USER MANUAL
MODEL: DG-82269
CONTACT US
Before returning your product, please contact us first! Voltz
Toys Customer Service can assist you with any replacement
parts, damages, or defective issues reported. You can contact
us directly at www.voltztoys.ca.
Email: help@voltztoys.ca
Phone number: 1-888-338-6589
Head Office: Unit 7-3600A Laird Rd, Mississauga, ON, L5L
6A6
COMPLIANCE STANDARDS:
SOR/2011-17
SOR/2018-138
SOR/2016-195
SOR/2016-302
SOR/2018-83
BOX CAR
SOR/2016-188
SOR/2014-254
EN71
ASTM F963-17
CPSIA
ENGLISH
Advertisement
Table of Contents
Related Manuals for DAAN Groups Voltz Toys DG-82269
Summary of Contents for DAAN Groups Voltz Toys DG-82269
- Page 1 Toys Customer Service can assist you with any replacement parts, damages, or defective issues reported. You can contact us directly at www.voltztoys.ca. A subdivision of The DAAN Groups Email: help@voltztoys.ca Phone number: 1-888-338-6589 Head Office: Unit 7-3600A Laird Rd, Mississauga, ON, L5L...
- Page 2 Please read the manual before using the product. The manual and carton contain important information. Please keep the manual for later references. Failure to follow the instructions in the manual may result in damages, acci- dents, or defective issues with the product. To improve the product and quality, we may alter the structure, appearance, packing method, assembly method, and product function without any no- tice.
-
Page 3: Parts List
PARTS LIST Disclaimer: The pictures in this instruction are for assembly reference only. Please refer to the actual product. WARNING This product is not the vehicle for transportation, it should be used under adult guidance. Parents should ensure that children have taken the safe- ty measures before use. -
Page 4: Product Specifications
PRODUCT SPECIFICATIONS Car Model DG-82269 Battery 12V7AH*2 Suitable age 8- 12 years old Weight Limit 50 kg Product Size 44.5 x 42 x 66 cm Speed 3-8 km / hour Charging time 8-12 hours Charger AC 110-220V (input) DC 24V-1000mA (output) Fuse Auto-reset fuse ASSEMBLY PREPARATION... -
Page 5: Function Description
FUNCTION DESCRIPTION Remove the seat cover, here is a small storage box. There is a variable speed switch on the handle bar, speed controlled by this switch, the harder you press down, the faster the car will be, release the switch, the car will come to a stop. -
Page 6: Footrest Assembly
1. FOOTREST ASSEMBLY Parts required: #1, #3 Slide both sides of foot rest into the car body. Press firmly, then secure the connection with 6x screws each side as shown on the diagram. -
Page 7: Handle Bar Assembly
2. HANDLE BAR ASSEMBLY Parts required: #2 Insert the handle into the designated slot on the car body, fix the connection with bolt/nut set. Connect the matching colour cables. Slide as much cable as possible through the opening, then place the cover and secure it with 2 x screws. -
Page 8: Function Introduction
FUNCTION INTRODUCTION... -
Page 9: Security Warning
FUSE This car is equipped with an auto-reset fuse. If the car stops suddenly while driving, it is caused by the instantaneous current exceeding, enabling the fuse to trip. This will result in the car disabling for about 8 seconds, and this fuse can be reset. - Page 10 10. To maintain product life and safety, avoid damaging the charger, battery, or electrical circuit. The car must use the default configuration of the dedicated charger and power supply. 11. Rechargeable batteries should be removed from the toy before charging. 12.
-
Page 11: Charging Procedures
CHARGING PROCEDURES • For safety purposes, charging must be done by adults. • The charging port is located under the seat. Follow the instructions to charge the battery. 1. First, insert the charger into the charging port. 2. Carefully insert the charger outlet into the power outlet. Please note the car will not turn on when the car is connected. -
Page 12: Maintenance And Service
ATTENTION • Dedicated charger and battery can only be used under manufacturer’s regulations. • Do not mix old, new or different types of batteries. • The battery terminal should not be short circuit. • Do not open the battery or charger. •... - Page 13 4. The car must be kept away from hot objects, such as stoves and heaters. Direct exposure to hot objects will melt the plastic. The car must be kept away from flammable materials to prevent ignition or fire when charging. 5.
-
Page 14: Troubleshooting
TROUBLESHOOTING...
