DAAN Groups Voltz Toys BMW M5 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
A subdivision of The DAAN Groups
USER MANUAL
MODEL: DG-82118
CONTACT US
Before returning your product, please contact us first! Voltz
Toys Customer Service can assist you with any replacement
parts, damages, or defective issues reported. You can contact
us directly at www.voltztoys.ca.
Email: help@voltztoys.ca
Phone number: 1-888-338-6589
Head Office: Unit 7-3600A Laird Rd, Mississauga, ON, L5L
6A6
COMPLIANCE STANDARDS:
SOR/2011-17
SOR/2018-138
SOR/2016-195
SOR/2016-302
SOR/2018-83
BMW M5
SOR/2016-188
SOR/2014-254
EN71
ASTM F963-17
CPSIA
ENGLISH

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Voltz Toys BMW M5 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for DAAN Groups Voltz Toys BMW M5

Summary of Contents for DAAN Groups Voltz Toys BMW M5

  • Page 1 Toys Customer Service can assist you with any replacement parts, damages, or defective issues reported. You can contact us directly at www.voltztoys.ca. A subdivision of The DAAN Groups Email: help@voltztoys.ca Phone number: 1-888-338-6589 Head Office: Unit 7-3600A Laird Rd, Mississauga, ON, L5L...
  • Page 2 Please read the manual before using the product. The manual and carton contain important information. Please keep the manual for later references. Failure to follow the instructions in the manual may result in damages, acci- dents, or defective issues with the product. To improve the product and quality, we may alter the structure, appearance, packing method, assembly method, and product function without any no- tice.

  • Page 3: Parts List

    PARTS LIST...
  • Page 4 OPENABLE BONNET ADJUSTABLE SEAT Pull out the handle under the seat, the seat can be adjusted to front and back. Handle/Poignée...

  • Page 5: Product Specifications

    PRODUCT SPECIFICATIONS Car Model DG-82118 Battery 12V10AH Suitable age 37-95 months Weight Limit 30 kg Product Size 124 x 74 x 55 cm Speed 3-5 km / hour Charging time 8-12 hours Charger AC 110V-220V (input) DC 12V1000mA (output) Fuse Auto-reset fuse ASSEMBLY PREPARATION •...

  • Page 6: Front Wheel Assembly

    1. FRONT WHEEL ASSEMBLY Parts required: #8, #10 Start the installation with the car in up-side-down position. Use the sleeve tool to remove the nut/washer set, slide front wheel on each side of front axle. Place the washer then tighten the nuts for both sides. Place the wheel cover after.

  • Page 7: Windshield Assembly

    3. WINDSHIELD ASSEMBLY Parts required: #2, #14 Flip the car to normal position. Align the windshield to its designated open- ing on the car body. Press firmly until it clicks and fix it with screws. 4. BATTERY CONNECTION Parts required: N/A Open the engine cover, insert fuse at the designated spot.

  • Page 8: Steering Wheel Assembly

    5. STEERING WHEEL ASSEMBLY Parts required: #3, #14 Connect the steering wheel cable with the corresponding cable from the unit. Slide the excess cable through the opening as much as possible. Insert the steering wheel against the steering column, align the column opening with wheel opening.

  • Page 9: Seat Assembly

    6. SEAT ASSEMBLY Parts required: #4, #14 Use the adjust function to slide the seat to first position. Slide the tubes to the opening, and fix the seat with 4 x 16mm flat head screws. 7. MIRROR ASSEMBLY Parts required: #5 Place mirror in corresponding slots located on either side of the car.
  • Page 10 DASHBOARD 1. Mp3 player 5. Speed switch 2. Charging port 6. Gearshift 3. Power switch 7. Pedal 4. Light switch MP3 PLAYER...

  • Page 11: Remote Control Instruction

    REMOTE CONTROL INSTRUCTION NOTE: This product does not included the AAA(1.5v) 2.4GHz Remote Control Pairing Procedures This remote is equipped with a memory function to retain it’s connection with your car. When replacing the batteries, you do not need to re-pair the remote.

  • Page 12: Security Warning

    FUSE This car is equipped with an auto-reset fuse. If the car stops suddenly while driving, it is caused by the instantaneous current exceeding, enabling the fuse to trip. This will result in the car disabling for about 8 seconds, and this fuse can be reset.
  • Page 13 10. To maintain product life and safety, avoid damaging the charger, battery, or electrical circuit. The car must use the default configuration of the dedicated charger and power supply. 11. Rechargeable batteries should be removed from the toy before charging. 12.

  • Page 14: Charging Procedures

    CHARGING PROCEDURES • For safety purposes, charging must be done by adults. • When initially assembled, connect the (red) battery wires under the hood. Charge for 8-12 hours before using. • The charging port is located on the dashboard. Follow the instructions to charge the battery.
  • Page 15 WARNING 1. The assembly of the car must be done by an adult. When unassembled, it contains potentially hazardous parts that are sharp or small. Please keep out of children’s reach. 2. Choking hazards of small parts. 3. Not for children under 36 months. Recommended for 37-95 months. 4.

  • Page 16: Maintenance And Service

    MAINTENANCE AND SERVICE 1. Before using, adults are responsible for reviewing the product and es- sential parts are in a functional condition. Check whether screws are loose or other potential hazards. Any damaged or defective parts must be repaired or resolved before using. 2.

  • Page 17: Troubleshooting

    14. Low batteries should be removed from the car and kept away from chil- dren. 15. Disconnect the batteries when completely inactive or discontinued. Do not let children use the car in this state. TROUBLESHOOTING...
