USER MANUAL
MODEL: DG-8CA01
ELECTRIC STROLLER
CONTACT US
Before returning your product, please contact us first! Voltz
Toys Customer Service can assist you with any replacement
parts, damages, or defective issues reported. You can contact
us directly at www.voltztoys.ca.
Email: help@voltztoys.ca
Phone number: 1-888-338-6589
Head Office: Unit 7-3600A Laird Rd, Mississauga, ON, L5L
6A6
COMPLIANCE STANDARDS:
SOR/2011-17
SOR/2018-138
SOR/2016-195
SOR/2016-302
SOR/2018-83
SOR/2016-188
SOR/2014-254
EN71
ASTM F963-17
CPSIA
ENGLISH
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for DAAN Groups Voltz Toys DG-8CA01
Summary of Contents for DAAN Groups Voltz Toys DG-8CA01
- Page 1 Toys Customer Service can assist you with any replacement parts, damages, or defective issues reported. You can contact us directly at www.voltztoys.ca. A subdivision of The DAAN Groups Email: help@voltztoys.ca Phone number: 1-888-338-6589 Head Office: Unit 7-3600A Laird Rd, Mississauga, ON, L5L...
- Page 2 Please read the manual before using the product. The manual and carton contain important information. Please keep the manual for later references. Failure to follow the instructions in the manual may result in damages, acci- dents, or defective issues with the product. To improve the product and quality, we may alter the structure, appearance, packing method, assembly method, and product function without any no- tice.
- Page 3 PARTS LIST...
- Page 5 PRODUCT SPECIFICATIONS Car Model DG-8CA01 Battery 24V7AH*2 Suitable age 37-95 months Weight Limit 50 kg Product Size 145 x 84.5 x 79.5 cm Speed 3-8 km / hour Electric motor 24V12000 RPM of driving motor (4 motors) Charging time 8-12 hours AC 220V/110V (input) Charger DC 24V1000mA/28.8V800mA (output)
- Page 6 1. FRONT AXLE ASSEMBLY Parts required: #17, #21 Start the installation with up-side-down position. Remove the bolt/nut set from the centre section of the front axle as shown in the diagram. Slide the axle brackets into the short porting of the steering column, place the washer and secure the connection with cotter pin.
- Page 7 Adjust the the loose side of the axle to right position, fix it with the main frame of the axle with the bolt/nut set. 2. FRONT WHEEL ASSEMBLY Parts required: #8, #9, #11, #17, #18, #20 Slide the front wheel into the axle. then the M12 washer. Secure the con- nection with M10 nut.
- Page 8 3. REAR WHEEL ASSEMBLY Parts required: #8, #10, #11, #12, #17, #18, #20 Slide the corresponding motor (labeled L/R) through the axle for given side. Connect the power cable. Slide the rear wheel into the axle. then the M12 washer. Secure the connection with M10 nut. Note, both sides need to be tightened at the same time.
- Page 9 4. POWER CONNECTION Parts required: N/A Connect the power supply cable from the battery to the car body. Slide the charging port into designated socket as shown on the diagram. 1. Connect the power cable. 2. Charging hole on the car body. Remove four screws can take the battery box to...
- Page 10 (2) Using the handle to pull the second seat to furthest location, slide the seat into the designated position and secure the instillation.
- Page 11 6. STEERING WHEEL ASSEMBLY Parts required: #6 A. Connect the cable from steering wheel with car. B. Slide as much cable as possible through the opening. Slide the steering wheel through the steering column, align the opening and secure the con- nection with M5*35mm bolt and M5 nut set.
- Page 12 8. LEFT, RIGHT AND REAR SAFETY GUARDS ASSEMBLY Parts required: #3, #4, #5, #18 (1) Connect the rear guard bar into designated slots from left/right guard bar as shown on the diagram. Fix the connection with 2 x M4*10mm screws each side.
- Page 13 DASHBOARD 1. Horn and music button 4. Power switch 2. Mp3 music player 5. Forward / Stop / Backward 3. Remote / Manual switch 6. Lights switch MP3 PLAYER 1. USB port 5. Mode (Radio/Bluetooth/SD card/USB) 2. SD card slot 6.
- Page 14 REMOTE CONTROL INSTRUCTION NOTE: This product does not included the AAA(1.5v) 2.4GHz Remote Control Pairing Procedures This remote is equipped with a memory function to retain it’s connection with your car. When replacing the batteries, you do not need to re-pair the remote.
- Page 15 FUSE This car is equipped with an auto-reset fuse. If the car stops suddenly while driving, it is caused by the instantaneous current exceeding, enabling the fuse to trip. This will result in the car disabling for about 8 seconds, and this fuse can be reset.
- Page 16 10. To maintain product life and safety, avoid damaging the charger, battery, or electrical circuit. The car must use the default configuration of the dedicated charger and power supply. 11. Rechargeable batteries should be removed from the toy before charging. 12.
- Page 17 CHARGING PROCEDURES • For safety purposes, charging must be done by adults. • When initially assembled, connect the (red) battery wires under the hood. Charge for 8-12 hours before using. • The charging port is located on the dashboard. Follow the instructions to charge the battery.
- Page 18 WARNING 1. The assembly of the car must be done by an adult. When unassembled, it contains potentially hazardous parts that are sharp or small. Please keep out of children’s reach. 2. Choking hazards of small parts. 3. Not for children under 36 months. Recommended for 37-95 months. 4.
- Page 19 MAINTENANCE AND SERVICE 1. Before using, adults are responsible for reviewing the product and es- sential parts are in a functional condition. Check whether screws are loose or other potential hazards. Any damaged or defective parts must be repaired or resolved before using. 2.
- Page 20 14. Low batteries should be removed from the car and kept away from chil- dren. 15. Disconnect the batteries when completely inactive or discontinued. Do not let children use the car in this state. TROUBLESHOOTING...
