JACKPOT MACHINE

INITIAL SETUP AND SERVICE FUNCTIONS

USER MANUAL

(rev. 3.0.)

*The manufacturer shall reserve its right to modify and amend the item and this documentation

without prior notification of the customers.

Need help?

Do you have a question about the Cat4Cash Jackpot Machine and is the answer not in the manual?

Questions and answers

Summary of Contents for EGT Cat4Cash Jackpot Machine

Page 1 JACKPOT MACHINE INITIAL SETUP AND SERVICE FUNCTIONS USER MANUAL (rev. 3.0.) *The manufacturer shall reserve its right to modify and amend the item and this documentation without prior notification of the customers. ©2013-2014, Euro Games Technology Ltd.
Page 2 Jackpot Machine INITIAL SETUP AND SERVICE FUNCTIONS REVISION HISTORY Rev.1.0. - an initial document version addressed to the machine software. Rev.1.1. - a new document version with following changes:  The last 4 screens of the Machine Accounting menu are added on pages 23-24. Rev.2.1.
Page 3 Jackpot Machine INITIAL SETUP AND SERVICE FUNCTIONS CONTENTS CHAPTER I. GAMING MACHINE INITIAL SETUP І.1. Gaming Machine Memory Reset…………………………………………….. І.2. Initial Settings of Gaming Machine Parameters……………………………. І.3. Gaming Machine Authorization Procedure…………………………………. Gaming Machine Control Restart………………………………………...…. І.4. CHAPTER II. SERVICE FUNCTIONS II.1.
Page 4 Jackpot Machine INITIAL SETUP AND SERVICE FUNCTIONS SIGNS USED WARNING! Warns about specific conditions or situations of/in the gaming machine, which require due attention. NOTE! Gives important or additional information of the gaming machine, software or the game. ©2013-2014, Euro Games Technology Ltd.
Page 6 Jackpot Machine INITIAL SETUP AND SERVICE FUNCTIONS CHAPTER I. GAMING MACHINE INITIAL SETUP І.1. Gaming Machine Memory Reset…………………………………………….. І.2. Initial Settings of Gaming Machine Parameters……………………………. І.3. Gaming Machine Authorization Procedure…………………………………. І.4. Gaming Machine Control Restart………………………………………...…. ©2013-2014, Euro Games Technology Ltd.
Page 7 NOTE! The authorization can be done before the initial machine setup according to prior arrangement with EGT service (see I.3. Gaming Machine Authorization Procedure). Gaming machine memory reset at any time after the authorization does not require a new authorization.
Page 8 Jackpot Machine INITIAL SETUP AND SERVICE FUNCTIONS To perform machine memory (NVRAM) reset follow the procedure described below: a) Power the machine off; b) The SATA flash card with game has to be put on the SATA1 slot of the Exciter II platform;...
Page 9 (see Service Manual of Vega Vision Series Gamin Machine. For the service manual please contact the EGT service.) After machine memory reset all one-time settable parameters are Not Set. After setting of all Not Set parameters of a given menu, it disappears from the list in Fig I.1.
Page 10 Jackpot Machine INITIAL SETUP AND SERVICE FUNCTIONS The following message appears on the screen after this procedure and the machine has to be restarted: Please, restart the gaming machine! I.2.1. List of One-time Settable Parameters For details about adjustable parameters see II.5. Setup. A list of one-time settable parameters is given below: 1.
Page 11 7. "Setup → Progressive Settings” Menu a) Always Handpay Jackpots: [Not Set/ Enable/ Disable] Cat 4 Cash Settings b) Cat 4 Cash Variant: [Not Set/ 1/ 2/ 3] EGT Mystery Settings c) EGT Mystery Jackpots: [Not Set/ Enable/ Disable] ©2013-2014, Euro Games Technology Ltd.
Page 12 Mystery Jackpot Splash Clear: [Not Set/ Auto/ Key] e) Setting Address in Jackpot Network to 0: [Not Set/ Enable/ Disable] f) Display EGT Mystery Jackpots in the help screens: [Not Set/ Enable./ Disable] 8. "Setup→SAS Setup→Common” Menu a) Voucher In:...
Page 13 Jackpot Machine INITIAL SETUP AND SERVICE FUNCTIONS 12. "Setup → Machine Info Setup” Menu a) Serial Number: 0 b) Asset Number: 0 13. "Setup → Languages Setup” Menu a) English - [Not Set/ Enable/ Disable] b) Bulgarian - [Not Set/ Enable/ Disable] c) French - [Not Set/ Enable/ Disable] 14.
Page 14 Jackpot Machine INITIAL SETUP AND SERVICE FUNCTIONS I.3. GAMING MACHINE AUTHORIZATION PROCEDURE WARNING! Make a connection with the EGT service and fix an exact date and time for online support (at least 2 days before the authorization procedure). WARNING! Authorization process is an event in real time (within 1 hour of machine starting/ login menu OWNER.
Page 15 INITIAL SETUP AND SERVICE FUNCTIONS Base Code is displayed on the screen. Otherwise, it is necessary to phone to the EGT Service and tell the operator your Base Code. You can use Skype, e-mail or SMS, as well. The operator will give you your activation code in reply, which code shall be entered into Enter Code field.
Page 16 Jackpot Machine INITIAL SETUP AND SERVICE FUNCTIONS CHAPTER II. SERVICE FUNCTIONS II.1. Accounting…………………………………………………………………. ….. II.2. Diagnostics……………………………………………………………………... II.3. History of last 50 games……………………………………………………..II.4. Event Logs……………………………………………………………………... II.5. Setup …………………………………………………………………………..II.6. Game Setup…………………………………………………………………..II.7. Service…………………………………………………………………..……… ©2013-2014, Euro Games Technology Ltd.
Page 17 Jackpot Machine INITIAL SETUP AND SERVICE FUNCTIONS MAIN MENU Main Menu is the main page of program service functions and its window is shown on the picture above. If different types of keys are inserted some of the elements of the Main Menu and/or submenus are not displayed (depending on the access rights of the appropriate key).
Page 18 Jackpot Machine INITIAL SETUP AND SERVICE FUNCTIONS II.1. ACCOUNTING II.1.1. Machine Accounting Page 1 These pages contain main statistics of the machine. Data of the electronic counters are shown in two columns. The first column contains machine data from the moment of the last clear of power-independent memory (NVRAM).
Page 19 Jackpot Machine INITIAL SETUP AND SERVICE FUNCTIONS  Winnings from Paytable (Coin Out) - winnings from games (paytable), including double ups;  Winnings from Progressives - winnings from progressives;  Winnings from External Bonuses - winnings from external bonus system (SAS Host or CBJS mystery); ...
Page 20 Jackpot Machine INITIAL SETUP AND SERVICE FUNCTIONS % - theoretical RTP% for game i; Total Bet - total bet for game i; Total BET - total bet for the machine. NOTE: Each TRTP% set is considered as a separate game i. ...
Page 21 Jackpot Machine INITIAL SETUP AND SERVICE FUNCTIONS  Total Out:  Physical Coin Out - amount in money of all tokens, paid out by machine (via a hopper);  Total Winnings Paid by Attendant - amount of all winnings in money, paid out by Attendant, which are not added to the credit;...
Page 22 Jackpot Machine INITIAL SETUP AND SERVICE FUNCTIONS Page 4  Coin Drop - amount in money of the tokens, dropped into a drop box;  Extra Coins Out - amount in money, equal to a product of number of events Extra coin paid by value of 1 token. ...
Page 23 Jackpot Machine INITIAL SETUP AND SERVICE FUNCTIONS Page 5 The page consists of Cat 4 Cash Jackpots statistics. This page contents two columns: Hits and Total Paid. In Hits column the total number of jackpots won of the appropriate level Mini, Midi, Maxi and Mega Is written.
Page 25 Jackpot Machine INITIAL SETUP AND SERVICE FUNCTIONS To view the next or previous pages of this menu use Button B2/ Button B1 buttons. To return back to the Main Мenu press a Button B5. II.1.2. Game Accounting When this element of the Accounting menu is chosen, a page whit list of the game names in Multigame appears.
Page 26 Jackpot Machine INITIAL SETUP AND SERVICE FUNCTIONS Page 1 Parameters, displayed on this page:  Total Bet (Coin In) - sum of all bets in money,  Total Won - sum of all winnings in money (including from progressive jackpots, external bonuses and double ups ); ...
Page 27 Jackpot Machine INITIAL SETUP AND SERVICE FUNCTIONS  Game hold % - current percentage, held from the game. Equal to (100- Game yield) [%];  Game yield % - current yield percentage of the game. Jackpots, external bonuses, and double-ups are accounted; ...
Page 28 Jackpot Machine INITIAL SETUP AND SERVICE FUNCTIONS Page 3  Host Bonus Hits - number of bonuses won from the host;  Mystery Jackpot Hits - number of Mystery Jackpots won (total for all kind of CBJS: Mini, Middle, Super); The next shown pages - 4, 5, 6, and etc.
Page 33 Jackpot Machine INITIAL SETUP AND SERVICE FUNCTIONS Page 12 To view the next or previous pages of this menu use Button B2/ Button B1 buttons. To return back to the Main Мenu press a Button B5. II.1.3. Total Denomination Accounting ©2013-2014, Euro Games Technology Ltd.
Page 34 Jackpot Machine INITIAL SETUP AND SERVICE FUNCTIONS Total Denomination Accounting and the Denomination in 0,01 EUR format are shown on the top of the page This page consists the total accounting by denominations for the machine as a whole. There are Master and Period Accounting columns. If different denominations are set, information of the least of them is shown at first (1 Player Denomination).
Page 35 Jackpot Machine INITIAL SETUP AND SERVICE FUNCTIONS When this element of the Accounting menu is chosen, a page whit list of the game names in Multigame appears. Game Denomination Accounting is written on the left top. When some of the games is chosen, Denomination Accounting page for the chosen game is logged.
Page 36 Jackpot Machine INITIAL SETUP AND SERVICE FUNCTIONS II.1.5. Voucher Accounting Only Master Accounting column is displayed on the screen.  Cashable Voucher In - sum in money of cashable vouchers, accepted by the machine;  Cashable Voucher In count - number of cashable vouchers, accepted by the machine;...
Page 37 Jackpot Machine INITIAL SETUP AND SERVICE FUNCTIONS II.1.6. Bill Accounting The following information is displayed on this page:  The number of bills of appropriate nominal, accepted in stacker;  Total number of bills accepted;  Total amount of bills accepted. These pages like Machine Accounting page consist of two columns - Master Accounting and Period Accounting.
Page 38 Jackpot Machine INITIAL SETUP AND SERVICE FUNCTIONS II.1.7. Security Accounting Page 1 Information, related to security is displayed on this page. Parameters, displayed on this page:  Main Door - gaming machine main door;  Last Open - date and time of last main door opening; ...
Page 39 Jackpot Machine INITIAL SETUP AND SERVICE FUNCTIONS  Drop Door - gaming machine drop door;  Last Open - date and time of last drop door opening;  Last Close - date and time of last drop door closing;  Bill Stacker Box Door - bill stacker access door;...
Page 40 Jackpot Machine INITIAL SETUP AND SERVICE FUNCTIONS  Games since last power on - number of games, played since the last power off;  Belly door - belly door access door;  Last Open - date and time of last belly door opening; ...
Page 41 Jackpot Machine INITIAL SETUP AND SERVICE FUNCTIONS  Last Close - date and time of last main door closing at machine power off;  Open count -number of main door openings at machine power off;  Logic board door (power off) - information of condition of the Exciter II metal case door at machine power off;...
Page 42 Jackpot Machine INITIAL SETUP AND SERVICE FUNCTIONS Registered errors of the machine are displayed on this page. Parameters, displayed on this page:  Coin In Jams - number of token jams in the Coin Acceptor  Coin Alarm - number of warning situations, reported by the Coin Acceptor;...
Page 43 Jackpot Machine INITIAL SETUP AND SERVICE FUNCTIONS II.1.9. Clear Period Accounting The following message appears on the center of the page: Press a button “Start” to clear all period meters By pressing of the Start button all Period Accountings are reset. To return back to the Main Menu press a Button B5.
Page 44 Jackpot Machine INITIAL SETUP AND SERVICE FUNCTIONS II.2.1. Keyboard Test A window with the 18 keyboard buttons and their appropriate names appears on the screen. Test of the keyboard buttons LEDs. If the test is available, the buttons are colored in one of the 5 colors, described below according to appropriate LEDs condition.
Page 45 Jackpot Machine INITIAL SETUP AND SERVICE FUNCTIONS II.2.2. Doors and Keys Test This is a page for test of doors, mechanical locks, and battery condition. A window with names of the eight doors is displayed - The door names are displayed in two different colors.
Page 46 Jackpot Machine INITIAL SETUP AND SERVICE FUNCTIONS II.2.3. Top Lamps Test This is a page for test of 3 top signal lights. The positions and numbers of the lamps in two situation variants (horizontally and upright), and a light mode during the test are displayed on the screen.
Page 47 Jackpot Machine INITIAL SETUP AND SERVICE FUNCTIONS Button B1/B2 buttons - Left channel volume - low/high Button B3/B4 buttons - Right channel volume - low/high START button - Save and Exit Button B5 - Exit with no changes of settings. Turning up and down of both channels may be also performed by touching the left or right channel scale on the touchscreen.
Page 48 Jackpot Machine INITIAL SETUP AND SERVICE FUNCTIONS To enter in this menu the printer has to be enabled in the machine setup. Otherwise, the menu is not active and it is colored in gray. The following message appears on the screen: Printer test To print void ticket press “Start”...
Page 49 Jackpot Machine INITIAL SETUP AND SERVICE FUNCTIONS The following message appears on the screen: Insert Bill or Ticket to start Test When a bill is inserted in the bill validator and the bill is detected by it, the following message appears on the screen: The inserted Bill is xx.xx [bank code] When a ticket is inserted in the bill validator and the ticket is detected by it, the following message appears on the screen:...
Page 50 Jackpot Machine INITIAL SETUP AND SERVICE FUNCTIONS II.2.9. Temperature Monitor Temperature Monitor screen - displays information of the temperatures in Processor Cores (CORE1-1, CORE1-2, CORE2-1, CORE2-2), Exciter Motherboard (SYSTEM), Processor (CPU) and Graphic Processor (GPU): To return back to the Main Menu press a Button B5. II.2.10.
Page 51 Jackpot Machine INITIAL SETUP AND SERVICE FUNCTIONS To enter in this menu the coin acceptor has to be enabled in the machine setup. Otherwise, the menu is not active and it is colored in gray. The following message appears on the screen: Coin Acceptor Test: shows its current condition Disable or Enable;...
Page 52 Jackpot Machine INITIAL SETUP AND SERVICE FUNCTIONS To enter in this menu the hopper has to be enabled in the machine setup. Otherwise, the menu is not active and it is colored in gray. The following messages appear on the screen: Press Button B1 to pay 1 coin.
Page 53 Jackpot Machine INITIAL SETUP AND SERVICE FUNCTIONS MD5: at pressing Button B2 button calculated MD5 of all SATA flash card is written; Bill Validator Data: information of software version, got from the bill validator; Ticket Printer Data: information of software version, got from the printer At each entering to this page nothing is displayed after the inscriptions SHA1: and MD5: When Button B1 or Button B2 buttons are pressed, an inscription given...
Page 54 Jackpot Machine INITIAL SETUP AND SERVICE FUNCTIONS II.3. HISTORY OF LAST 50 GAMES The Played Games History contains up to 50 records, as each of them covers data of the main games, bonus games in them, double-ups and jackpots. To enter History menu use the Cashier, Admin or Owner keys and then select Play History.
Page 55 Jackpot Machine INITIAL SETUP AND SERVICE FUNCTIONS The positions of the stopped reels for a given game are displayed on the left of the screen and the following parameters under them: Date - date and time of the game start; ─...
Page 56 Jackpot Machine INITIAL SETUP AND SERVICE FUNCTIONS The following rows are shown if the corresponding event has occurred: Mystery: (winning from CBJS Mystery); ─ Host Award: (winning from SAS Host bonus); ─ Collected: (sum of all money, paid out from winning, exceeded limits or ─...
Page 57 Jackpot Machine INITIAL SETUP AND SERVICE FUNCTIONS The pages appear only if there was C4C feature in the appropriate game. Free Spin X of 8 sign is displayed at the top of the screen, where X is the number of the current C4C free spin and 8 is the total number of C4C free spins. On the left of the screen the positions of the stopped reels for a given C4C free spin are displayed and under them the following parameters: Date - date and time of the trigger game start;...
Page 58 Jackpot Machine INITIAL SETUP AND SERVICE FUNCTIONS Game End Credit - displays the monetary value of the credit after the game ─ completion; Since This Game: - credit events, occurred after the end of this game and ─ before the start of the next game; The following rows are shown if the corresponding event has occurred: Mystery: (winning from CBJS Mystery);...
Page 59 Jackpot Machine INITIAL SETUP AND SERVICE FUNCTIONS II.3.3. Free Spins - History The pages appear only if there were free spins in the appropriate game. Free Spin X of Y sign is displayed at the top of the screen, where X is the number of the current free spin and Y is the total number of free spins.
Page 60 Jackpot Machine INITIAL SETUP AND SERVICE FUNCTIONS Lines Win - monetary amount of the winning, formed by line combinations ─ of the trigger game. This row appears only if there are some line winnings in the trigger game; Scatter Win - monetary amount of the winning, formed by scatter ─...
Page 61 Jackpot Machine INITIAL SETUP AND SERVICE FUNCTIONS Midi Jackpot ─ Maxi Jackpot ─ Mega Jackpot ─ Collected Credits ─ C4C Coins ─ C4C Mystery Win ─ Each of components is written only if such winning is won in the feature. The winning is shown in money with appropriate bank code of the currency.
Page 62 Jackpot Machine INITIAL SETUP AND SERVICE FUNCTIONS II.4. EVENT LOGS II.4.1. All Events Log This window displays information on activity during the game, access to the machine, errors in periphery devices and failures of the amusement machine. All events and errors in all categories are displayed in a table, which consists of columns with ID number, date and time of the event, description, and event data.
Page 63 Jackpot Machine INITIAL SETUP AND SERVICE FUNCTIONS II.4.2. Credit In Log This page displays information of last 20 additions of credit by a key. The money added by Attendant key is registered - Keyed In. The ID number of the event, its date and time, and the money amount in appropriate currency are shown in the displayed table.
Page 64 Jackpot Machine INITIAL SETUP AND SERVICE FUNCTIONS This window displays information of the payments, caused by CASH OUT button pressing and of winnings, paid out as a result of Credit Limit exceeding. At payment via hopper after payment completion (by reason of fully amount paid or of empty hopper), Pay out completed, and the amount paid are logged.
Page 65 Jackpot Machine INITIAL SETUP AND SERVICE FUNCTIONS To view the next or previous pages of this menu (if there are such) use Button B2/ Button B1 buttons. To return back to the Main Menu press a Button II.4.6. Progressive Log This window displays information of last 20 progressive jackpots, won by the gaming machine: ...
Page 66 Jackpot Machine INITIAL SETUP AND SERVICE FUNCTIONS Progressive jackpot paid is displayed at 1 row in a Description column. The amount in money is displayed in an Event Data column. To view the next or previous pages of this menu (if there are such) use Button B2/ Button B1 buttons.
Page 67 Jackpot Machine INITIAL SETUP AND SERVICE FUNCTIONS II.4.8. Voucher Out Log Printed vouchers and receipts are logged at this page. The voucher type is displayed at the 1 row in a Description column, and validation data: and the last 4 numbers of bar code is displayed at the 2 row.
Page 68 Jackpot Machine INITIAL SETUP AND SERVICE FUNCTIONS II.4.9. Cashless In Log Amounts, received as result of AFT transfer, are logged at this page. Amount received is displayed at the 1 row in a Description column, and ID and transaction number, kind of transfer, credit, and amount are displayed at the row.
Page 69 Jackpot Machine INITIAL SETUP AND SERVICE FUNCTIONS II.4.10. Cashless Out Log Payments, as result of AFT transfer, are logged at this page. Amount sent is displayed at the 1 row in a Description column, and ID and transaction number, kind of transfer, credit, and amount are displayed at the 2 row.
Page 70 Jackpot Machine INITIAL SETUP AND SERVICE FUNCTIONS II.4.11. Host Bonus and Mystery Log Amounts of bonuses, accepted by the SAS host or CBJS Mystery Jackpots, are logged at this page: The type of the bonus and awarded are displayed at the 1 row in a Description column, and the amount in money is displayed in an Event Data column.
Page 71 Jackpot Machine INITIAL SETUP AND SERVICE FUNCTIONS All parameters, which are set after the setting of another one, are colored in gray at first, and they are not available for setting till the parameter, on which they are dependent, is set. The parameters which have not Not Set in their setting options is not one time settable parameters and correction is possible in any time.
Page 72 Jackpot Machine INITIAL SETUP AND SERVICE FUNCTIONS II.5.2. Device Setup The parameters, listed below are one-time settable parameters:  Bill Validator: Not Set/ None/ JCM/ Cash Code/ Ardac Elite/ MEI - chooses whether there is a bill validator and its type; ...
Page 73 Jackpot Machine INITIAL SETUP AND SERVICE FUNCTIONS II.5.3. Monetary Settings The parameters, listed below are one-time settable parameters:  Currency Code - is inserted the bank code of the currency used to be displayed with the amounts of money both on the game screen and in service functions; ...
Page 74 Jackpot Machine INITIAL SETUP AND SERVICE FUNCTIONS To select an upper or a lower parameter use Button B1/ Button B2 buttons. To choose the next or the previous option of the chosen parameter condition, use Button B4/Button B3 buttons. The given parameter setting can start after pressing a START button.
Page 75 Jackpot Machine INITIAL SETUP AND SERVICE FUNCTIONS II.5.5. Bill Validator Channels Setup of the bill validator 16 channels. To enter in this menu the bill validator has to be enabled.  Setup Mode: Not Set/ Auto/ Manual - gives a possibility for automatically set the channels, according to the appropriate currency channels in the bill validator.
Page 76 Jackpot Machine INITIAL SETUP AND SERVICE FUNCTIONS II.5.6. Limits Setup To enter in this menu, Device Setup and Monetary Settings have to be done. The limits can to be changed if the credit is zero.  Credit Limit: - the maximum amount in money, which may be inserted into Credit meter.
Page 77 Jackpot Machine INITIAL SETUP AND SERVICE FUNCTIONS  Attendant Limit - the maximum permissible amount in money, which the attendant can insert by key, taking account of the current credit. Can set only if Attendant Add Credit is enabled. Attendant Limit has to be ≤ Credit Limit. If Credit Limit=0, then Attendant Limit is not limited.
Page 78 Jackpot Machine INITIAL SETUP AND SERVICE FUNCTIONS II.5.7. Mechanical Counters The entering in this screen is possible only if the Monetary Settings are done. Choice What Will the Mechanical Counters Count Out Each of the listed parameters can be counted out by one of the mechanical counters.
Page 79 Jackpot Machine INITIAL SETUP AND SERVICE FUNCTIONS Progr. Jackpot: Not set/ None/ 1/ 2/ 3/ 4/ 5/ 6/ Progr. Jackpot Hits: Not set/ None/ 1/ 2/ 3/ 4/ 5/ 6/ Games: Not set/ None/ 1/ 2/ 3/ 4/ 5/ 6/ WARNING! Total Win = Coin Out (Not Hand Paid Win) + Jackpot (Hand Paid Win) Do not direct two Jackpot (Hand Paid Win) parameters to one and the...
Page 80 Jackpot Machine INITIAL SETUP AND SERVICE FUNCTIONS If one and the same counter counts out simultaneously events and money, at pressing the button for “Save” “Wrong Settings!” message in a red splash is appeared on the screen. The save procedure is not completed. The same splash is appeared if there is at least one parameter with Not Set.
Page 81 Jackpot Machine INITIAL SETUP AND SERVICE FUNCTIONS  Gamble Limit: - is not used. To select an upper or a lower parameter use Button B1/ Button B2 buttons. To choose the next or the previous option of the chosen parameter condition, use Button B4/Button B3 buttons.
Page 82  Display EGT Mystery Jackpots in the help screens – Not Set/ Enable./ Disable – When it is Enable page 10 with Mystery jackpots amounts is added to the help screen. When it is Disable the Mystery jackpots amounts are not shown in the help screens.
Page 83 Jackpot Machine INITIAL SETUP AND SERVICE FUNCTIONS To select an upper or a lower parameter use Button B1/ Button B2 buttons. To choose the next or the previous option of the chosen parameter condition use Button B4/Button B3 buttons. The given parameter setting can start after pressing a START button.
Page 84 Jackpot Machine INITIAL SETUP AND SERVICE FUNCTIONS II.5.10.1. Common The parameters with a Not Set option in their fields are one-time settable parameters.  Voucher In: Not Set/ Disable/ Channel 1/ Channel 2 - This parameter defines whether the bill validator will be able to accept vouchers (tickets) and at which channel in the SAS network.
Page 85 Jackpot Machine INITIAL SETUP AND SERVICE FUNCTIONS The following parameters are available to set if Enhanced Validation is enabled:  Handpay Validation: Not Set/ Channel 1/ Cannel 2 - This parameter defines whether there will be validation of handpay events from the host in the machine and at which channel in the SAS network.
Page 86 Jackpot Machine INITIAL SETUP AND SERVICE FUNCTIONS II.5.10.2. SAS Channels Setup The parameters with a Not Set option in their fields are One-time settable parameters  Address - address of the machine in the SAS network for the given channel; NOTE! If a given channel is not used, its address has to be set equal to 0.
Page 87 Jackpot Machine INITIAL SETUP AND SERVICE FUNCTIONS SAS Channel 1 SAS Channel 2 Address: from 0 to 127 - may be changed at Address: from 0 to 127 - may be changed at credit=0 credit=0 Game Play Exceptions: Not set/ Game Play Exceptions: Not set/ Disable/Enable Disable/Enable...
Page 88 Jackpot Machine INITIAL SETUP AND SERVICE FUNCTIONS This menu is accessible to setup only if Voucher Out is enabled. A screen with a keyboard and 8 fields is shown. The text, which is inserted in the fields of the screen, is printed out on the voucher or the receipt. ...
Page 89 Jackpot Machine INITIAL SETUP AND SERVICE FUNCTIONS II.5.10.4. AFT Setup This menu is available to set only if AFT is enabled. The parameters with Not Set options are one-time settable parameters.  Partial Transfer: Not set/ Enable/Disable - when is enabled, it is possible to transfer an amount less than the definite one from the host;...
Page 90 Jackpot Machine INITIAL SETUP AND SERVICE FUNCTIONS  Host controlled - The host (not the machine) defines whether the cash out control will be Soft or Hard.  Answer to Registration Poll - Yes/ No - determines whether the machine answers to host if the machine has AFT registration.
Page 91 Jackpot Machine INITIAL SETUP AND SERVICE FUNCTIONS II.5.12. Machine Info Setup  Serial Number: 0 - May be inserted only numbers. One-time settable parameter;  Asset Number: 0 - May be inserted only numbers. One-time settable parameter. To select an upper or a lower parameter use Button B1/ Button B2 buttons. To choose the next or the previous option of the chosen parameter condition, use Button B4/Button B3 buttons.
Page 92 Jackpot Machine INITIAL SETUP AND SERVICE FUNCTIONS II.5.13. Lamps Test Masks Mechanical counters lamp and machine keyboard lamps (LED’s) test setup page.  Mechanical Counters Lamp: Enable/ Disable - enables and disables the test of mechanical counters lamp;  KB General Test: Enable/ Disable - enables and disables the test of the keyboard lamps (LEDs) ...
Page 93 Jackpot Machine INITIAL SETUP AND SERVICE FUNCTIONS  Gamble/Black/Select Bet Lamp: Disable  Take Win Lamp: Disable  Start Lamp: Enable/ Disable After enabling the common test flag, the individual test flags for each LED may be set. The LEDs with enabled flag are tested at each machine start-up and this will generate warning messages on the screen and Events Log records if there is short circuit in LED or LED burned out.
Page 94 Jackpot Machine INITIAL SETUP AND SERVICE FUNCTIONS II.6. GAME SETUP II.6.1. Common Setup ©2013-2014, Euro Games Technology Ltd.
Page 95 Jackpot Machine INITIAL SETUP AND SERVICE FUNCTIONS Parameters for set:  Show Game Rating: No/ Yes - determines whether the Game Rating button will be on the select game screen or not. In this way the rating of the games by numbers of played games will be enabled or not. ...
Page 96 Jackpot Machine INITIAL SETUP AND SERVICE FUNCTIONS II.6.3. Games Settings/ Games Setup When Games Settings is selected from the list in Game Setup menu, a page where all enabled games are listed appears on the screen. When select a game from this list, a page for setup of appropriate game appears.
Page 97 Jackpot Machine INITIAL SETUP AND SERVICE FUNCTIONS NOTE! If enter SF and this parameter is set No until the given game is the current chosen, then after exit SF the screen for game selection appears with corrected place of the select game video-buttons. NOTE! At disabling of a game, its Accounting remains accessible as in SF, as on SAS.
Page 98 Jackpot Machine INITIAL SETUP AND SERVICE FUNCTIONS At Min Bet per Line = 5: At Min Bet per Line = 10: Max Bet Max Bet per Line per Line Button B1 Button B1 Button B2 Button B2 Button B3 Button B3 Button B4 Button B4 Button B5...
Page 99 Jackpot Machine INITIAL SETUP AND SERVICE FUNCTIONS II.7.1. Hopper Fill To fill the hopper with tokens, follow the procedure, described below: Activate any of the following keys: Cashier, Admin or Owner. Service Functions screen will appear on the display; From Service menu select Hopper Fill option. Screen for service hopper filling with tokens will appear.
Page 100 Cash field shows the current credit value. The value of the current winning may be including in this value. Otherwise, it is necessary to phone to the EGT Service and tell the operator your Base Code. The operator will give you your activation code in reply, which code shall be entered into Enter Code field.
Page 101 Head Office Address 4 Maritsa Str. Vrana-Lozen-Triugulnika Pancharevo Region 1151 Sofia, BULGARIA EGT Technical Support - Head Office Phone: +359 2 890 24 68 Fax: +359 2 890 24 88 Mobile: +359 896 71 02 72 e-mail: service@egt-bg.com; parts@egt-bg.com EGT Sales - Head Office...
