Summary of Contents for Teka IBF 63210 SSM BK
- Page 2 INSTALLATION INSTRUCTIONS AND RECOMMENDATIONS FOR USING AND MAINTAINING CERAMIC HOT PLATES TOUCH CONTROL....................XX INSTRUCCIONES PARA LA INSTALACIÓN Y RECOMENDACIONES DE USO Y MANTENIMIENTO ENCIMERAS VITROCERÁMICAS TOUCH CONTROL...................XX INSTRUCTIONS POUR L'INSTALLATION ET CONSEILS D'UTILISATION ET D'ENTRETIEN PLAQUES DE CUISSON VITROCÉRAMQIUE TOUCH CONTROL...............XX INSTRUÇÕES DE INSTALAÇÃO E RECOMENDAÇÕES PARA A UTILIZAÇÃO E MANUTENÇÃO PLACAS DE COZINHA VITROCERÂMICAS TOUCH CONTROL..............XX...
- Page 3 Presentation/Presentación/Présentation/Apresentação...
- Page 4 ó i ç ã í â t í Installation 1. Selection of installation equipment Cut out the work surface according to the sizes shown in the drawing. For the purpose of installation and use, a minimum of 5 cm space shall be preserved around the hole. Be sure the thickness of the work surface is at least 12mm.
- Page 5 Instalación / Instalação / Installation / Installation Distancias mínimas / Distâncias mínimas / Minimum distances / Distances minimales Note: There are ventilation holes around outside of the hob. YOU MUST ensure these holes are not blocked by the worktop when yo u put the hob into position.
- Page 6 Instalación / Instalação / Installation / Installation Distancias mínimas / Distâncias mínimas / Minimum distances / Distances minimales 6. Cautions The induction hotplate must be installed by qualified personnel or technicians. We have professionals at your service. Please never conduct the operation by yourself. The hob will not be installed directly above a dishwasher, fridge, freezer, washing machine or clothes dryer, as the humidity may damage the hob electronics The induction hotplate shall be installed such that better heat radiation can be ensured to enhance its reliability.
- Page 7 Heating zone selection controls Heating zone selection controls Flexible Area control Boost On/Off control 3. Technical Specification Cooking Hob IBF 63210 SSM BK Cooking Zones 3 Zones Supply Voltage 220-240V~ 50Hz or 60Hz Installed Electric Power 7400W Product Size L×W×H(mm) 590X520X62 Building-in Dimensions A×B (mm)
- Page 8 Safety warnings: occur if inadver- by unsupervised tently another pot or children. Warning. If the pan is placed on it ceramic glass bre- within the detection Children must not aks or cracks, imme- period. Prevent pos- play with the device. diately unplug the sible accidents! stovetop to avoid...
- Page 9 the mains. This time is required to Fig. 2 Installation allow for the complete discharge of the electronic circuitry and thus Installation with cutlery drawer preclude the possibility of electric shock from the cable terminals. If you wish to install furniture or a cutlery drawer under the hob, a Pans with Partial Ferromagnetic separation board must be fitted...
- Page 10 How to use If the display flashes 3. Using the Boost function alternately with the heat setting 1. Start cooking Activate the boost function This means that: Touch the ON/OFF control. After Touching the heating zone selection power on, the buzzer beeps once, •...
- Page 11 6. Timer control As big zone 1. To activate the free area as a You can use the timer in two single big zone, Touching the different ways: Flexible Area control. a) You can use it as a minute minder. In this case, the timer will not turn any cooking zone off when the set time is up.
- Page 12 When the time is set, it will begin When the time is set, it will begin c) Cancel the timer to count down immediately. The to count down immediately. The Touching the heating zone selection display will show the remaining display will show the remaining control that you want to cancel the time.
- Page 13 Confirmation Power Management 2. Press “Lock” key. Function 1. After the desired power setting mode is selected, please press “Lock” key The symbol “S” will be displayed on zone #1 and symbol “E” will be displayed on zone #2. When the timer indicator stops flickering, the power mode is set successfully.
- Page 14 • Turn the steak only once during Cooking Guidelines Heat Settings Boilovers, melts, and hot Pans do not become hot and The touch controls are What? Problem Problem cooking. The exact cooking time sugary spills on the glass appears in the display. unresponsive.
- Page 15 Care and Cleaning Failure code The touch controls are Problem unresponsive. Ceramic plate temperature Problem Possible sensor failure. The controls are locked. The settings below are guidelines only. The exact setting will depend on several factors, including your causes Check the connection or cookware and the amount you are cooking.
- Page 16 Hints and Tips Operation of your appliance can lead to errors and malfunctions. The following tables contain possible causes and notes for resolving an error message or malfunction. It is recommended to read the tables carefully below in order to save your time and money that may cost for calling to the service center. Problem Possible causes What to do...
- Page 17 Failure Display and Inspection The induction hob is equipped with a self diagnostic function. With this test the technician is able to check the function of several components without disassembling or dismounting the hob from the working surface. Troubleshooting 1. Failure code occur during customer using & Solution; Failure code Problem Solution...
- Page 18 2. Specific Failure & Solution Failure Problem Solution A Solution B Check to see if plug is No power supplied. secured tightly in outlet and that outlet is working. The accessorial power board and the display Check the connection. board connected The LED does not failure.
- Page 19 Information for domestic electric hobs Symbol Value Unit Model identification IBF 63210 SSM BK Type of hob Built-in hob 1 zone Number of cooking zones and/or areas 1 area Heating technology(induction cooking zones and cooking Induction cooking zone and areas,radiant cooking zones,solid plates)
- Page 21 TEKA INDUSTRIAL S.A. C/Cajo, 17 - 39011 SANTANDER (Cantabria), SPAIN...
