Eagle AXS
EAGLE AXS SYSTEMS STANDARD OPERATING PROCEDURE
EAGLE AXS-SYSTEME STANDARDVERFAHREN
GEN.0000000005971 Rev A © 2019 SRAM, LLC

Advertisement

loading
Need help?

Need help?

Do you have a question about the Eagle AXS and is the answer not in the manual?

Questions and answers

Related Manuals for SRAM Eagle AXS

Summary of Contents for SRAM Eagle AXS

  • Page 1 Eagle AXS EAGLE AXS SYSTEMS STANDARD OPERATING PROCEDURE EAGLE AXS-SYSTEME STANDARDVERFAHREN GEN.0000000005971 Rev A © 2019 SRAM, LLC...
  • Page 2 • Cassette tool with 7-8 mm splines • Kassettenwerkzeug with 7-8 mm splines • D1 Flattop Chain tool (eg. Park Tool® CT-3.3) • D1 Flattop Chain tool (eg. Park Tool® CT-3.3) • Eagle AXS Chaingap Gauge • Eagle AXS-Kettenabstandswerkzeug Lubricants and Fluids Schmiermittel, Öle und Flüssigkeiten •...
  • Page 3 Installationsvorgänge Cassette Installation Einbau der Kassette DUB™ Bottom Bracket Installation Einbau des DUB-Innenlagers Crankset Installation Einbau der Kurbelgarnitur SRAM® Battery Installation Einsetzen der SRAM-Batterien System Pairing Koppeln des Systems AXS™ Button Shifting Schalten mit der AXS-Taste Rear Derailleur Installation Einbau des Schaltwerks...
  • Page 4 AXS Installation Color Coding Farbcodierung The color coding in this manual provides a quick way of understanding the action that will be performed in each step of the installation. Refer to this chart for more information about how each color is used. Die Farbcodierung in dieser Anleitung bietet einen schnellen Überblick über die Aktion, die bei jedem Montageschritt durchgeführt wird.
  • Page 5 AXS Installation Cassette Installation Kassetten Installation NOTICE Cassette lockring tool splines must fully engage the cassette lockring or locktube (XD). 7-8 mm Splines must be between 7 and 8 mm in length for XD cassettes. HINWEIS 40 N·m Das Profil des Sicherungsring- Werkzeugs der Kassette muss vollständig in den Sicherungsring oder das...
  • Page 6 AXS Installation DUB™ BSA Bottom Bracket Installation Einbau des DUB BSA-Innenlagers 73 Guide 68, 73, 83, 100 mm 68, 83, 100 mm 73 SB+ Guide 50 N·m 50 N·m 1. Apply grease that is safe for the bottom bracket frame material. 2.
  • Page 7 AXS Installation DUB™ BSA Bottom Bracket Installation Einbau des DUB BSA-Innenlagers 73 Guide 68, 73, 83, 100 mm 68, 83, 100 mm 73 SB+ Guide 50 N·m 50 N·m 1. Tragen Sie ein Fett auf, das für das Material des Innenlagers sicher ist. 2.
  • Page 8 AXS Installation DUB™ Bottom Bracket Installation Einbau des DUB-Innenlagers 73, 89.5, 92, 104.5, 107, 121 mm Ø41 mm Ø42 mm Ø46 mm 1. Apply grease that is safe for the bottom bracket frame material. 2. After confirming the five-way dimensions of the bottom bracket shell, select the corresponding BB part number. 1.
  • Page 9 AXS Installation DUB™ Bottom Bracket Installation Einbau des DUB-Innenlagers DUB BB30™ DUB PressFit 89.5 DUB PressFit 30™ DUB PressFit 92 / DUB PressFit 92 SB+ DUB PressFit 104.5 DUB PressFit 107 (DH) DUB PressFit 121 (Fat Bike) 1. Remove the left side cup from the center tube. 2.
  • Page 10 AXS Installation DUB™ Bottom Bracket Installation Einbau des DUB-Innenlagers 1. Use a bottom bracket bearing press tool or a headset press to install the left side cup into the non-drive side of the frame. 2. Install the right side cup and center tube bearing cup into the drive side of the frame. NOTICE When pressing in, be sure to check that the boot is properly aligned to the left BB.
  • Page 11 AXS Installation DUB™ Bottom Bracket Installation Einbau des DUB-Innenlagers DUB BB30™ 73-A / DUB PressFit 30™ 73-A DUB PressFit 92 / DUB PressFit 121 (Fat Bike) DUB PressFit 89.5 DUB PressFit 92 / DUB PressFit 92 SB+ DUB PressFit 104.5 DUB PressFit 107 (DH) 1.
  • Page 12 AXS Installation DUB™ Crankset Installation Einbau der DUB-Kurbelgarnitur 54 N·m 1. Apply grease to the spindle. 2. Tighten the crank arm bolt to 54 N·m. 3. Use a rubber or plastic mallet to tap the drive side crank arm until it is fully seated. 1.
  • Page 13 AXS Installation DUB™ Crankset Installation Einbau der DUB-Kurbelgarnitur 1. Turn the preload adjuster in the + direction until it stops or makes contact with the bearing shield. 2. Tighten the bolt until the adjuster edges touch. N OT I CE Do not overtighten the preload adjuster as this could damage the bearing.
  • Page 14 AXS Installation DUB™ Crankset Installation Einbau der DUB-Kurbelgarnitur Check the crankset for play by rocking the crank arms back and forth. If there is play in the crankset, remove the crank arms and apply additional grease to the spindle. Turn the preload adjuster in the opposite direction of the + sign until it stops. Repeat the installation procedure until play is eliminated.
  • Page 15 NOT I CE Do not discard the derailleur battery block (A) or the battery cover (B). Insert the fully charged SRAM battery into the derailleur and close the battery latch. When installed correctly, the latch will snap into place. H I N WE I S Bewahren Sie den Batterietrenner (A) und die Batterieabdeckung (B) für das Schaltwerk auf.
  • Page 16 AXS Installation System Pairing Koppeln des Systems 1. Press and hold the AXS button until the green LED blinks slowly, then release. 2. Press and hold the AXS button on the controller until the green LED blinks quickly, then release. 3.
  • Page 17 AXS Installation AXS™ Button Shifting Schalten mit der AXS-Taste Press and release the AXS™ button on the rear derailleur once to move the derailleur outboard one position, or twice quickly to move inboard one position. Drücken Sie die AXS-Taste am Schaltwerk einmal und lassen Sie sie wieder los, um das Schaltwerk um eine Position nach außen zu bewegen.
  • Page 18 AXS Installation Rear Derailleur Installation Einbau des Schaltwerks B-Adjust Washer 11 N·m NOT I CE Do not apply grease to the mounting bolt or derailleur hanger threads. Push the B-adjust washer forward when installing the derailleur. Make sure there is no gap between the B-Adjust washer and the derailleur hanger.
  • Page 19 AXS Installation Chain Installation Montage der Kette 1. Wrap the chain around the chainring and largest cassette cog. 2. For full suspension bicycles, add one inner link and one outer link where the chain starts to overlap. For hardtail bicycles, add two inner links and two outer links where the chain starts to overlap.
  • Page 20 AXS Installation Chain Installation Montage der Kette 1. Place the chain onto the smallest cassette cog. 2. Rotate the derailleur cage forward and press the Cage Lock lock button to lock the derailleur in the extended position. 3. Route the chain through the derailleur pulleys. Make sure to route the chain below the tab in the cage. ⚠...
  • Page 21 AXS Installation Chain Installation Montage der Kette Pull each end of the chain together and install the PowerLock. Press the PowerLock connector links together. N OT I C E The arrow must point in the direction of chain travel before locking the PowerLock into place. Once locked, the PowerLock cannot be disconnected.
  • Page 22 AXS Installation Chain Gap Adjustment with Gauge Einstellung des Kettenabstands mit dem Kettenabstandswerkzeug B-Adjust Screw 1. Shift the rear derailleur inboard to the largest cog. 2. Install the chain gap adjustment gauge onto the upper pulley. 3. To make an adjustment, rotate the derailleur clockwise around the B-Adjust washer to relieve tension on the B-Adjust screw. Turn the B-Adjust screw, then release the derailleur.
  • Page 23 AXS Installation Chain Gap Adjustment without Gauge Einstellung des Kettenabstands ohne Werkzeug B-Adjust Screw 5 mm 1. Shift the chain into the 2nd largest cassette cog. 2. The gap between the tallest teeth of the largest cassette cog and the upper pulley must be 5 mm. 3.
  • Page 24 AXS Installation Rear Derailleur Adjustments Einstellung des Schaltwerks 1. Align the upper pulley with the center of the 2nd-largest cog by adjusting the rear derailleur: 2. Press and hold the controller AXS button while pressing the paddle. Press downward on the paddle to adjust the derailleur inboard, and press upward on the paddle to adjust the derailleur outboard.
  • Page 25 AXS Installation Rear Derailleur Adjustments Einstellung des Schaltwerks 1. Shift the rear derailleur inboard to the largest cog. 2. Adjust the low limit screw (L) so that it lightly contacts the outer link of the derailleur, then back the screw out a 1/4 turn. 3.
  • Page 26 AXS Installation AXS Controller Installation Separate Klemmschelle für AXS-Steuerung 3 N·m 2 N·m 2 N·m 1. Apply friction paste to the inner clamping surface when installing on carbon fiber handlebars. ⚠ WA RN I N G - CR AS H HA ZA R D Failure to apply friction paste may lead to the clamp slipping which may cause the rider to crash, resulting in serious injury or death.
  • Page 27 AXS Installation AXS Controller Installation MMX-Schelle für AXS-Steuerung 5.5 N·m 3 N·m 1. Apply friction paste to the inner clamping surface when installing on carbon fiber handlebars. 2 N·m ⚠ WA RNING - CR AS H H A ZA R D Failure to apply friction paste may lead to the clamp slipping which may cause the rider to crash, resulting in serious injury or death.
