Removal and Installation Procedures
J1
Screws (T 15)
J5
J2
Power Supply Module
J4
J3
Figure 6-18: Power Supply Module Removal
4. Reinstallation: Do substeps 3a–3c in reverse order to reinstall the power
supply module.
