Automatic Label Dispenser
User Manual
(Manual No.7947)
Model: USS-LD00015/21/22/23
This manual should be made available to all users of this
equipment. For best results and maximum durability of the
equipment, carefully read and follow all instructions.
Version2.0©202404
For questions or concerns, e-mail service@ussolid.com, visit www.ussolid.com
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for U.S. Solid USS-LD00015
Summary of Contents for U.S. Solid USS-LD00015
- Page 1 Automatic Label Dispenser User Manual (Manual No.7947) Model: USS-LD00015/21/22/23 This manual should be made available to all users of this equipment. For best results and maximum durability of the equipment, carefully read and follow all instructions. Version2.0©202404 For questions or concerns, e-mail service@ussolid.com, visit www.ussolid.com...
- Page 3 I. Product Specifications I. Gar MODEL USS-LD15-80 USS-LD15-120 USS-LD15-180 USS-LD21-80 USS-LD21-120 USS-LD21-180 USS-LD21-80-FOS USS-LD21-120-FOS USS-LD21-180-FOS USS-LD22-80 USS-LD22-120 USS-LD22-180 USS-LD23-80 0.2”- 3.15” (5-80 USS-LD23-120 0.2”- 4.7” (5-120 USS-LD23-180 0.2”- 7” (5-180 mm) Label Width Range 0.2”- ∞ (5-∞ mm) Label Length Range 1/1.5/3 inches Core Diameter Max.
- Page 4 II. Machine Introduction I. Gar 1.5” Core 3” Core Insert Insert Paper Baffle Pressing plate Hanger Shaft Speed Knob Peel Off Plate Sensor U Pin Rewinder Shaft Power Switch USS-LD22/USS-LD23 Panel Description Counter: Count labels and display the preset number of labels from 0 to 9999999. Speed + or -: Increase or decrease speed, adjustable from 1 to 9 levels.
- Page 5 display shows ”0”. The preset is done. Press the “auto” button once, the dispenser will start to work and stop automatically after a preset quantity is reached. At this time, the manual indicator light is on. Then press "reset" and "auto" again, and the machine will dispense the labels in cycles according to the preset quantity.
- Page 6 hold the label core against the roll. Please note: The paper baffle must be tightened sufficiently. The innerspring should be pressed in half, at least. 4. Pull the leading edge of the label paper under the pressing plate, through the dispensing plate, and down towards the rewinder shaft.
- Page 7 Adjusting the tension of the pressing plate(Refer to Figure 4) The tension of the pressing plate has three levels, the default is minimum level 1. Larger tension is recommended for high viscosity labels and soft labels. (Figure4) IV. Pack List .
- Page 8 The machine’s motor and circuit board have a one-year warranty. This warranty covers any defects in material or workmanship under normal use. Within 30 days of delivery, U.S. Solid will either work with you to repair your product with replacement parts, replace the product after receiving the returned defective machine, or accept a returned defective machine for a full refund.
