  • Page 1 Keysight HD3RACK Rack Mount Kit for InfiniiVision HD3-Series Oscilloscopes INSTALLATION GUIDE...
  • Page 2 Notices © Keysight Technologies, Inc. 2024 and may be used or copied only in acquires no greater than Limited Rights as accordance with the terms of such license. defined in FAR 27.401 or DFAR 227.7103-5 No part of this manual may be reproduced in (c), as applicable in any technical data.
  • Page 3 In This Guide… This guide contains instructions for installing the Keysight HD3RACK Rack Mount Kit for InfiniiVision HD3-Series Oscilloscopes. The rack mount kit provides a support shelf and hardware for mounting Keysight HD3-Series oscilloscopes into Electronic Industries Association (EIA) standard 19-inch (487-mm) rack cabinets.
  • Page 4 Here are the dimensions of the support shelf. 482 mm 18.98 in. 268 mm 10.55 in. 209 mm 8.23 in. 240 mm 9.45 in. (without (with front front handles) handles) Rack Mount Kit for HD3-Series Oscilloscopes...
  • Page 5: Installation

    Keysight HD3RACK Rack Mount Kit for HD3-Series Oscilloscopes Installation Guide Installation Prepare the support shelf Attach the oscilloscope to the support shelf Install the support shelf You need the following tools to install the rack mount kit: • T20 TORX driver.
  • Page 6 Installation Prepare the support shelf 1 Remove the screws and washers (two per screw) that secure the two retaining brackets. Set the screws, washers, and brackets aside. Rack Mount Kit for HD3-Series Oscilloscopes...
  • Page 7 Installation Attach the oscilloscope to the support shelf 1 Place the oscilloscope on the support shelf. Slightly raise the rear of the oscilloscope and slide it fully forward until it stops. 2 Push the oscilloscope fully forward on the support shelf assembly. Rack Mount Kit for HD3-Series Oscilloscopes...
  • Page 8 Installation 3 Install the two retaining brackets and washers that you previously removed: a Push the brackets fully forward until they stop against the oscilloscope’s rear feet. b Secure each bracket using the screw and washers you previously removed. There are two washers per screw so the screw does not protrude from the bottom of the shelf.
  • Page 9 Installation Install the support shelf 1 Place the four sheet metal nuts at their proper locations in the rack front. 2 Hold the support shelf using the front handles, and using the support shelf guide pins, slide the support shelf into the rack cabinet. 3 Fasten the support shelf to the rack cabinet using four 10-32 dress screws.
  • Page 10 Installation Rack Mount Kit for HD3-Series Oscilloscopes...
  • Page 12 This information is subject to change without notice. © Keysight Technologies, Inc. 2024 Printed in Malaysia First edition, July 2024 *54760-97000* 54760-97000 www.keysight.com...
