- Page 1 Translation of original operating instructions Operating instructions Turbo tank trailer We are Fliegl. from model year 06/2019...
- Page 3 12/09/2019 Copyright Fliegl, 2019 All rights reserved. Reproduction, in whole or in part, only with permission from Fliegl. We are constantly developing and enhancing our products and therefore reserve the right to make changes to them without prior notification.
- Page 4 84453 Mühldorf am Inn, Germany Description and identification: Product: Fliegl turbo tank trailer Type: HFW 5000, HFW 6200, HFW 7500, HFW 8600, HFW 10600, HFW 12000, HFW 14000, HFW 16000, HFW 18000, HFW 20000, HFW 22000, HFW 25000 Project designation:...
- Page 5 Fliegl Agrartechnik GmbH assumes no liability for the use of other products and any resulting damage. No claims for modification of delivered products can be made on the basis of the information, images and descriptions provided in this manual.
- Page 6 Turbo tank trailer Designated use The Fliegl turbo tank trailer is intended for general use in agricultural applications. It is designed and suitable for transporting and spreading sludge, slurry, biogas fermentation residue etc. Please contact the manufacturer regarding the trailer's suitability for conveying special transport media.
- Page 7 The centre of gravity and thus the drawbar load may shift depending on how the load is distributed. If additional devices are used, the payloads, empty loads and axle loads will change. 7 of 20 Fliegl Agrartechnik GmbH, 84453 Mühldorf am Inn, Germany...
- Page 8 Means of supporting and protecting against falling Thread – grade (min.) Fitting location Tightening torque [Nm] M20 – 10.9 Drawbar eye M30 – 8.8 Traction bar 1400 Overrun brake mechanism See section 10 8 of 20 Fliegl Agrartechnik GmbH, 84453 Mühldorf am Inn, Germany...
- Page 9 Test the brake function before driving with the trailer. The response characteristics of the brake can be altered by means of a throttle check valve in the tractor brake system (if fitted). 9 of 20 Fliegl Agrartechnik GmbH, 84453 Mühldorf am Inn, Germany...
- Page 10 Connect the pressure line (1). (The pressure line leads to the pressure filter on the machine.) Connect the oil return hose (2) to the oil return line (T) of the towing vehicle, as in the case of the single-action control device. 10 of 20 Fliegl Agrartechnik GmbH, 84453 Mühldorf am Inn, Germany...
- Page 11 Check the drive shaft length when straight and at maximum steering angle. Check that the drive shaft profile has overlapped by 2/3 and can still move freely when steered. With overload protection max. torque 2000 Nm 11 of 20 Fliegl Agrartechnik GmbH, 84453 Mühldorf am Inn, Germany...
- Page 12 Transport the tank trailer from its usage or cleaning location to the storage area. Disconnect the hydraulic, pressure and electrical lines from the Fliegl tank and your tractor. Then re-attach the dust caps to the lines, and secure the lines in the designated storage location (hose holder) on the tank trailer.
- Page 13 The fill level can be monitored via the fill level indicator. When filling is complete, stop the pumping station and close the dome cover. Now drive the Fliegl turbo tank trailer to the usage location. The removal and stirring of slurry produces highly toxic gases which are explosive when combined with oxygen.
- Page 14 For commercial vehicles, check the screw connections after the first 10 operating hours Retighten all loose screw connections as necessary W = workshop task Or weekly Or quarterly Replace hydraulic hoses every 6 years 14 of 20 Fliegl Agrartechnik GmbH, 84453 Mühldorf am Inn, Germany...
- Page 15 Lubricate the three-way slider Pivoting drawbar eye Lubricating the drive shafts: The drive shafts must be lubricated at the specified points every 50 operating hours. Fig. 11: Drive shaft 15 of 20 Fliegl Agrartechnik GmbH, 84453 Mühldorf am Inn, Germany...
- Page 16 If this is exceeded, the brake system must be re-adjusted or repaired by a specialist brake workshop. Mechanical ALB regulation ALB = automatic load-dependent brake force regulation. The setting length is specified on the ALB plate. This setting must not be changed. 16 of 20 Fliegl Agrartechnik GmbH, 84453 Mühldorf am Inn, Germany...
- Page 17 Check the brake lining regularly (every 200 operating hours) and adjust if necessary. The default setting is preset in the factory. The default setting must only be restored when replacing drawbars or parts of the support bearing group. 17 of 20 Fliegl Agrartechnik GmbH, 84453 Mühldorf am Inn, Germany...
- Page 18 7-pin connector Yellow Blue White Green Brown Black ISO/DIN 1724 The three ground wires must not be electrically connected to the trailer. 18 of 20 Fliegl Agrartechnik GmbH, 84453 Mühldorf am Inn, Germany...
- Page 19 Only mineral oil of the type ISO VG 460 must be used for the pump gear (required volume: 1.5 l). When the pump is not in use and there is a risk of freezing, the supplied medium must be emptied via the drain plug. 19 of 20 Fliegl Agrartechnik GmbH, 84453 Mühldorf am Inn, Germany...
- Page 20 Fliegl Agrartechnik GmbH Bürgermeister-Boch-Str. 1 D-84453 Mühldorf a. Inn Tel.: +49 (0) 86 31 307-0 Fax: +49 (0) 86 31 307-550 e-Mail: info@fliegl.com 1-007K06191.2...
