing the connection type. Ensure your phone is connected to the WIFI network. (We advise turning mobile data off during setup) 1.
- Page 17 CONTROLLING YOUR DEVICE THROUGH THE APP THE HOME SCREEN Add a device Chose the device to control Access the user Smart Scenes / profile Automation...
- Page 18 DEVICE SCREEN The device screen is the main control screen for the dehumidifier, providing access to the controls to modify its functions. Profile: Use to change the name of the dehumidifier Back: Returns to the ON / OFF Button: Use to and amend user settings.
- Page 19 SMART SCENES Smart Scenes is a powerful tool that allows the user to customise the dehumidifier's operation based on conditions within the room and outside influences. This gives the user the option of specifying much more intelligent actions. These are split into two categories: Scene and Automation.
- Page 20 AUTOMATION Automation allows the device to be set up to take automatic action. This can be triggered by time, indoor temperature, humidity in the room, weather conditions, and a range of other factors DEVICE DETAILS SCREEN 2. Press on the Plus in the top 3.
- Page 21 The device details screen allows you to edit the details of the device and use some of its additional features. It can be accessed from the device screen by pressing the symbol in the top right-hand corner. CHANGING THE NAME OF YOUR DEVICE The top option within this allows you to change the name of the device to something relevant to the use of the product, such as “Living Room Dehumidifier”.
- Page 22 CARE AND MAINTENANCE Always shut off the unit and unplug it from the mains before cleaning or performing any maintenance. When it is not in use for long periods, it is advisable to remove the plug from the power socket. Do not use chemical solvents (such as benzene, alcohol or gasoline), as they may cause irreversible damage to the unit.
- Page 23 TROUBLESHOOTING Problem Possible Cause Solution Contact an electrician to perform a Power is abnormal repair. The unit does not Check the placement of the water tank or Water tank displaced or full work. empty water tank. The room temperature is too Lower room temperature, clear air outlet high, or the air outlet is covered Filter is dirty...
- Page 24 Knocking noise The motor wheel is low on Run the dehumidifier in Laundry mode coming from the lubrication, or dirt may have for two days to increase the lubrication; if dehumidifier entered the motor ball bearings. the fault persists, call the service centre. Negative air pressure in the room pulls the water back into the dehumidifier overflow.
- Page 25 Using the unit in turbo mode will add more heat to your room and reduce your heating bill, as dry air will heat quickly. electriQ UK SUPPORT For your convenience, make these simple checks before calling the service line.
- Page 26 TECHNICAL DATA Model No. DESD8LW-V2 Rated Voltage 230V ~ 50Hz Dehumidify Capacity 8L / day (at 20 C / 60%RH) Max Rated Input Power 610 W Tank Capacity 2.0 litres IP Rating IPX0 Air Volume 150 m ≤48 dB(A) Noise level...
- Page 27 Compliance and Quality Manager, Buy It Direct, Huddersfield August 2024 EU DECLARATION OF CONFORMITY Hereby, electriQ declares that these air conditioners are in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet addresses: https://www.electriq.co.uk/content/DOC/EU/DESD8LW-V2.pdf...
