USER MANUAL
PREMIUM DEHUMIDIFIER WITH DIGITAL HUMIDISTAT
WITH AIR PURIFIER, UV AND PLASMA IONISER AND
SMART WIFI APP CONTROL
CD25PRO-LE-V2 - 25L Litres per day
Thank you for choosing electriQ
Please read this user manual before using this innovative
Dehumidifier and keep it safe for future reference
Visit our page www.electriQ.co.uk for our entire range of Intelligent Electricals
Advertisement
Table of Contents
Related Manuals for ElectrIQ CD25PRO-LE-V2
Summary of Contents for ElectrIQ CD25PRO-LE-V2
- Page 1 SMART WIFI APP CONTROL CD25PRO-LE-V2 - 25L Litres per day Thank you for choosing electriQ Please read this user manual before using this innovative Dehumidifier and keep it safe for future reference Visit our page www.electriQ.co.uk for our entire range of Intelligent Electricals...
-
Page 2: Table Of Contents
CONTENTS SAFETY INSTRUCTIONS ENERGY SAVING INSTALLATION FEATURES PARTS CONTROL PANEL QUICK REFERENCE GUIDE OTHER FEATURES AND INDICATORS POSITIONING THE DEHUMIDIFIER WATER DRAINAGE SETTING UP THE WIFI CONTROLLING YOUR DEVICE THROUGH THE APP CARE AND MAINTENANCE FREQUENTLY ASKED QUESTIONS TROUBLESHOOTING TECHNICAL SPECIFICATION SUPPORT... -
Page 3: Safety Instructions
SAFETY INSTRUCTIONS IMPORTANT • Carefully read the instructions before operating the unit. • This appliance is only intended for use in an indoor domestic environment. Any other use is not recommended by the manufacturer and may cause fire, electrical shock or other injuries to person or damage to property. - Page 4 • A damaged power supply cord should be replaced by the manufacturer or a qualified electrician in order to avoid a hazard. • Any service other than regular cleaning or filter replacement should be performed by an authorized service representative. Failure to comply could result in a voided warranty.
-
Page 5: Energy Saving
ENERGY SAVING AND UNIT SAFETY PROTECTION TIPS • Do not cover or restrict the airflow from the outlet or inlet grills. • For maximum performance, the unit should be operated at least 20 cm away from walls and 50 cm from other objects within the room. •... -
Page 6: Installation
40% and 80% ensuring your room is not dried too much and power is not wasted. FEATURES Your dehumidifier is part of the electriQ low energy premium dehumidifier range featuring low power consumption, power saving logic and advanced air purification. Easy to use controls Low energy –... -
Page 7: Parts
PARTS Handle Air Outlet Louvres Castors Power Cord Control Panel Pre-Filter / Activated Carbon Filter (Optional) Continuous Drainage Port Water Tank ACCESSORIES Activated carbon filter (Optional) HEPA FILTER 6 stage dual action dehumidifier and purifier great in improving indoor air quality... -
Page 8: Control Panel
CONTROL PANEL POWER POWER BUTTON Turns the appliance on/off MODE BUTTON Select the function of the unit between SMART / HIGH / LOW / and Air Purifier. The LED’s next to the button will show which mode is selected. SMART MODE: The unit will default to SMART mode the first time it is switched on and remains in this mode until another program is chosen. - Page 9 WIFI BUTTON Press and hold the WIFI button for 3 seconds to activate the WIFI connection mode. The WIFI indicator light will be illuminated. See the WIFI guide within this manual for further information on how to set it HUMIDITY SETTING Press the UP and DOWN buttons to select the desired relative humidity level.
-
Page 10: Quick Reference Guide
QUICK REFERENCE GUIDE POWER POWER BUTTON: Press to turn the unit ON/OFF. OSCILLATION BUTTON: Press once to make the louvre swing and press again to lock at 45 degrees, press again to lock at 90 degrees. Do not operate the unit if the self-opening louvers do not open on power on. TIMER: Press the timer button, then use the UP and DOWN buttons to adjust the duration of the timer (1-24 hours, START/STOP timer) IF SET WHILE THE UNIT IS RUNNING... - Page 11 LAUNDRY MODE When drying clothes, it is advised for the dehumidifier to operate continuously with maximum water extraction until the water tank is full. Set the unit to the High mode, and set the desired humidity level between 35%-50%. 35% is very dry and is hardly achievable in a UK domestic environment.
-
Page 12: Other Features And Indicators
OTHER FEATURES AND INDICATORS TANK FULL LIGHT When the water tank is full, removed or incorrectly inserted the unit will stop dehumidifying, the red tank full light will illuminate and the unit will beep. Empty the tank and reinsert it correctly to resume operation. AUTO DEFROST When frost builds up on the evaporator coils, the compressor will cycle off and the unit will go in to defrost mode. -
Page 13: Positioning The Dehumidifier
Please note the unit should not be placed directly against a radiator or other heat source. When positioning your electriQ dehumidifier, ensure that it is placed clear of any obstacle that may limit the air movement. Place the dehumidifier on a flat dry surface. -
Page 14: Water Drainage
WATER DRAINAGE When the water tank is full, the unit will stop automatically. When this happens the TANK FULL red light will show on the control panel, and the unit will bleep. There are two ways to dispense collected water. It can be either collected within the internal tank or expelled through a drainage hose (not supplied) using continuous drainage. - Page 15 CONTINUOUS DRAINAGE This dehumidifier has a continuous drain hole that can be connected to a plastic pipe with a 15 mm inner diameter (Not Supplied). Water can be automatically plumbed in or drained into a sink, a larger receptacle or through the wall into an outside drain. Please follow the steps below to set your unit up for continuous drainage.
-
Page 16: Setting Up The Wifi
SETTING UP THE WIFI APP This is designed as a general guide to the setup. There may be differences in the interface and features available due to product development and features of the model. BEFORE YOU START • Ensure your router provides a standard 2.4ghz connection. •... - Page 17 REGISTER THE APP 1. Press on the register button 3. Enter your email address or Read the Privacy policy and at the bottom of the screen. phone number and press press the Agree Button. continue to register. 4. A verification code will be 5.
- Page 18 SETTING UP YOUR HOME WITHIN THE APP TUYA is designed so it can work with a large number of compatible smart devices within your home. It can also be set up to work with multiple devices within different houses. As such, during the setup process the app requires that different areas are created and named to allow easy management of all your devices.
- Page 19 CONNECTING USING QUICK CONNECTION Before initiating the connection, make sure the unit is in standby mode, with the WIFI light flashing twice per second. If not, follow the instructions for changing the connection mode. Ensure your phone is connected to the WiFi network. (We advise turning mobile data off during setup) 1.
- Page 20 CONNECTING USING AP MODE (ALTERNATIVE METHOD) Before initiating the connection, make sure the unit is in standby mode, with the WiFi light flashing once per second. If not, follow the instructions for changing the connection type. Ensure your phone is connected to the WiFi network. (We advise turning mobile data off during setup) 1.
-
Page 21: Controlling Your Device Through The App
CONTROLLING YOUR DEVICE THROUGH THE APP THE HOME SCREEN Add a device Choose the device to control Smart Scenes / User Profile Automation DEVICE SCREEN ON / OFF Button: Use to Name of dehumidifier: Press to enter the Device quickly turn the unit on or Screen off. - Page 22 DEVICE SCREEN The device screen is the main control screen for the dehumidifier, providing access to the controls to amend the functions of the dehumidifier Profile: Use to change the name of the dehumidifier Back: Return to the Home and amend user settings. Screen On / Off Slider: Use to turn the...
- Page 23 SMART SCENES Smart Scenes is a powerful tool providing the option to customise the operation of the dehumidifier based both on conditions within the room and outside influences. This gives the user the option of specifying much more intelligent actions. These are split into two categories Scene and Automation.
- Page 24 AUTOMATION Automation allows an automatic action to be set up for the device. This can be triggered by the Time, indoor temperature, humidity of the room, weather conditions, and a range of other influences. 1. Press on the Smart Scene 2.
- Page 25 DEVICE DETAILS SCREEN The device details screen gives you the option to edit the details for the device, and use some of its additional features. The device details screen can be accessed from the device screen by pressing on the symbol in the top right hand corner.
-
Page 26: Care And Maintenance
CARE AND MAINTENANCE Always shut off the unit and unplug it from the mains before cleaning or performing any maintenance. When it is not in use for long periods, it is advisable to remove the plug from the power socket. Do not use chemical solvents (such as benzene, alcohol or gasoline) as they may cause irreversible damage to the unit. -
Page 27: Frequently Asked Questions
FREQUENTLY ASKED QUESTIONS Why doesn't the dehumidifier seem to extract much water if the temperature is low? This is a compressor dehumidifier which works best in temperatures above 15 C. If the temperature is low and the air is dryer than the setting on the humidistat the unit will not extract water. -
Page 28: Troubleshooting
Tank is full or is not in the right position-- Empty the tank light notification and replace in the right position. Any other malfunctions will need to be reported to electriQ service centre. Do not attempt unauthorised repairs as these may invalidate the warranty. -
Page 29: Technical Specification
Lowfields Way, Elland West Yorkshire, HX5 9DA DECLARATION OF CONFORMITY Hereby, electriQ declares that this Portable air conditioner is in compliance with Directive 2014/53/ EU. The full text of the EU declaration of conformity is available at the following internet address:...
