  • Page 1 G5 PDU User Manual...

  • Page 2: Table Of Contents

    Radius Authentication ....................27 G5 PDU LDAP Server Settings ................. 29 Logging in to the CLI ....................32 Section 5 – Remote Access ..................33 Section 6 – Local Display ....................35 OLED Display ......................35 SMARTZONE G5 USER MANUAL...
  • Page 3 Detecting Environmental Sensors................68 Configuring Environmental Sensors ................69 Warranty and Regulatory Information................70 Warranty Information ....................70 Regulatory Information ....................70 Support and Other Resources ..................71 Accessing Panduit Support ..................71 Acronyms and Abbreviations ..................72 SMARTZONE G5 USER MANUAL...
  • Page 4 Upgrade Configuration with Bootloader Mode ............86 Appendix C: PDU Alarms ....................87 Trap Codes assigned to Alarms List ................89 Appendix D: Horizontal Intelligent Network Controller Replacement ......94 Appendix E: Vertical Intelligent Network Controller Replacement ......... 96 SMARTZONE G5 USER MANUAL...

  • Page 5: Section 1

    Section 1 Intelligent Network Controller The Panduit Monitored Input, Monitored & Switched, Monitored per Outlet, and Monitored & Switched per Outlet PDUs have an integral, hot swappable Intelligent Network Controller. The Intelligent Network Controller contains the OLED interface, control buttons, the USB, Ethernet, Serial and Sensor ports, and recessed Reset Button.

  • Page 6: Connecting The Pdu To A Computer Serial Port

    2. Using a CLI command to enable DHCP or set a static IP. 3. Verify access to the Web interface. The Ethernet LED on the PDU front panel provides communication status by color and display activity. The recessed Reset button restarts the PDU (see Figure 2 below). SMARTZONE G5 USER MANUAL...

  • Page 7: Setup Serial Communication

    3. Open the terminal emulation program (HyperTerminal or PuTTY) on the computer and select the serial port connection (such as COM1). 4. Set the communications port as follows: • Bits per second: 115200 • Data bits: 8 SMARTZONE G5 USER MANUAL...
  • Page 8 • Username: admin • Password: 12345678 (or your new password) 6. The “Panduit>” prompt appears after you have logged in, ready to enter the CLI command. 7. To configure network settings, enter the appropriate “net” command and press Enter.
  • Page 9 9. To set a static IPv4 configuration, run: • net tcpip static x.x.x.x (ipaddress) x.x.x.x (netmask) x.x.x.x (gateway) • Example: net tcpip static 192.168.1.100 255.255.255.0 192.168.1.1 • Enter Y to confirm and the PDU’s Intelligent Network Controller will reboot. SMARTZONE G5 USER MANUAL...

  • Page 10: Section 2 - Remote Configuration

    Setup: enter the username and password in the appropriate fields. Press Login or Enter. o If username and password were NOT configured during the Network Configuration Setup, use the default username: admin and password: 12345678. For security purposes, change the password upon login. SMARTZONE G5 USER MANUAL...
  • Page 11 Login Page Introduction to Web GUI SMARTZONE G5 USER MANUAL...
  • Page 12 Information about the PDU can be found using this icon. You also can also click user guide and license to ask for help. This icon shows who is logged in (user or admin). SMARTZONE G5 USER MANUAL...
  • Page 13 Number Icon Description Account passwords can be changed, and user accounts managed through this page. Power Summary Page Power PDU Page SMARTZONE G5 USER MANUAL...
  • Page 14 Environmental Page Security Page SMARTZONE G5 USER MANUAL...
  • Page 15 1. The Change Password window opens directly. Enter the current password and new password twice to confirm. By default, passwords must be between 8 and 32 characters. 2. Click Change Password to complete the password change. SMARTZONE G5 USER MANUAL...
  • Page 16 After initial login, to change the password: 1. Go to User Name>Change Password. 2. The Change User Password window opens. SMARTZONE G5 USER MANUAL...

  • Page 17: Access Types

    • Full • Read-Only The Panduit PDU comes with a standard Full profile and a standard Read Only profile. The Full profile is typically the system administrator and has the “Admin Role” with full operating permissions. The default Read Only profile includes the default “User Role”...
  • Page 18 1. Use the Roles tab to set full or read only privileges. 2. Select Add to save the new user profile. Modify user profile: 1. Go to User Administration>Users. 2. Select the user name. 3. Select Edit. Make changes to the user profile. 4. Select Update. SMARTZONE G5 USER MANUAL...

  • Page 19: Menu Dropdowns

    1. Go to User Administration>Users. 2. Select the red X next to user name. NOTE: To make multiple selections, press Shift + click to highlight multiple profiles. Menu Dropdowns Overview Alarms Help Language Logs Settings Admin SMARTZONE G5 USER MANUAL...

  • Page 20: Section 3 - Simple Network Management Protocol (Snmp)

    Section 3 – Simple Network Management Protocol (SNMP) SNMP Configuration Setup SNMP 1. Access the Web interface and login. 2. Under SNMP Managers, select SNMP General. The SNMP General page displays. 3. The SNMP General includes SNMP Access and Version. SMARTZONE G5 USER MANUAL...
  • Page 21 Setup SNMP Port 1. Access the Web interface and login. 2. Under SNMP Managers, select SNMP Port. The SNMP Port page displays. SMARTZONE G5 USER MANUAL...
  • Page 22 3. Setup SNMP Port and SNMP Trap Port Define SNMP V1/V2c User 1. Access the Web interface and login. 2. Under SNMP Manager, select SNMP V1/V2c. The SNMP V1/V2c page displays. 3. Ensure that SNMP V1/V2c is selected in the SNMP Version field. SMARTZONE G5 USER MANUAL...

  • Page 23: Configuring Users For Snmp V3 Communications

    • Write Community: the SNMP V1/V2c user can edit “private” 6. Click Enable and Update. Configuring Users for SNMP v3 Communications 1. Access the Web interface and login. 2. Under SNMP Managers, select SNMP V3. The SNMP V3 page displays. SMARTZONE G5 USER MANUAL...
  • Page 24 5. Select the “Enable SNMPv3 access” checkbox. (Leave this box blank to restrict SNMP access). • Choose a Security Level from the dropdown menu: • NoAuthNoPriv: No authentication and no privacy. This is the default. • AuthNoPriv: Authentication and no privacy. • AuthPriv: Authentication and privacy. SMARTZONE G5 USER MANUAL...

  • Page 25: Configuring Snmp Traps

    Privacy Pass Phrase, and Confirm Privacy Pass Phrase. Configuring SNMP Traps Setup an SNMP Trap port 1. Access the Web interface and log in. 2. Under SNMP Manager, select SNMP Port. SMARTZONE G5 USER MANUAL...
  • Page 26 3. Set up SNMP Port and SNMP Trap Port. 4. Set up the SNMPV1 trap name, host, and community. SMARTZONE G5 USER MANUAL...

  • Page 27: Section 4 - Local (Access) Configuration

    ([ ]). For data of type array, the 'x' character as index of array in command input syntax means all indexes. You must be logged into the PDU before commands can be sent. See Appendix A for a list of all CLI commands. SMARTZONE G5 USER MANUAL...

  • Page 28: Serial Cable Pinout To Create Your Own Cable

    To make your own RJ45-to-DB9 Serial cable, the connections are wired as shown: Figure: 5 Radius Authentication 1. Go to User Settings > in the admin menu. 2. Go to Radius Configuration and click on the edit pencil. SMARTZONE G5 USER MANUAL...
  • Page 29 3. Select the Enable button. 4. Enter Server IP address field, Port number field, and Secret field. 5. Click save and your Radius authentication is complete. SMARTZONE G5 USER MANUAL...

  • Page 30: G5 Pdu Ldap Server Settings

    8. In the Search User DN field, i.e. DC=subdomain, DC=mydomain, DC=com 10. 9. In the Login Name Attribute field, enter sAMAccountName (typically) 10. In the User Entry Object Class field, enter person. With these LDAP settings configured, the Bind is complete. (see screen shot) SMARTZONE G5 USER MANUAL...
  • Page 31 PDU administrators. i.e. admins Within the G5 PDU Web Interface, go to User Settings (under admin menu) > Roles. Enter the Role Name that was created in AD. i.e. admins Enable role privileges as needed. (see screen shot) SMARTZONE G5 USER MANUAL...
  • Page 32 LDAP authentication is ready to use. To test this, just click save, then click on “LDAP Configuration” again and type an Active Directory user name/password into the test box. Click Test LDAP Configuration. If a box pops up with all green “SUCCEEDED” (no X’s), the LDAP is successfully configured. SMARTZONE G5 USER MANUAL...

  • Page 33: Logging In To The Cli

    Logging in with HyperTerminal To login through HyperTerminal, set the COM settings to the following parameters: • Bits per second: 115200 • Data bits: 8 • Parity: None • Stop bits: 1 • Flow control: None SMARTZONE G5 USER MANUAL...

  • Page 34: Section 5 - Remote Access

    5. Enter your Username. Press Enter. 6. Enter your password. Press Enter. 7. You are now logged into the SSH. Refer to the CLI Commands table below for available commands. NOTE: SSH connection is not available when serial connection is enabled. SMARTZONE G5 USER MANUAL...
  • Page 35 Connect the RJ-45 end of the cable to the Serial+RS485-1 connector. SMARTZONE G5 USER MANUAL...

  • Page 36: Section 6 - Local Display

    Section 6 – Local Display This section contains operation information for the Panduit Monitored, Switched and Monitored & Switched PDUs, including: • OLED panel and control button functions • Manual selections OLED Display The OLED provides information about the PDU and connected devices. The OLED window flashes red when a critical alarm is active.

  • Page 37: Menu Mode

    2. Menu mode (OLED main menu): The settings that display under each high level (main) menu depend on your PDU model. Menu Mode The table below summarizes how to use the control buttons on the OLED display. SMARTZONE G5 USER MANUAL...
  • Page 38 LED Unit Status The LED will change colors depending on the state of the PDU. LED State Description Solid Green Normal Operation Solid Red Critical Alarm Solid Orange Warning Alarm SMARTZONE G5 USER MANUAL...

  • Page 39: Oled Menu Structure

    The PDU menu selection hierarchy consists of Setup, Alarms, Power, and Sensors. On the main menu, scroll down to highlight Setup. Press Select. Scroll down to select a submenu and press Select to display the submenu options. Press Menu to return to the previous menu. SMARTZONE G5 USER MANUAL...

  • Page 40: Setup Menu

    Scroll down to highlight the selected option from the menu. Press Select to display the screens to set the values for the selected option. After you select the values, press Select to set the values as displayed on the screen. Press Menu to return to the previous menu. SMARTZONE G5 USER MANUAL...
  • Page 41 Firmware version. On the Setup menu, scroll down to highlight Device submenu. Press Select to display the option screens. After you make the selections, press Select to set the values as displayed on the screen. Press Menu to return to the previous menu. SMARTZONE G5 USER MANUAL...
  • Page 42 On the Setup menu, scroll down to highlight Screen. Press Select to display the screens to set the values for the submenu. After you select the values, press Select to set the values as displayed on the screen. Press Menu to return to the previous menu. SMARTZONE G5 USER MANUAL...
  • Page 43 Setup menu, scroll down to highlight Lang. Press Select to display the screens to set the values for the submenu. After you select the values, press Select to set the values as displayed on the screen. Press Menu to return to the previous menu. SMARTZONE G5 USER MANUAL...
  • Page 44 On the Setup menu, scroll down to highlight USB. Press Select to display the screens to set the values for the submenu. After you select Yes, press Select to set the values as displayed on the screen. Press Menu to return to the previous menu. SMARTZONE G5 USER MANUAL...
  • Page 45 SMARTZONE G5 USER MANUAL...
  • Page 46 Alarms. Press Select to display the first active alarm screen. Scroll down if needed to view active alarm data. When you finish your review, press Menu to return to the main menu. If the backlight was blinking red to indicate an active alarm, the backlight returns to normal. SMARTZONE G5 USER MANUAL...

  • Page 47: Power Menu

    The Power menu manages device, phase, breaker and outlet. On the Main Menu, scroll down to highlight Power. Press Select. Scroll down to select a submenu and press Select to display the submenu options. Press Menu to return to the previous menu. SMARTZONE G5 USER MANUAL...
  • Page 48 Phase. Press Select to display the screens to set the values for the submenu. After you select the values, press Select to set the values as displayed on the screen. Press Menu to return to the previous menu. SMARTZONE G5 USER MANUAL...
  • Page 49 Press Select to display the screens to set the values for the submenu. After you select the values, press Select to set the values as displayed on the screen. Press Menu to return to the previous menu. SMARTZONE G5 USER MANUAL...
  • Page 50 FOR 1-PHASE WITH BREAKERS FOR 3-PHASE WITH 6 BREAKERS SMARTZONE G5 USER MANUAL...

  • Page 51: Sensors Menu

    The Sensor menu is to display temperature, humidity, door switch, fluid leak etc. On the Main Menu, scroll down to highlight Sensor. Press Select. Scroll down to select a submenu and press Select to display the submenu options. Press Menu to return to the previous menu. SMARTZONE G5 USER MANUAL...

  • Page 52: G5 Ipdu Outlet Power Sequence Setup

    NOTE: Maximum of 4 sensors are configured per PDU. G5 iPDU Outlet Power Sequence Setup 1. From the PDU GUI Home menu select Control & Manage. SMARTZONE G5 USER MANUAL...
  • Page 53 2. Select Outlet Control Enabled SMARTZONE G5 USER MANUAL...
  • Page 54 3. For each Outlet select the Edit pencil. 4. In the Edit Outlet window enter the Delay time (0-7200 seconds) then select Save. SMARTZONE G5 USER MANUAL...
  • Page 55 5. Your Outlet Power Sequence has been set. SMARTZONE G5 USER MANUAL...

  • Page 56: Section 7 - Daisy Chain Configuration

    1. Locate a CAT-5 cable. Connect one end of the cable to one PDU. Connect the other end of the cable to the other PDUs. See Figure 3 for the location on the front panel of each model type. SMARTZONE G5 USER MANUAL...

  • Page 57: Rna (Redundant Network Access) Functionality

    • Each PDU is separately connected to the Slave or Master’s private communications network. • The two PDUs are connected with a data communications bus to allow PDUs to share user-defined information. • Each PDU acts like a master PDU to report PDU data to both networks. SMARTZONE G5 USER MANUAL...

  • Page 58: Rna Setup

    ‘12345678’. This account is configured for proper access and control in RNA mode. 6. To enable this account, login to the CLI with admin credentials. 7. Enter the command ‘dev daisy dna init’. 8. The following message will appear to confirm the landlord account is enabled: SUCCESS. SMARTZONE G5 USER MANUAL...
  • Page 59 9. RNA is now configured and enabled. SMARTZONE G5 USER MANUAL...

  • Page 60: Section 8 - Connecting And Configuring Optional Hardware

    Hardware Accessory Hardware Overview Panduit G5 Monitored, Switched, Monitored per Outlet, and Monitored & Switched per Outlet PDUs can monitor environmental conditions of a rack with the addition of optional SZ G5 environmental sensors. Conditions such as temperature, humidity, leak detection, and intrusion can be monitored with the sensors.
  • Page 61 All Panduit G5 PDUs have two physical sensor ports, and each PDU can collect a total of eight sensor measurements (or readings). For example, if a PDU has an Open/Close...
  • Page 62 Up to six physical sensors can be supported per PDU with the addition of the optional sensor port hub Figure: Sensor Ports for vertical PDU SMARTZONE G5 USER MANUAL...

  • Page 63: Connecting A Temperature Sensor

    4. Plug the sensor cable (or the connected Ethernet cable) into the Sensor-1 or Sensor-2 port on the PDU or into the sensor port hub (if applicable). SMARTZONE G5 USER MANUAL...

  • Page 64: Connecting A Temperature And Humidity Sensor

    4. Plug the sensor cable (or the connected Ethernet cable) into the Sensor-1 or Sensor-2 port on the PDU or into the sensor port hub (if applicable). Connecting a 3-Temperature and 1-Humidity Sensor SMARTZONE G5 USER MANUAL...

  • Page 65: Connecting A Rope Fluid Leak Sensor

    NOTE 1: This kit includes one 6m leak sensor rope. Additional length can be added using option kit (includes one 6m leak sensor rope extension). Up to four of the 6m length leak sensor rope extensions can be connected for a total of 30m. SMARTZONE G5 USER MANUAL...

  • Page 66: Connecting The Open/Closed Door Sensor

    This MUST be used in the detection area. NOTE 3: If mounting to a cabinet or wall, use the adhesive-backed mount (provided). The adhesive-backed mount in the detection area may prevent or delay leakage notification. Connecting the Open/Closed Door Sensor SMARTZONE G5 USER MANUAL...
  • Page 67 4. Stick switch sensor to the inner frame of the rack while aligning it with the magnetic sensor mounted to the door. 5. Stick switch sensor to rack frame using adhesive. Location can be determined by the customer, but should be opposite the door hinge. SMARTZONE G5 USER MANUAL...
  • Page 68 6. Mounting magnetic sensor to the front door. Stick magnetic sensor to inner door frame aligned with rack sensor using the adhesive strip. 7. Mounting position of sensors to the front door is shown in figure below. SMARTZONE G5 USER MANUAL...

  • Page 69: Connecting The Sensor Hub

    Detecting Environmental Sensors The sensor serial number is listed in the Web interface when the sensor is detected. To identify each detected environmental sensor: 1. Open the Dashboard. 2. View the External Sensors section on the Dashboard page. SMARTZONE G5 USER MANUAL...

  • Page 70: Configuring Environmental Sensors

    3. Select Edit button to configure the desired sensors. 4. In the Edit Extension dialog box, type value of up critical, up warning, low warning, and low critical. 5. Select Save to exit the sensor setup. Repeat this process for additional sensors. SMARTZONE G5 USER MANUAL...

  • Page 71: Warranty And Regulatory Information

    Warranty and Regulatory Information Warranty Information (http://www.Panduit.com) Regulatory Information Safety and regulatory compliance For important safety, environmental, and regulatory information, see Safety and Compliance Information at the Panduit website (http://www.Panduit.com) SMARTZONE G5 USER MANUAL...

  • Page 72: Support And Other Resources

    Support and Other Resources Accessing Panduit Support • For live assistance, go to the Panduit.com website • To access documentation and support services, go to the Panduit website. SMARTZONE G5 USER MANUAL...

  • Page 73: Acronyms And Abbreviations

    Acronyms and Abbreviations Alternating Current Kilo-volt-ampere Power Distribution Unit SMARTZONE G5 USER MANUAL...

  • Page 74: Documentation Feedback

    Documentation Feedback Panduit is committed to providing documentation that meets your needs. To help us improve the documentation, send any errors, suggestions, or comments to Documentation Feedback (CS@Panduit.com). When submitting your feedback, include the document title, part number, edition, and publication date located on the front cover of the document.

  • Page 75: Appendix A: Cli Commands

    Panduit>sys time time. Panduit>sys time 14:35:34 sys ntp <IP Address> Synchronize system date >sys ntp 69.25.96.13 and time, with ntp server NOTE: IP Address must be a you set. valid ntp, server address otherwise, executes, failed SMARTZONE G5 USER MANUAL...
  • Page 76 NOTE 2: If in daisy chain configuration, master will also upgrade its all slave’s firmware. sys upd boot Update system’s Panduit>sys upd boot bootloader. E801 system will enter upgrade mode after reboot System Reboot now, Are you sure?(Y/N):Y SMARTZONE G5 USER MANUAL...
  • Page 77 Panduit>sys log del data, SUCCESS Panduit> Network Commands Command Description Example net ssh [on/off] Query or on/off SSH. Panduit>net ssh SUCCESS, SSH Port: 22 SSH Server is running Panduit>net ssh on SUCCESS Panduit>net ssh off SUCCESS SMARTZONE G5 USER MANUAL...
  • Page 78 Please reboot to validate System Reboot now, Are you sure?(Y/N): Y net tcpip<static ip, mask, Set static IP, mask and Panduit>net tcpip static gateway> gateway. 192.168.30.39 255.255.255.0 192.168.30.1 E801 Network is reconfigured, Please reboot to validate SMARTZONE G5 USER MANUAL...
  • Page 79 [on|off] Query or on/off USB. Panduit>dev usb Panduit>dev usb off Panduit>dev usb on dev daisy [dna|qna] Query or set daisy chain Panduit>dev daisy mode. SUCCESS daisy chain unit number: 1 daisy chain address list: SMARTZONE G5 USER MANUAL...
  • Page 80 NOTE 2: PDUID index from 1; if in daisy chain, the master's PDUID is 1, others is ,2,3, dev outlet <PDUID> Query or set specified Panduit> dev outlet 1 1 off <outlet index> [on|off] PDUID and outlet-index's SUCCESS outlet status. NOTE: For Monitored PDUs, this command is invalid.
  • Page 81 Serial: , , , , , FuncType: PDU Monitored Rating :220-240V, 16A, 3.5-3.8kVA, 50/60Hz Mac :C8:45:44:66:2B:26 Tcpip :192:168:30:38 Panduit>pwr unit 1 SUCCESS PDU UNIT 1 power Feature voltage: 0V current : 0.0A active power: 0W apparent power: 0W SMARTZONE G5 USER MANUAL...
  • Page 82 [idx] Query specified outlet’s Panduit> pwr outlet 1 electric information. SUCCESS PDU OUTLET 1 power Feature voltage: 0V current : 0.0A active power: 0W apparent power: 0W NOTE: For Monitored PDUs, this command is invalid. SMARTZONE G5 USER MANUAL...

  • Page 83: Appendix B: Firmware Update Procedure

    1. Open the User interface in a web browser by entering the PDU IP address. 2. Login to with Administration credentials. 3. Go to System Management >Update Firmware. 4. In the Firmware Update dialog box, browse to Panduit.FW firmware file. SMARTZONE G5 USER MANUAL...
  • Page 84 NOTE: the firmware file must be named Panduit.FW or Panduitvxx.FW. 5. Select Upload. The system will update the newest firmware to the Intelligent Network Controller. SMARTZONE G5 USER MANUAL...

  • Page 85: Serial (Command Line Interface) Method

    Serial (Command Line Interface) Method To access a PDU, directly connect to serial connection. 1. Copy the Panduit.fw file in /(root) directory using ftp. 2. Connect to the PDU via Serial using hypertrm. Press Enter. 3. Login by using a role with administration privileges.

  • Page 86: Ftps Method

    1. Login to a FTPs program with a role with administration privileges. 2. Transfer the updated Panduit.fw file to the folder labeled fw. Close the FTPs. 3. Connect to the PDU via SSH using a program such as HyperTerm or PuTTY.

  • Page 87: Firmware Recovery With Bootloader Mode

    2. Select the Enable USB Access Checkbox. To upload configuration, you must: Copy conf.ini to USB. Insert USB to PDU. Enter USB mode in OLED device. Select Conf up. After the operation is completed, remove USB, and quit USB mode. SMARTZONE G5 USER MANUAL...

  • Page 88: Appendix C: Pdu Alarms

    Circuit Breaker Status ON Circuit Breaker Status OFF Outlet X Active Power Above upper critical Outlet X Active Power Above upper warning Outlet Outlet X Active Power Below lower warning Outlet X Active Power Below lower critical SMARTZONE G5 USER MANUAL...
  • Page 89 System Communication Lost Daisy Chain state changed USB Port User Activity User X Authentication failure User Activity User X User logged in User Activity User Activity User X Session timeout User Activity User X User blocked SMARTZONE G5 USER MANUAL...

  • Page 90: Trap Codes Assigned To Alarms List

    The circuit breaker (1-12) current is BELOW critical threshold value 39-50 The circuit breaker (1-12) is in OFF state 51-98 The outlet (1-48) active power is ABOVE critical threshold value 99-146 The outlet (1-48) active power is BELOW critical threshold value SMARTZONE G5 USER MANUAL...
  • Page 91 The phase 1 current is BELOW warning threshold value. 214-225 The circuit breaker (1-12) current is ABOVE warning threshold value. 226-237 The circuit breaker (1-12) current is BELOW warning threshold value. 238-249 The circuit breaker (1-12) is in OFF state. SMARTZONE G5 USER MANUAL...
  • Page 92 The outlet (1-48) IMMEDIATE REBOOT occurred. 632-679 The outlet (1-48) DELAYED REBOOT occurred. 680-727 The outlet (1-48) Cancel Pending Commands occurred. 728-735 The sensor (1-8) contact state is in cleared. Event log Cleared. Data log Cleared. PDU configuration file Imported. SMARTZONE G5 USER MANUAL...
  • Page 93 User xxx modified. Trap codes assigned for information alarms: Trap Class Trap Trap Description Code Clear The PDU unit active power is alarm clear. 771-773 The phase (1-3) voltage alarm cleared 774-776 The phase (1-3) current alarm cleared SMARTZONE G5 USER MANUAL...
  • Page 94 777-788 The circuit breaker (1-12) current alarm cleared 789-836 The outlet (1-48) active power current alarm cleared. 837-844 The sensor (1-8) temperature/humidity alarm cleared. SMARTZONE G5 USER MANUAL...

  • Page 95: Appendix D: Horizontal Intelligent Network Controller Replacement

    Appendix D: Horizontal Intelligent Network Controller Replacement 1. Unscrew the left and right captive nuts on the Intelligent Network Controller by turning them counter clockwise. 2. Pull out the Intelligent Network Controller from the PDU. SMARTZONE G5 USER MANUAL...
  • Page 96 3. Insert the new Intelligent Network Controller. 4. Align the Intelligent Network Controller and tighten the captive nuts by turning them clockwise. SMARTZONE G5 USER MANUAL...

  • Page 97: Appendix E: Vertical Intelligent Network Controller Replacement

    1. Use a T10 Torx screwdriver to remove the top and bottom screws from the Intelligent Network Controller. 2. Disconnect the existing signal wire from the Intelligent Network Controller. Connect the signal wire to the new Intelligent Network Controller. SMARTZONE G5 USER MANUAL...
  • Page 98 Signal wire 3. Replace and tighten the two screws on the replacement Intelligent Network Controller into the PDU. SMARTZONE G5 USER MANUAL...
