- Page 1 G5 PDU Installation Manual...
- Page 2 Contents Before You Begin ....................... 4 Overview ......................... 4 Important Safety Information ..................4 Required Tools ....................... 6 Section 1 – Introduction ...................... 6 Classification Overview ....................6 Features ......................... 7 Form Factors ........................8 Load Segment and Phase Distinction ................8 Power Cord Retention ....................
- Page 3 Mounting Options ...................... 20 Mounting Hardware Installation ................. 21 Grounding the PDU ...................... 22 Connecting the Ground Bonding Cable ..............22 Bonding ........................23 Section 3 – Connecting the PDU ..................24 Connecting the PDU to a Power Source ............... 24 Section 4 –...
- Page 4 Overview This document provides installation instructions and configuration instructions to qualified personnel for installing a Panduit Metered, Switched, and Metered & Switched Power Distribution Unit (PDU) into a datacenter rack. Please read all instructions before operating the equipment and save this manual for future reference.
- Page 5 Be sure all circuit breakers are in the off position before connecting input power. Be sure that the devices connected to the Panduit PDU are adjusted for, or otherwise capable of, operation from the same line voltage supplying the PDU.
- Page 6 PDUs can be managed from a Web interface, or a Command Line Interface (CLI), and viewed from the local display. Panduit PDUs are designed for use with all Panduit cabinets and are compatible with most third-party data center racks. The PDU models vary in form factor with several mounting configurations available.
- Page 7 Features The Panduit Monitored, Switched, Monitored per Outlet, and Monitored & Switched PDUs provide the following features: • Lower profile on vertical PDUs – enhances serviceability area in the back of the rack.
- Page 8 2U PDUs can be installed in a U position in the rack. Load Segment and Phase Distinction Panduit G5 PDUs have colored outlets to help distinguish between the different load segments and phases. All Panduit three phase PDUs have different colored outlets (white, light gray, and dark gray) to distinguish the different phases.
- Page 9 Single Phase PDU Example Three Phase PDU Example Universal Input PDU Example There is one exception to the different colored outlets per load segment. The three phase half-height dual sided model has two different load segments on each phase as shown in the illustration below.
- Page 10 Power Cord Retention Integrated Cord Retention Most IEC C13 and C19 outlet on the PDU comes equipped with an integrated cord retention feature. This will allow you to secure the cord to the outlet without a cord retention bracket. The Dual Sided PDU models to not include this feature to save space;...
- Page 11 3. Secure the tie wrap. 4-in-1 combination outlets Provides the ultimate in flexibility by allowing a customer to use an outlet as either a C13/C15 outlet (Image C) or a C13/C15/C19/C21 outlet (Image D) without any modifications. Merely plug in the corresponding power cord to the applicable outlet. Locking Power Cord Optional locking power cords can be used on each IEC C13 (Image A) and C19 (Image B) outlet on the PDUs.
- Page 12 Each vertical PDU has two different mounting hole locations on the sides and back of the PDU for the button installation to assist with mounting in a non-Panduit racks. When installing the mounting buttons, use either mounting holes as a set.
- Page 13 Mounting button installation – outlets facing the back or front of the rack 1. Align and install the mounting buttons with the screw holes on the sides of the PDU. 2. Install the PDU by inserting the mounting buttons into the keyhole slots on the PDU mounting bracket in the rack.
- Page 14 dual sided models. Those units can only mount on its side with outlets facing the back of the rack. Reference the dual sided PDU installation section for installation instructions. Vertical (0U) PDU– Two or More Installation For two full-height (in a 42U/45U/48U rack), two mid-height (in a 42U/45U/48U rack), or four half-height (in a 42U/45U/48U rack) vertical units to be mounted on one side of the rack, all units must be installed with the outlets facing in towards the center of the rack.
- Page 15 of the cabinet and circuit breakers facing the inside of the cabinet when viewing the cabinet from the rear. NOTE: One full-height can be installed per side of rack whereas two half-height models per side (one on the top and the other on the bottom). IM054 REV 10 - G5 INSTALLATION MANUAL Page 15...
- Page 16 Universal Input PDUs Notes: 1. The Universal PDU must be installed by a ‘skilled person’ as defined in the IEC 62368- 1 standard. 2. The ‘skilled person’ shall only interact with the uPDU interconnect with the facility side connector disconnected. 3.
- Page 17 On the rack, maintaining the spacing between top and bottom PDU brackets, move both PDU brackets up until the top PDU bracket reaches how far it can go up. Install Universal Input PDUs to PDU brackets. NOTE: When installing Universal Input PDUs with input cord at the top, top three RUs might be obstructed at the back by the input cord plug.
- Page 18 and will show the incorrect power rating of the PDU. 1. Reference the User Manual for instructions to connect to the Web interface. 2. Navigate to the System Management page under setting. System Management Navigation 3. Select Set Input Cord under actions. Set Cord Type 4.
- Page 19 5. Select Save and the PDU will reset. Use the following table to determine the correct configuration setting. Cord Part Number NA Region EMEA Region UPDUCRD1 32A3WYE 30A3WYE UPDUCRD2 60A1L-L UPDUCRD3 60A3DLT UPDUCRD4 50A3DLT UPDUCRD5 60A3WYE 63A3WYE UPDUCRD6 20A3WYE 16A3WYE UPDUCRD7 30A1L-L UPDUCRD8...
- Page 20 1. Install the cage nuts at the desired U location. 2. Screw the mounting bracket ears into the RETMA rail surface at the U location where the cage nuts were installed. 2U PDUs Mounting Options IM054 REV 10 - G5 INSTALLATION MANUAL Page 20...
- Page 21 This unit can be installed in any U locations of the rack. Mounting Hardware Installation 1. Install cage nuts at the desired U locations. 2. Install the PDU. IM054 REV 10 - G5 INSTALLATION MANUAL Page 21...
- Page 22 Grounding the PDU Connecting the Ground Bonding Cable Per international regulatory requirements, the primary Safety Earth Bond connection is contained in the PDU as an integral part of the branch circuit cabling and plug. There is an external ground bonding point located on the chassis of the PDU. The ground bonding screw is provided as an attachment point for conductors.
- Page 23 Bond Power Distribution Units (PDUs) to grounding strip or grounding bus bar. See Panduit Grounding and Bonding Jumper kits for factory terminated options to provide a bolt-on solution. Bonding This product contains an external earthing screw with a star washer, which should be used for supplementary Earth bonding to the rack metalwork.
- Page 24 Section 3 – Connecting the PDU Connecting the PDU to a Power Source Always follow local and national codes when installing the PDU. The PDU should be connected to a dedicated circuit protected by a branch circuit breaker matching the PDU input plug type.
