Pairing the TV Streamer to
the Nucleus
Turn on your TV Streamer
1 1
Plug the TV Streamer into the wall for
power. You will see a green light on the
front of the TV Streamer.
Press the pairing button
1 3
on the TV Streamer
The TV Streamer will flash yellow for 20
seconds when it is in pairing mode.
Note: You may pair up to 3 accessories. Press the
button one time for the first accessory, two times
for the second accessory, and three times for the
third accessory.
Look for the blue light on your sound processor
1 5
Your sound processor will flash blue when successfully paired!
If you do not see the blue light, attempt steps 2–4 again, turning
the device(s) on more quickly after pressing the pairing button.
Use either the RCA or digital optical cable to connect to your TV
6
For help, call Device Support at 800 483 3123, then select option 2.
8 Sound Processor
®
Turn off your sound processor
2
Hold the button
—OR—
for 5 seconds
The light on top will turn off when the
sound processor is off.
Note: If you wear a Cochlear device on the other
ear, turn it off now.
Turn on your sound processor
4 1 4
Within 20 seconds of pressing
the pairing button:
Press the
—OR—
button one time
Note: If you wear a Cochlear device on the other
ear, turn it on now.
2
1
Remove the
battery
3
4
Attach the
battery
Advertisement
Need help?
Do you have a question about the Mini Microphone 2+ and is the answer not in the manual?
Questions and answers
How do I delete a second pairing for the mini mic? It's on both channel 1 and channel 3. My TV streamer is on channel 1.
To delete a second pairing for the Cochlear Mini Microphone 2+ on channel 3, follow these steps:
1. Turn off your Cochlear sound processor.
2. Turn on the Mini Microphone 2+.
3. Press the pairing button three times using the tip of a pen or similar object. The status LED will flash yellow three times per sequence, indicating channel 3 pairing mode.
4. While pairing mode is active, turn on your sound processor.
5. The sound processor should indicate successful pairing with an audible melody or flashing light.
Since the microphone supports up to three accessory pairings, re-pairing a new device on channel 3 will replace the existing pairing.
